Summary of Contents for Gator GX5TRKT
- Page 1 PRODUCT USER MANUAL 5TRK T 5” MONITor car / Trailer Kit “ “ 5” 12/24V NTSC Wired Screen Size Voltage Surface/Suction Mounts IP67 3 Metre Coiled Parking IP67 Rating Panel Socket PAGE 1 GX5HDKT INSTRUCTION MANUAL Trailer Cord Guide Lines Mounts...
-
Page 2: Instruction Manual
INSTALLATION DIAGRAM 7 Pin Plug 7 Pin Flat Connection Colour Left Indicator Yellow Auxiliary or Reverse Light Black Socket View Plug View Earth White 7 Pin Round Right Indicator Green Electric Brakes Blue Stop Light Tail Lights Brown Socket View Plug View Extra for Flat 12 Pin Plug Connection... - Page 3 Trigger wire wiring Fig1 Bulb Bulb Positive when Positive when vehicle vehicle is in reverse is in reverse Multimeter shows a Multimeter shows a negative voltage Positive voltage 12.8V 12.8V DC V DC V 5 Pin Prolink panel mount sockets 10M Prolink II Extension Cable 4 Pin connectors...
- Page 4 INSTALLATION The video signal is transferred from the camera to the monitor via an RCA cable that will need to be run through the boot, through the passenger compartment to the monitors wired loom run under the dash. From there the power and video signals are sent directly to the monitor. At the rear of the car the camera is powered directly from the reversing tail light.
- Page 5 INSTALLATION You should also make sure the globe it self is not resting on something that could be harmed by extreme heat as the globe when on can get very hot). Turn the ignition back on again with the cars gear set to reverse (without the engine running). The globe should illuminate and the multimeter will show a positive voltage or a negative voltage across the globe.
-
Page 6: Product Features
INSTALLATION Testing the reverse camera function 1.Engage the park brake and turn the ignition key to the on position. DO NOT start the vehicle. 2. Select reverse gear with the gear shift. The monitor will sense the video signal from the camera automatically and will display the camera’s image of the rear of the vehicle. - Page 7 MENU FUNCTIONS Menu options and settings 1. Press the Menu button to access functions 2. Press the + or - button to confirm selection 3. Press the <CH> button to switch between AV1 & AV2 input (Priority if triggered) - Brightness: Adjusts screen brightness (0 - 40) - Contrast: Adjusts screen contrast (0 - 40) - Colour: Adjusts screen colour (0 - 40) - Zoom: Changes display mode between 4:3 &...
- Page 8 - Supply Power:DC12V +/- 10% - Dimensions: 85(H) x 140(W) x 15mm(D) TECHNICAL ASSISTANCE If you need assistance setting up or using your Gator product now or in the future, call Gator Support. Australia TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am –...
