Fostoria E3915-60P User Instructions

1. Always unplug your portable electric heater before cleaning or disassembling.
2. Do not bend or damage heating elements when cleaning. Any bending or breaking will cause
your heater to be inoperable.
3. For the most part, your heater requires dusting. Always use a clean, dry cloth for dusting or a
crevice tool on your vacuum cleaner to remove built-up dust and lint. DO NOT USE WATER.
4. Any other servicing should be performed by an authorized service representative.
5. When heater is not in use disconnect and roll up cord.
6. When heater is not in use for extended periods, clean as directed above and store in original carton to
prevent possible damage.
7. NOTE: Altering this heater in any way will void your warranty.
IMPORTANT NOTE:
The pilot light is an indicator that the heating elements are energized or can be energized regardless of the
thermostat setting.

OPERATION:

Make sure the switch is in the off position and the thermostat is in the low position before plugging into the
receptacle. After energizing the heater, turn the thermostat knob fully clockwise to allow the desired area to
reach a comfortable temperature. When the area reaches the desired level of comfort, turn the thermostat
knob counterclockwise until the heater de-energizes. The thermostat will cycle the heater on and off to main-
tain the current setting. To turn the heater off, turn the power switch to the off position.
For heaters rated for use on 120 volts, if the cord has a plug as shown at "A" below, an adapter as shown at
"C" is available for connecting three-blade grounding-type plugs to two slot receptacles. The green ground-
ing lug extending from the adapter must be connected to a permanent ground such as a properly grounded
outlet box. The adapter should not be used if a three-slot grounded receptacle is available.
For heaters rated for use on 240 or 208 volts, the cord has one of the plug caps as shown in "D" below. No
adapter is available for these blade configurations, and none should be used. The type outlet is a 240 or 208
volt grounding outlet. When properly installed, it provides a ground connection through the cord to the heater
to protect the operator from electrical shock.
USER INSTRUCTIONS
FORM:8402
ECO 1-6870
11/13
