Model ET1500CB
Reduce risk of fire or electrical shock. Do not
expose this product to rain or moisture.
Introduction:
The Environmentally Hardened ET1500CB Transmitter is part of an overall system that utilize the existing cable
infrastructure. The ET1500CB Transmitter is designed for use with the ER1500CB or ER8500CB Receiver end units.
Please refer to the ER1500CB or ER8500CB manual for installation and operation related to those units.
The Transmitter works in conjunction with a multi-port receiver and requires very little installation time and no set up or
configuration. These units quickly turn ordinary 75 ohm coax cable into a high speed network communication for
distances up to 500 meters or 1640 feet. The ET1500CB is transparent to the network thus requiring no IP and MAC
addressing. Simply connect your network devices to the networking ports of the transmitter and receiver along with
existing cabling and the system begins communicating. LED indicators show the status of network communication.
Et1500Cb Transmitter Installation Recommendations:
The ET1500CB is designed for use with 75 ohm copper based coaxial cable. The quality of which must be consistent
with any reasonably serviceable cable condition. That is free from damage as in cuts, breaks, or cracks to the outer cov-
ering and insulated shielding which may compromise the signal conductivity of the cable.
The ET1500CB is designed to transmit and receive up to 100Mbps of Ethernet TCP/IP data at a maximum distance of
500m / 1,640ft. Before considering this solution be sure that the cables involved do not exceed the recommended maxi-
mum lengths. If the cable distance value is undetermined at the time of installation, we recommend the use of a Time
Domain Reflectometer (TDR) which through the use of short rise time pulses can measure impedance characteristics,
splices, and unknown cable distance estimates.
NITEK
681200132
Note: This installation should be made by a
qualified service person and conform with local
codes.
5410 Newport Drive, # 24
Rolling Meadows, IL 60008
Phone: (847) 259-8900
Fax: (847) 259-1300
E-mail: info@nitek.net
®
WWW.NITEK.NET
Installation and
Operation Manual
Patent Pending USA and Europe
Euro Pat App 2779641
RoHS
IEC/UL 60950-1
COMPLIANT
2002/95/EC
De Aar 99
8253 PN Dronten
The Netherlands
Tel: +31(0) 321 310 043
E-mail: info@nitekeurope.net
WWW.NITEK.NET
03242014
Advertisement
Table of Contents
Related Manuals for Nitek ET1500CB
Summary of Contents for Nitek ET1500CB
- Page 1 These units quickly turn ordinary 75 ohm coax cable into a high speed network communication for distances up to 500 meters or 1640 feet. The ET1500CB is transparent to the network thus requiring no IP and MAC addressing. Simply connect your network devices to the networking ports of the transmitter and receiver along with existing cabling and the system begins communicating.
- Page 2 ET1500CB Transmitter Installation: Refer to the diagrams below when installing. Use best industry practices and follow all local building codes. 1) At the camera location, securely mount the Transmitter unit and accessories. 2) The Transmitter must be connected to an external power source in order to function, with a DC voltage range of 9 to 56 volts and capable of providing 400mA.
