Nitek FTS324104R00 Installation Manual

Installation Manual
FTS324104R00 Dual Transmitter
2 Camera Transmitter w/Data and Aux Comm.
Note: This installation should be made by a qualified
service person and conform with local codes.
Reduce risk of fire or electrical shock do
!
not expose this product to rain or moisture.

Specifications

Video Connection
Connector
Input Impedance
Input Level
Frequency Response
Optical Connection
Connector
Path Loss
Wavelength
Dimensions
Width
Power Connection
Provided from FSR1000 Card Rack
Auxiliary Ports
Data Selectable
Alarm In
Alarm Out Relay

Installation Instructions

- The fiber transmitter is designed to be mounted in the FSR1000 Fiber Card Rack.
- Always allow for bend radius of optical and electrical cables when installed.

Power/Video/Opto LED

Color Description
Green System Normal
Yellow (RX) Link working, No video at TX
Red (TX) Power on, No video into TX
(RX) Power on, No opto into RX

Data LED

Color Description
Green Data is Low / Logic 0
Red Data is High / Logic 1 (RS422/485)
Off Data is Tri-state / (High - RS232)

Service Information

There are no user serviceable parts inside the unit. In the event that service is required to this unit please
contact NITEK Technical Support at 800-528-4343.
75 ohm BNC Socket
75 ohm terminated
1 volt p-p nominal
10Hz to 10MHz
SC Style
20 dB
1310 / 1550nm
1 Card slot
RS422/RS485/RS232
Contact Closure
100V / 150mA max

Rear Panel Data Connections

Data
IN + (A)
IN - (B)
OUT + (A)
OUT - (B)
GND

Set Data Format with Internal Switch

NITEK
CH1 CH2
POWER
VIDEO/OPTO
DATA OUT
DATA IN
ALARM OUT
ALARM IN
OPTO IN / OUT
CH1
CH2
RS485 RS422
7 1
8 2
7 7
8 8
6 6
RS485
RS422
Data CH1
RS232
NITEK
®
