**NOTE: This guide applies to radios purchased after 08/01/2017. Your
radio was pre-programmed and fully optimized before shipping to you.
Youʼre not required to use the guide. Go out and play!

Switching Modes: Memory/Manual

• The RM-45 can switch between Memory (MR) mode [pre-programmed
channels], or Manual (VFO) mode [manually entered frequencies] by
pressing the P1 button on the face of the radio.
• Pre-programmed channels are easily identified by a small channel
number and channel name (also known as an alpha tag).

Entering a Custom Frequency:

To perform this operation, you must first be in VFO Mode.
• Press P2 to set the desired MHz using the Channel Dial.

Scan Mode:

Scan Mode allows you to scan through all of the programmed channels
to look for radio traffic.
• Press P5 to enter scan mode.

Keypad Lock/Unlock:

• TO LOCK/UNLOCK: Press and hold the P5 button on the radio for two
seconds. A small
symbol will appear/disappear on the top right
corner of the display to confirm that the keypad is locked/unlocked.
Channel
Dial
Channel
Number
Rugged Radios
RM-45 45-WATT RADIO
USER GUIDE
Transmit
Function
VFO/MR
Light
Button
Button
Scan/Skip
Squelch Adjust
Indicator
Button
|
www.ruggedradios.com
Push-to-Talk
Button
MHz Shortcut
Power
Button
Button
Battery Voltage
Scan &
& Tone Code
Lock/Unlock
Volume
Dial
Microphone
Programming
Port
Port
|
888-541-7223
