CAUtIoN: to REDUCE tHE RISK oF PRoPERtY
DAMAGE:
Mobile Phones
Some mobile phone leads do not allow charging from
a standard USB port. Check with the mobile phone
manufacturer before using the phone with this charger.
Rechargeable Devices
If there is any sign that your appliance is behaving
differently when plugged into this charger than it does
when connected to the usual power source, unplug
the appliance and seek advice from the appliance
manufacturer.

POWEr SOurCE rEquIrEmENtS

The power source must provide 12 VDC and must be
able to supply the necessary current to operate the load.
CAUtIoN: to REDUCE tHE RISK oF PRoPERtY
DAMAGE:
• The charger must be connected only to batteries with
a nominal output voltage of 12 Volts. The appliance
will not operate from a 6 Volt battery and will sustain
permanent damage if connected to a 24 Volt battery.
• Always connect the charger to the 12 volt DC power
source before plugging any devices into the unit.
• Do not attach a USB hub to this unit to allow additional
items to be added.
To prevent damage, the unit will shut down if it is
overloaded. To restart the unit you must remove it from
PIUSB2B_ManualENFRSP_050813.indd 8-9
8
the power source, wait for a few seconds and then
re-insert the unit into the power source.

OPErAtING INStruCtIONS

The tip of the plug is positive (+) and the side contact is
negative (–).
1. Connect the unit to a vehicle's accessory outlet or
other 12 volt DC power source. Make sure there is
adequate space for proper ventilation of the charger.
2. Rotate the unit slightly to make sure there is good
contact.
3. The Power/Fault LED Indicator will light blue,
indicating a proper connection.
If the Power/Fault LED Indicator lights red,
•
Fault condition exists. Refer to the Troubleshooting
Section of this Instruction Manual.
• If the charger does not work,
ignition/accessory outlet is powering the accessory
outlet. Some vehicles require the ignition switch to
be turned on.
4. Plug the USB-powered device into one of the USB
Charging Ports and operate normally.
Notes:
This unit' s USB Charging Ports do not support data
communication. They only provide 5 volts DC/2A power (as
indicated) to an external USB-powered device.
Remember to disconnect the charger from any power source
when not in use.
a
make sure the
