Barco XHD-400 Quick Start Manual

Barco® Media Server XHD-Series
Quick-Start Guide
Part number: 60600318 Version: 03.00

Mechanical check

Confirm that there are no broken parts and that the
unit is free of dents or scratches. If you find broken
parts, dents, or scratches, notify your Barco sales
representative as soon as possible.

Hardware Start-up

1. Make the following connections to the rear panel
of the Barco Media Server.
a. Connect a monitor to the DVI port labelled
"Desktop." (DVI cable not included.)
b. Connect keyboard and mouse to USB 2.0 ports.
c. Optional—Connect the Ethernet cable from a
router to Ethernet Port #2.
d. Connect power cord.
2. Switch the master power switch on the rear panel
to ON.
The Barco Media Server box turns on immediately.

Output, Video Capture, and Genlock Connections

These connections vary, depending on model.
See Section 2.4.2, "Output, video capture, and
genlock connections" of the Barco Media Server
XHD-Series User Guide.

XHD-Series Barco Media Servers

All XHD-400/2/4 Series servers have the same
buttons, switches, LED indicators, and USB 3.0 ports
on the front panel.
Barco Technical Support:
USA:
+1 (866) 374-7878 /
China:
40088 22726
www.barco.com/support/eSupport.aspx

Software Start-up

Barco Media Server boxes come pre-installed with
Microsoft® Windows® Embedded 8.1 x64 and
X-Agora™. When the box is powered on, Windows
opens an empty desktop with two icons in the
left-hand corner of the taskbar.
• Double-click the X-Agora icon
(either on the taskbar or on the Desktop)
to open X-Agora.
• Right-click the Windows icon
to gain access to the following items:
o Control Panel
o File Explorer
o Run
o Shut down or sign out
o Desktop
• Select (left-click) the Windows icon, and select
the circled down-arrow on the Start screen, to
access all applications on the machine.

XHD-404 Front Panel

EMEA:
0800 90 0410
(on the taskbar)
