Smart Start GS-2260TW User Manual

Two-way 6-button lcd automatic/manual transmission

Advertisement

T W O - W A Y
6 - B U T T O N
L C D
A U T O M A T I C / M A N U A L
T R A N S M I S S I O N
R E M O T E
S T A R T E R
User Guide
It is the responsibility of the vehicle operator to ensure their vehicle is
parked in a safe and responsible manner.
1. a) Manual transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in the NEUTRAL position
and the parking brake is engaged in order to avoid accidents upon remote
starting.
b) Automatic transmission: When leaving the vehicle, it is the user's
responsibility to ensure that the gearshift lever is in "Park" in order to avoid
accidents upon remote starting.
(Note: Make sure that the automatic vehicle cannot start in "Drive".)
2. It is the user's responsibility to ensure that the remote starter is disabled or
put into valet mode before servicing.
A note concerning the battery inside the transmitter:
Depending on your usage of the transmitter, the battery can last anywhere between 3 to 6 months. When the
battery is low, the transmitter will produce two beeps in a repetitive cycle. At that point you should replace
your battery with a new one. That is why we recommend that you keep a spare battery somewhere handy such
as the glove compartment.
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this
device must accept any interference, including interference that may cause undesired operation of the
device.
To reduce potential radio interference to other users, the antenna type and its gain should be so chosen
that the equivalent isotropically radiated power (EIRP) is not more than that required for successful
communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by unauthorized
modifications to this equipment. Such modifications could void the user's authority to operate the
equipment.
D1148
2016-04-01
W W ARNING!
-LR-
Canada

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GS-2260TW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Smart Start GS-2260TW

  • Page 1 T W O - W A Y 6 - B U T T O N L C D A U T O M A T I C / M A N U A L T R A N S M I S S I O N R E M O T E S T A R T E R User Guide...
  • Page 2: Table Of Contents

    TABLE OF CONTENT INTRODUCTION ........................3 VEHICLE PRESETS .......................... 3 ............................3 EATER & R & H ................... 3 INDSHIELD IPERS ADIO EADLIGHTS USING THE REMOTE CONTROL ..................... 3 LCD R ........................ 3 EMOTE UNCTIONS ......................4 ASIC EHICLE PERATIONS ......................
  • Page 3: Introduction

    Introduction This is a state-of-the-art remote car starter system. The system is packed with advanced features such as priority access to the driver’s door (commodity features), the Safe Start children safety feature and SmartStart™. SmartStart™ is a groundbreaking technology that enables your remote starter features to be accessed by your smartphone.
  • Page 4: Basic Vehicle Operations

    The functions of the transmitter are as follows: Function Button: . Turns On the backlight Auxiliary Button: . For accessing Multi-level Activates functions Panic Mode LOCK Button: Locks all Doors and arms the Starter Kill UNLOCK Button: Unlocks all Doors and disarms the Starter Kill TRUNK Button: Activates the Trunk...
  • Page 5: Transmitter Mode Selection

    Transmitter Mode Selection Function Button pressed Icon sound Instructions /description Press and hold Vibration mode Vibrates 4x and then press Press once to have Alarm clock mode alarm clock on Melody on/off Press twice to have alarm clock off How to access remote’s function menus: User Transmitter appears on screen.
  • Page 6: Arming And Disarming The Starter Kill

    Once the Countdown is activated it will continue counting down until reaching 0:00. If the Timer has not reached 0:00 and you are starting the vehicle, you should reset your Countdown Timer to 0:00 before starting your vehicle as to avoid being startled. Arming and disarming the Starter Kill This added security feature will prevent the vehicle from starting with the Ignition key when the starter kill is armed.
  • Page 7: Remote-Starting Your Vehicle

    Remote-Starting Your Vehicle Setting Your Vehicle Into Ready Mode If your vehicle has a manual transmission you must read the following indications. The unit must first be set to Ready Mode in order to start the vehicle by remote. If the unit is not set to Ready Mode, it cannot remote start the vehicle.
  • Page 8: Driving Off

    Driving Off With the vehicle running under remote control, press the button to disarm the starter kill (if installed) and unlock the doors. Enter the vehicle and do the following: Turn the ignition key to the position. (Do not turn the key to the position IGNITION ON (RUN) CRANK...
  • Page 9: Valet Modes

    If your vehicle has a manual transmission, Idle Mode can be activated through the same routine as that used for Ready Mode (page-7); at the last step, press button to lock the doors, arm the system and leave the engine running. Note1: The engine will continue running until the user re-enters the vehicle or until the expiration of the engine run time.
  • Page 10: Panic Mode

    To take the system out of Valet Mode To take the system out of Valet mode using the KEY (Ignition Valet Mode): Insert the ignition key into the ignition switch. Within 10 sec., turn the key 5 times successively into the IGNITION/RUN and OFF positions. The parking lights will flash twice.
  • Page 11: Extended Run Time

    To exit Cold Weather Mode, do any one of the following actions: Open the hood. Start the engine by remote. Turn the ignition key to the IGNITION ON (RUN) position. Press the for 1 second and release. The remote will beep once and will appear on the display.
  • Page 12: Missing A Start Or A Stop Confirmation

    Missing a Start or a Stop Confirmation If you have not received a Start or the Stop confirmation after pressing the button, pressing the button will refresh the display and will confirm if the vehicle was started or stopped. If no Start Confirmation Was Received: Press the button: The remote’s...
  • Page 13: Safe Start

    Safe Start This feature will eliminate accidental remote starts, e.g. when children are playing with the transmitter. Safe start enabled: If this feature is enabled, the user must press the button twice within 3 seconds to remote-start the vehicle. Swap start: If this feature is enabled; Press the for 1 second and release.
  • Page 14: Home Valet Tm " Mode

    “Home Valet ” Mode If configured at installation, this feature will remotely set the vehicle to a no-remote-start mode: if the vehicle is parked indoors there is no danger of it starting accidentally by remote control. If the vehicle has a manual transmission, it should be set into ready mode before activating the Home Valet™. Note: Once the Home Valet Mode is activated, the vehicle will not start by remote, but the OEM alarm functions will remain active.
  • Page 15: Oem-Style Alarm

    Press : ..........LOCK Press ..........UNLOCK Press : ..............START Press ............. STOP Press ..........TRUNK Start/Stop While in Safe Start Mode Function Button press Icon Sound Description Press simultaneously twice within 3 Start on safe start seconds. Press for 1 sec- a Melody + x 2 mode...
  • Page 16: Multi-Level Features

    Multi-Level Features Basic Features (press the button 1X) Level 1 ............. Aux 2 ............. Cold Weather Mode Multi-Car Operation (press the button 2X) Level 2 ....... car lock ....... : 2nd car unlock ....... : car start/stop ....... car trunk Customized Features (press the button 3X) Level 3...
  • Page 17: Troubleshooting Poor Transmitting Range

    Option 1: Level 1 (requires pressing the button 1X) Multi car operation Level 2 (requires pressing the button 2X) Basic features Level 3 (requires pressing the button 3X) Customized features Option 2 (by default) Level 1 (requires pressing the button 1X) Basic features Level 2 (requires pressing the button 2X)
  • Page 18: Parking Light Flash Table

    Parking Light Flash Table Parking lights flashes Description Doors locked. Trunk released. Start signal received from the remote. Runtime has expired 2 slow Shutdown by remote Doors unlocked 2 fast Valet mode is deactivated 3 slow Runtime is extended. 3 fast Valet mode activated.
