M790 pH/ORP Controller Owner's Manual
b. The flow switch verifies that water is flowing during a feed
cycle, and sends the controller instructions to deactivate
the feed if water is not flowing.
c. Operation of this controller without a functioning flow-
switch will void the NSF Certification. Routinely check that
the flow-switch is functioning by closing the left valve on
the bottom of the flow-cell (flow light should turn off).
3. pH and ORP Sensors
a. pH Sensor – standard (Use only IPS Controllers part # SXPH
to maintain NSF Certification)
b. ORP Platinum Sensor – standard (Use only IPS Controllers
part # SXORP to maintain NSF Certification)
c. ORP Gold Sensor - for use with Salt Chlorine systems
(Use only IPS Controllers part # SXORP-G to maintain NSF
Certification)
4. Fittings – for tapping installation of flow cell input/output
5. In-line Filter – installed prior to flow cell to protect switch and
sensor
6. Tubing – 25 feet of 3/8" for providing filtered water to and from
the flow cell
7. Feeders – peristaltic pumps for acid for controlling pH, and
chlorine for controlling ORP (purchased separately)
8. Mounting Board – ABS plastic with mounting holes and stain-
less hardware (16" x 12" standard, 24" x 19" optional)
9. Check Valve/Injector – qty. 1 each (for use with optional pumps)
