Royal Sovereign
Quick Step Up Guide for ARP-2412
Identification of parts
1. Display Panel
2. Air Outlet
3. Exhaust Hose Cover(N/A)
4. Exhaust Hose
5. Air Filters
6. Rear Casters
7. Front Casters
8. Water Tank
9. Water Tank Hanger
10. Nozzle
11. Drain
12. Power Cord
1) Extend Hose from Unit
2) Position Window plate with the
unfinished edge facing away from
the hose
3) Insert Screws (included) from
the unfinished edge into the hose
adapter
1986 - 2011
