- Page 1 Stationary water filter Geyser- Model types ClassiC for soft water for water with high iron content for hard water for complex water treatment Operational and installation HousinG Colour Manual white...
-
Page 2: Table Of Contents
Thank you for choosing Geyser water filter! our technologies and developments provide water of perfect quality in your house. This manual describes all Geyser filter functional capabilities and filter set-up. read carefully and keep to refer it in future. Everything for filter usage just after its set-up is packed. -
Page 3: Geyser Technologies
Comfortable set-up - water flow direction can be changed easily by means of the patented system of a cartridge mounting (Patent №2014135903). safety – all the materials used in Geyser systems are certificated to contact with drinking water and products. - Page 4 FilterinG Materials and CartridGes Sediment cartridge is made of polypropylene (PFM, РР, PPY). It removes dirt, suspended solids and insoluble impurities >5 µm from water Aragon is micro-porous ion-exchange polymer. It removes a wide range of harmful impurities from water: hardness salts, iron, manganese, heavy metals, chlorine, solids and organic compounds.
-
Page 5: Scope Of Supply
sCope oF supply Assembled filter Connection pipe 1/4” „ „ wrench for a housing triple adaptor „ „ wrench for a bottom valve Manual „ „ Pure water tap with everything for Package „ „ connection The manufacturer reserves the right to make design and packaging of a minor improve without showing in this manual. ConneCtion Guidelines For ConneCtion and use The connection should be fulfilled by a qualified specialist or a manufacturer’s representative! - Page 6 ConneCtion diaGraM System is connected to cold water pipe Cover (monoblock) Housings with cartridges Decorative bowl triple adapter with a tap rubber gasket Plastic washery kit Connection pipe 1/4” Insert to fix a cartridge fastening nut with a washery kit Collet clamp screw 1/4’’...
- Page 7 ConneCtion to water pipe Make sure that water feed to a place of connection is shut off! 1. Fix a triple adapter (A) to the cold water main line, making the connections tight (Fig. 1). А В 2. Insert a plastic pipe (Fig. 2) into a screw (В). Insert a pipe into a fitting of a ball valve until it stops and tighten a screw (рис.
-
Page 8: Start Up
Cartridges should be replaced upon the expiration of their capacity or service life. WARNING! only Geyser cartridges are recommended to use in replacement of the used ones. Failure to comply with this instruction may change a filter functions and specifications. - Page 9 (if necessary) the sealing ring; then replace the corresponding cartridge (Fig. 4). Sealing ring recommended to be greased with food silicon or Vaseline (do not use sealant!) prior to reassembly. return the housing to its position and tight with the wrench.
- Page 10 to the top of the cartridge through its threaded throat portionwise. then wrap its throat with overwrap and fix it with an elastic or a string. Turn the cartridge upside down and unscrew a bottom valve with the corresponding wrench. Put it into a kitchen sink in the same bind vertically and pour 3 more liter water through it, as aforesaid.
-
Page 11: Warranty Liabilities
warranty liaBilities Guaranteed use period of filter operation is 3 years from the sale date. In case the date and the seal of trading organization are missing the warranty dates from the filter release day. the warranty does not apply to the cartridge, its capacity is indicated on page 4. - Page 12 Geyser aquaChief occupies two times less space than system working with standard whelmed media. individual attention it is very easy to tune up Geyser aquaChief to purify water in different regions with the variety of ecotar media types. Detailed information on www.geizer.com MANuFACTuRER: “AKvATORIA”...
Need help?
Do you have a question about the Classic and is the answer not in the manual?
Questions and answers
В каком порядке установить картриджи при обратном потоке воды?
To install cartridges for reverse water flow in the Geyser Classic, follow this order:
1. Undo the housing and remove the insert.
2. Flip each of the three inserts 180°.
3. Exchange the first and last cartridges.
4. Reassemble the system.
This setup will reverse the inlet and outlet, changing the water flow direction.
