Summary of Contents for Clockaudio ARM 102-C MK2
- Page 1 Clockaudio ARM 100 / 102 / -C MK2 Instructions www.clockaudio.com email: info@clockaudio.co.uk Clockaudio Ltd, Wellington Gate, Silverthorne Way, Waterlooville, Hampshire, PO7 7XY, England...
-
Page 2: Table Of Contents
Thank you for purchasing a Clockaudio product. We are confident that this product will give you many years of trouble free operation. As part of Clockaudio’s continual ongoing programme of product development, improvements to the existing ARM microphone range including the ARM-C controller have been made to further increase the already excellent reliability. -
Page 3: Arm-C Control Unit Overview
1. ARM-C Control Unit Overview The ARM-C controller allows a DSP to instruct up to 4 ARM microphones to be raised or lowered. Up to four units can be daisy chained (using the Link to DSP input connection). Thus allowing a DSP using a single control line to raise/lower up to 16 ARM microphones. -
Page 4: Installation
2. Installation 1. Install the ARM motorised microphone as per separate instructions given with the product. 2. Ensure that the Control unit power supply is NOT switched on until all wiring and connections have been completed. 3. Connect the ARM motorised microphone(s) to any of the M1 – M4 motor outlet ports on the Control unit. -
Page 5: Connecting Multiple Arm-C Controllers
3. Connecting Multiple ARM-C Controllers Note: Connection / termination blocks for ARM-C PSU are not supplied. -
Page 6: Rear Panel
4. Rear Panel While the front of the unit provides DSP, Link, M1, M2 and power connections, the rear panel provides connection for M3 and M4. The four ARM microphones can be connected to any of the four connectors. 5. Pinouts for RJ12 DSP/Cable Off the shelf, readymade cables are freely available on the high street electrical retail outlets. -
Page 7: Troubleshooting Guide
6. Troubleshooting Guide Microphone does not move Check that the DSP control signal is present logic up or down +2.5 to 12 Volts is required. Is the microphone motor cable connected? Is the DC supply to the Controller unit switched on blue power light should be illuminating? ... -
Page 8: Specifications
7. Specifications 7.1. ARM 100 and ARM 102N ARM 100 ARM 102N Polar Pattern Omni-Directional Cardioid Capsule type Condenser Audio cable length 2m (6.6ft) Control cable length 2m (6.6ft) Integral, requires 9 – 48VDC Phantom power RF filters Included (eliminates GSM frequencies from 800 – 1200 MHz) Impedance 200 Ohms Frequency response... -
Page 9: Product Warranty
The warranty is subject to the following provisions: The warranty does not cover accidental damage, misuse, cabinet parts, knobs, batteries or consumable items. Any product returned to Clockaudio failing to meet the terms listed will incur a repair and postage charge. ... -
Page 10: Disposal Of Unit
9. Disposal of Unit At the end of the life of this equipment, dispose of equipment according to local regulations For more information and advice on Clockaudio products please look on Clockaudio website: www.clockaudio.com Clockaudio Limited, Clockaudio North America Inc.
