Green-Go GGO-WBP Quick Start Manual

Green-GO Wireless Quick Start Guide
g
Thank you for choosing the Green-GO Wireless Intercom system.
The Green-GO Wireless Intercom system consists of the following hardware:
- GGO-WBP: Wireless Belt-pack
- GGO-WAA: Active Antenna (Sold Separately)
What's in the box:
1 x Green-GO Wireless Unit
•
1 x Battery Pack
•
1 x USB Charge Cable
•
1 x USB Wall Outlet
•
1
2
3

Setting up the Green-GO Wireless Belt-pack

The battery should be charged and ready to go, however due to the time the unit may have
o
spent in storage, we recommend that you charge the battery for approximately 4 hours via the
included USB cable and USB Power Adapter
We advise use of a wall outlet to avoid power surge occurring from use with a USB port.
o
Once the battery is charged, take the battery off charge.
o
Insert the battery into the Green-GO wireless belt-pack unit by sliding it into the main section.
o
When doing so, ensure that the pack is inserted so that the screw hole of the battery pack
matches the screw hole of the main Green-GO unit. Push the battery fully into the slot, and
secure with the retainer screw. The battery can be charged inside the Green-GO belt-pack,
and does not need to be removed.
Connect your microphone headset to the unit, ensuring that you are using a headset with a 4-
o
Pin XLR Female Connection.
www.greengodigitial.com
2
1
3
RGB Display
Selection Button
Clickable Rotary Encoder
4
5
6
8
7
4 Battery Compartment
5 USB Charge Port
6 LED Indicator
7 Retaining Screw
8 Power On/Off Switch
9 4-Pin XLR Headset Socket
9
Version 2.2
