High Rise™ Sit-Stand
Assembly Instructions for Model DC300
•
Please read all instructions before beginning assembly. We strongly recommend
you watch the video at www.victortech.com/High-Rise.
•
Remove all parts and hardware from box and lay out on a scratch-free work surface,
as this will avoid damaging any parts during assembly. The shipping box provides
an ideal work surface.
•
Do not dispose of any contents or packaging material until assembly is complete.
This will help to avoid accidentally discarding small parts or hardware.
•
For your safety and ease, adult assembly by two people is recommended.
•
Use the parts and hardware lists to identify and separate each of the pieces included
prior to starting assembly.
•
Do not use power tools. Use only the included Hex Key and Wrench. Power tools
can damage hardware and split wood.
Need Help? Watch the video at www.victortech.com/High-Rise
Desk Converter
PRE-ASSEMBLY
Patent
Pending
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DC300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Victor DC300

Summary of Contents for Victor DC300

  • Page 1 High Rise™ Sit-Stand Desk Converter Assembly Instructions for Model DC300 Patent Pending PRE-ASSEMBLY • Please read all instructions before beginning assembly. We strongly recommend you watch the video at www.victortech.com/High-Rise. • Remove all parts and hardware from box and lay out on a scratch-free work surface, as this will avoid damaging any parts during assembly.

  • Page 2: Parts List

    Parts List Tower Missing Parts? Call 1-800-628-2420 for Victor customer service. Monitor Bracket Stabilizers Desk Surface Steel Base Hardware Bag: Bolt 5 pcs Washer 2 pcs 2 pcs Monitor Screws 4 pcs Thumb Screw 1 pc Hex Key 1 pc...
  • Page 3 Step 1: Attach Tower to Steel Base The Tower will be packaged in a compressed position. Do not loosen the knobs until assembly is complete. This will make assembly easier. Use the Hex Key to attach the Tower to the Steel Base. Follow these steps: 1.
  • Page 4 Step 2: Attach Desk Surface to Tower 4 - 6 Attach the Desk Surface to the Tower. (Note: Long bolts, washers, and spacers will already be attached to the Desk Surface crossbar) 1. Place the Desk Surface on top of the Steel Base, as shown above. 2.
  • Page 5 Step 3: Attach Monitor Bracket to Monitor & Tower 1. The DC300 comes with a VERSA bracket designed to fit most monitors. Your monitor is compatible if there are four screw holes in the center of the back of the monitor.
  • Page 6 Use only when all fasteners are tight. At least every six months, tighten all fasteners. If parts are missing, broken, or worn, stop use of the product until repairs are made using Victor authorized parts. Need Help? Watch the video at www.victortech.com/High-Rise...
  • Page 7 Wrench. Step 6: Stabilize the Desk Surface (Optional) 1. Your DC300 Desk Converter is now fully operational. You may desire the desk surface to feel more secure when in the standing position. For this, two Stabilizers have been provided. To use them, first set the desk surface to the desired height.
  • Page 8 This will reduce the amount of strain on your body. Wear comfortable shoes. Get an Anti-Fatigue Mat: Standing on a hard surface could hurt your joints. We recommend standing on a soft surface. Victor Technology www.victortech.com Bolingbrook, IL USA 1-800-628-2420 Need Help? Watch the video at www.victortech.com/High-Rise...
