Page 1: Table Of Contents
Fan with Light, Night Light and Motion Sensor INSTALLATION GUIDE Table of Contents Warnings and Cautions Typical Installation New Construction Installation Easy installation in both Retrofit Installation Operation new construction and retrofit Cleaning and Maintenance Troubleshooting Service Parts © 2017 Broan... -
Page 2: Warnings And Cautions
Page 2 ZB80ML n ZB110ML Installation Guide WARNING CAUTION TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR . For general ventilating use only. Do not use to exhaust INJURY TO PERSONS, OBSERVE THE FOLLOWING: hazardous or explosive materials and vapors. -
Page 3: New Construction Installation
Page 3 ZB80ML n ZB110ML Installation Guide New Construction Installation Tools needed Materials needed • Power screwdriver with a Phillips bit • 6" round metal ducting recommended for best performance. Use of other ducting is acceptable but may impact performance. - Page 4 Screws from Parts Bag Attach Duct Connector and Ducting Top and bottom flanges Screw from go outside Housing Parts Bag Insert tab into slot inside Housing Tape Tape 6" Ducting Tape 4" Ducting 6" to 4" Reducer (for Model ZB80ML only)
- Page 5 Page 5 ZB80ML n ZB110ML Installation Guide New Construction Installation Connect Wires and Install Knockout Plate • Run 120VAC electrical wiring to the installation location. • Use proper UL-approved connectors to secure wiring to the Knockout Plate provided in Parts Bag.
- Page 6 Page 6 ZB80ML n ZB110ML Installation Guide New Construction Installation Insert Mask and Finish Ceiling • Install ceiling material. • Cut out around Housing. CAUTION IN ORDER TO PREVENT MOTOR/CONTROL DAMAGE: Mask protects unit If the blower was unplugged, power must during construction.
-
Page 7: Retrofit Installation
Page 7 ZB80ML n ZB110ML Installation Guide Retrofit Installation Tools needed Materials needed • Power screwdriver with a Phillips bit • Ruler • Tape to seal duct connections • Phillips screwdriver • Pencil • Existing rigid duct will require the addition of a short length of flexible duct •... - Page 8 Page 8 ZB80ML n ZB110ML Installation Guide Retrofit Installation Remove Blower Assembly Set aside Blower Assembly Both sides Remove Wiring Panel Set aside Wiring Panel Set aside screw Insert Mounting Frame Remove screws from Mounting Frame Bend up and set aside...
- Page 9 Housing as it is inserted into Mounting Frame Attach Ducting and Duct Connector Screw from Parts Bag Pull existing ductwork into Housing Insert tab into slot inside Housing Tape Tape 6" Ducting Tape 4" Ducting 6" to 4" Reducer (for Model ZB80ML only)
- Page 10 Page 10 ZB80ML n ZB110ML Installation Guide Retrofit Installation Install Knockout Plate, Connect Wires and Reinstall Wiring Panel • Use proper UL-approved connectors to secure wiring to the Knockout Plate provided in Parts Bag. • Connect wires as shown in wiring diagram.
- Page 11 Page 11 ZB80ML n ZB110ML Installation Guide Motion Controlled Light along with Fan LIGHT STANDARD OR MULTI-FUNCTION NIGHT WALL SWITCHES LIGHT NIGHT MASTER LIGHT 14/3 SENSOR/ CONTROL 120 VAC LINE IN Retrofit Installation Reinsert and Secure Blower Assembly CAUTION IN ORDER TO PREVENT MOTOR/CONTROL DAMAGE: Power must be disconnected (see page 2, WARNING item 2) before inserting motor plugs into control assembly.
-
Page 12: Operation
Page 12 ZB80ML n ZB110ML Installation Guide Install Bulbs Night Light (purchase separately) WARNING To Set the User-Adjustable Motion Light Timed-Off** Before servicing or cleaning unit, 1. This adjustment should only be made if, during installation, light switch power off at service panel and lock the service was wired to motion sensor along with the fan. -
Page 13: Cleaning And Maintenance
Page 13 ZB80ML n ZB110ML Installation Guide Cleaning and Maintenance Troubleshooting Before continuing, turn off power as previously noted in CAUTION WARNING on previous page and CAUTION section on this page. IN ORDER TO PREVENT MOTOR/CONTROL DAMAGE: DO NOT remove motor plug to stop spinning motor. -
Page 14: Service Parts
Motion Control Assembly 97020846 Control Assembly & Motor (ZB80ML) 97020845 Control Assembly & Motor (ZB110ML) 97018331 Duct Connector - 6" 99111513 6” to 4” Reducer (ZB80ML only) 99020301 Blower Wheel 97019371 Scroll Assembly (ZB80ML) 97018768 Scroll Assembly (ZB110ML) 97018776 Grille Assembly (includes 12, 13) 99140208 Grille Spring (2 req’d)
