- Page 1 Revision 1.0...
-
Page 2: Table Of Contents
Display ........................... 14 DC Power Connector ......................14 RF Out Port ........................14 Ethernet Port -> ......................... 14 USB Port ..........................14 2.2. Power Adaptor ..........................14 2.3. Battery ............................14 Installing a battery......................... 15 INNO Instrument Inc. Page 1 of 69... - Page 3 Freq/dist-Numeric ‘2’ ......................40 Autoscale-Numeric ‘3’ ......................42 Peak-Numeric ‘4’ ........................43 Trace-Numeric ‘5’ ........................43 Run/Hold-Numeric ‘6’ ......................45 Save-Numeric ‘7’ ........................45 Load-Numeric ‘8’ ........................46 Limit-Numeric ‘9’ ........................47 Preset-Numeric ‘’ ......................48 INNO Instrument Inc. Page 2 of 69...
- Page 4 Basic Specifications ....................... 60 V90 Basic Specifications (Option) ..................61 V95 Basic Specifications (Option) ..................61 5.10. Ordering Information ........................ 62 Supplied Accessories ......................62 Optional Accessories ......................63 arranty Information ......................64 ppendix ..........................67 INNO Instrument Inc. Page 3 of 69...
-
Page 5: Safety Instructions
Always wear a grounding wrist strap connected to the desktop anti-static mat via daisy-chained 1 MΩ resistor. Before operating, connect clamp on the body of the Analyzer to the body of the DUT. Observe all general safety precautions related to the equipment operation powered by mains. INNO Instrument Inc. Page 4 of 69... -
Page 6: Strorage
Refer to the user’s manual if the instrument is marked with this symbol Direct Current Alternating Current Power On Power Off A chassis terminal: a connection to the instrument’s chassis, which includes all exposed metal structure INNO Instrument Inc. Page 5 of 69... -
Page 7: Certification
View900 Cable Antenna Analyzer User Manual CERTIFICATION INNO Instrument Inc. Page 6 of 69... -
Page 8: General Information
View900 Cable Antenna Analyzer User Manual GENERAL INFORMATION INNO Instrument Inc. Page 7 of 69... -
Page 9: Descrption
Smart Battery management can be used to check Battery capability Field replaceable Lithium Ion battery with over 5.5 hours operation time Backlight keypad for easier use in low light environments INNO Instrument Inc. Page 8 of 69... -
Page 10: The Layout Of View900
View900 Cable Antenna Analyzer User Manual 1.2. THE LAYOUT OF View900 Front View Rear View Top View INNO Instrument Inc. Page 9 of 69... -
Page 11: Instrument Overview
View900 Cable Antenna Analyzer User Manual 2. INSTRUMENT OVERVIEW INNO Instrument Inc. Page 10 of 69... -
Page 12: Front Panel
The front view of View900 is represented in Figure 1.1. The front panel is equipped with the following parts: Key button Rotary knob Multi Function Button Navigation Button Power Button ESC Button Menu Button LED Indicator Green LED Operating Status Red LED Instrument is Charging INNO Instrument Inc. Page 11 of 69... -
Page 13: Power Key
Frequency / Distance setting Autoscale Change the Amplitude to fit to the measurement Peak Find a peak valule Trace Trace Menu Run/Hold Run or Hold sweep (toggle) Save Save Menu Load Load Menu Limit Limit Menu INNO Instrument Inc. Page 12 of 69... -
Page 14: Navigation Button
Green and Red LEDs are on the left of the front power key. The information displayed by each LED is as follows: Color Status Indication Green Power On, Booting Power Off Battery Charging INNO Instrument Inc. Page 13 of 69... -
Page 15: Display
Product Power Unit Model No. INNO-PU-8 AC Input 100-240 Va.c. 50-60Hz DC Output 12.0Vd.c. 3.0A Max Manufacturer INNO INSTRUMENT (CHINA) INC. 2.3. Battery View900 uses the following Battery Pack: Product BATTERY PACK Model No. LBT-230A Power Supply 7.4Vd.c. 7800MAh, 57.72Wh Manufacturer INNO INSTRUMENT (CHINA) INC. -
Page 16: Installing A Battery
3. Close the battery cap HARGING A ATTERY 1. Insert a battery 2. Provide AC-DC Adaptor 3. Press power button to turn on 4. Check if a battery icon is displayed on the screen INNO Instrument Inc. Page 15 of 69... -
Page 17: Low Bttery
En cas de fuite d'électrolyte de la batterie ou si la batterie dégage une odeur étrange, éloignez la batterie du feu. Au cas où une partie quelconque du corps humain touche l'électrolyte de la batterie, lavez-la immédiatement et rendez-vous à l'hôpital pour éviter des dommages potentiels. INNO Instrument Inc. Page 16 of 69... - Page 18 Évitez de placer la batterie à proximité de sources de chaleur ou de fenêtres. Si la batterie est inutilisée pendant une longue période, séparez-la de l'unité. Gardez cette batterie hors de portée des enfants. INNO Instrument Inc. Page 17 of 69...
-
Page 19: Menu Decriptions
View900 Cable Antenna Analyzer User Manual 3. M ECRIPTIONS INNO Instrument Inc. Page 18 of 69... -
Page 20: Menu Descriptions
Run a ‘Cable & Antenna Analyzer mode Run ‘Calibration.’ Select either Mechanical (OSL) Calibration or Electrical Calibration. Settings’ to configure measurement parameters ‘Power Measurement with an external power Sensor.’ ‘Files’ menu to view saved data ‘Information’ of the instrument INNO Instrument Inc. Page 19 of 69... -
Page 21: Cable And Antenna Analyzer Mode
View900 Cable Antenna Analyzer User Manual ABLE AND NTENNA NALYZER MODE Main Menu – CAA Select CAA to run VSWR/Return Loss/Cable Loss/DTF INNO Instrument Inc. Page 20 of 69... - Page 22 NDICATOR Displays Sweep and Calibration information Indicator - Calibration “On” or “Off” - Run or Hold sweep - single or continuous sweep - Data Point INNO Instrument Inc. Page 21 of 69...
-
Page 23: Calibration
View900 supports Open-Short-Load Mechanical Calibrator and Electrical Calibrator to minimize calibration time. View900 has two Calibration methods. 1. Select ‘Calibration’ in the Main Menu. 2. Select ‘Cal’ in the Measure Mode. Main MENU – Calibration Select Calibration from the Main Menu INNO Instrument Inc. Page 22 of 69... -
Page 24: Setting
View900 Cable Antenna Analyzer User Manual Select OSL Select E-Calibration ETTING Select Setting in the Main Menu to configure instrument setting. Main MENU – Setting Select Setting from the Main Menu INNO Instrument Inc. Page 23 of 69... - Page 25 You can change Time setting from Multi-function button ‘System > Display/Sound > Light.’ Setting – Setup Sleep Mode Time You can change Time setting from Multi-function button ‘System > Display/Sound > Sleep Mode.’ INNO Instrument Inc. Page 24 of 69...
- Page 26 You can change Time setting from Multi-function button ‘System > Advanced Setting > LAN.’ Setting – GPS GPS information (when GPS antenna connected) You can change Time setting from Multi-function button ‘System > Advanced Setting > GPS.’ INNO Instrument Inc. Page 25 of 69...
-
Page 27: Power Sensor
To perform RF power measurement, provide external power sensors. When you connect external power sensor to USB port, View900 automatically recognize. You can measure RF power after initialization. Main MENU – Power Sensor Select Power Sensor from the Main Menu Select Initialize INNO Instrument Inc. Page 26 of 69... -
Page 28: Files
Manage saved Trace file You can change Time setting from Multi-function button ‘Load > Load Trace.’ Files – Screen Manage the saved Screen You can change Time setting from Multi-function button ‘Load > Load Screen.’ INNO Instrument Inc. Page 27 of 69... - Page 29 View900 Cable Antenna Analyzer User Manual Files – Setup Manage the saved Setup You can change Time setting from Multi-function button ‘Load > Load Setup.’ INNO Instrument Inc. Page 28 of 69...
-
Page 30: Information
View900 Cable Antenna Analyzer User Manual NFORMATION Check the instrument information such as IP, Software, Hardware version, and information related to after- sales service. Main Menu – Information Select Information from the Main Menu INNO Instrument Inc. Page 29 of 69... -
Page 31: Css Measure Descriptions
View900 Cable Antenna Analyzer User Manual CSS MEASURE DESCRIPTIONS INNO Instrument Inc. Page 30 of 69... -
Page 32: Tap Menu
- Select DTF Return Loss to perform DTF measurement in Return Loss scale - Select Cable Loss to perform Cable Loss measurement. - Select Smith Chart to perform Smith Chart measurement - Select Single/Dual display mode to perform two measurements simultaneously INNO Instrument Inc. Page 31 of 69... -
Page 33: Freq
- Cable Loss Setting (DTF Mode) - Cable Velocity Setting (DTF Mode) - Window Filter Setting (DTF Mode) - Rectangular Window Setting (DTF Mode) - Blackman Window Setting (DTF Mode) - Hamming Window Setting (DTF Mode) INNO Instrument Inc. Page 32 of 69... -
Page 34: Amp
AMP is used to adjust the amplitude setting to fit the measurement trace into a screen. AMP Menu-Tree - Set the top line of amplitude - Set the bottom line of amplitude - Auto sets optimum values - Set Amplitude to the maximum range of each measurement mode INNO Instrument Inc. Page 33 of 69... -
Page 35: Sweep
- Display only Markers without Table - Disable all Markers and Tables - Marker Search menu - Marker Tracking “On” or “Off” - Move marker to Peak - Move Marker Valley Preset all markers INNO Instrument Inc. Page 34 of 69... -
Page 36: Multi-Function Button
4.2. Multi-Function Button You can conveniently select specific setting or function using multi-function button on the View900, ‘1’ UMERIC Performing Calibration: Calibration Procedure Multi-Key Function ‘Cal’ (Numeric ‘1’) Press OSL Calibration E-Calibration INNO Instrument Inc. Page 35 of 69... - Page 37 View900 Cable Antenna Analyzer User Manual INNO Instrument Inc. Page 36 of 69...
- Page 38 3) Short Cal Complete 3. Load Calibration Load cal start Load Cal Process Load Cal Complete When calibration done successfully, the screen automatically returns to the measurement screen. CAL “On.” Icon will be displayed. INNO Instrument Inc. Page 37 of 69...
- Page 39 Provide USB and connect V95 to RF port. Press Initialize button to Start calibration Calibration Press Start button to perform calibration, E-Calibration will be done automatically in the order of Open Short Load. INNO Instrument Inc. Page 38 of 69...
- Page 40 View900 Cable Antenna Analyzer User Manual When calibration done successfully, the screen automatically returns to the measurement screen. CAL “On.” Icon will be displayed. INNO Instrument Inc. Page 39 of 69...
-
Page 41: Freq/Dist-Numeric '2
You can also set the start/stop frequency from built-in list of standard wireless communication frequency. You can also register frequently used band into Favorite. Select a standard you want to register into Favorites and set ‘On’. INNO Instrument Inc. Page 40 of 69... - Page 42 For DTF measurement, you can set the distance (in meter or foot) for DTF VSWR and DTF Return Loss measurement. Use the Cable List saved in View9000 to select a cable to be measured. INNO Instrument Inc. Page 41 of 69...
-
Page 43: Autoscale-Numeric '3
View900 Cable Antenna Analyzer User Manual ‘3’ UTOSCALE UMERIC Autoscale fit the amplitude to the screen by adjusting Top & Bottom values automatically. Autoscale Press Autoscale to adjust top & bottom value of amplitude INNO Instrument Inc. Page 42 of 69... -
Page 44: Peak-Numeric '4
- Display the difference between the measured and saved Trace - Display the sum of the measured and saved Trace - Display the multiplication of the measured and saved Trace - Display the division the measured and saved Trace INNO Instrument Inc. Page 43 of 69... - Page 45 Calculate the sum of the measured and measured and saved Trace saved Trace Trace * Mem Trace/Mem Calculate the multiplication of the - Calculate the division the measured and saved measured and saved Trace Trace INNO Instrument Inc. Page 44 of 69...
-
Page 46: Run/Hold-Numeric '6
Save the current measured - Save current screen (*.png) - Set current setup (*.sta) Trace (*.tra) File Location can be selected using Save>Save to. Note - Default file name is ‘measurement mode_date (YYYYMMDD)’ INNO Instrument Inc. Page 45 of 69... -
Page 47: Load-Numeric '8
Loaded Trace will be displayed in parentheses. For example, M1 in the following figure is at 3178.13MHz, the current measured value is 0.00dB, and the Loaded Trace is 14.11dB. INNO Instrument Inc. Page 46 of 69... -
Page 48: Limit-Numeric '9
Set Start & Stop frequency & Limit Press OK Note - Upper: Fail if the measured value is higher than the Upper Limit Line - Lower: Fail if the measured value is lower than the Upper Limit Line INNO Instrument Inc. Page 47 of 69... -
Page 49: Preset-Numeric
- Select Cable Loss to perform Cable Loss measurement. - Select Smith Chart to perform Smith Chart measurement - Select Single/Dual display mode to perform two measurements simultaneously ‘+/-‘ YSTEM UMERIC System information SYSTEM Side Menu-Tree - System menu INNO Instrument Inc. Page 48 of 69... - Page 50 - Set LAN (IP, Gateway, Subnet Mask) - Confirm GPS Information (when connecting GPS antenna)- Optional - SW Upgrade Language - Current available language, English or Chinese Date/Time - Set Date & Time INNO Instrument Inc. Page 49 of 69...
- Page 51 View900 Cable Antenna Analyzer User Manual Display/Sound - Set Buzzer On or Off - Set Light - Set Keypad LED On (Off, 10sec, 20sec, 30sec) - Set Sleep Mode Light Sleep Mode INNO Instrument Inc. Page 50 of 69...
- Page 52 - After downloading newer version of SW, copy it to USB thumb drive, connect to View900 USB port - Connect USB to USB port and browse SW file from the File List - Upgrade and re-boot automatically - Check the SW version to make sure the latest version upgraded INNO Instrument Inc. Page 51 of 69...
-
Page 53: Tap Menu Multi Function Button Descriptions
View900 Cable Antenna Analyzer User Manual & TAP MENU MULTI FUNCTION BUTTON DESCRIPTIONS INNO Instrument Inc. Page 52 of 69... -
Page 54: Vswr-Vswr Measurement
- Set Start & Stop Frequency - Set Sweep Data Points 3. Calibration - Perform OSL Calibration 4. Return-Loss Measurement - Connect DUT (Device under test) to RF Out port and read the result INNO Instrument Inc. Page 53 of 69... -
Page 55: Dtf-Vswr Measurement
- Perform OSL Calibration 4. Cable - Browse cable list and select the cable to be measurement 5. DTF-VSWR Result - Connect DUT (Device under test) to RF Out port and read the result INNO Instrument Inc. Page 54 of 69... -
Page 56: Dtf Return-Loss Measurement
- Perform OSL Calibration 4. Cable - Browse cable list and select the cable to be measurement 5. DTF Return-Loss Result - Connect DUT (Device under test) to RF Out port and read the result INNO Instrument Inc. Page 55 of 69... -
Page 57: Cable-Loss Measurement
- Set Start & Stop Frequency - Set Sweep Data Points 3. Conduct Calibration - Perform OSL Calibration. 4. Cable-Loss Measurement - Connect DUT (Device under test) to RF Out port and read the result INNO Instrument Inc. Page 56 of 69... -
Page 58: Smith Chart Measurement
- Set Start & Stop Frequency - Set Sweep Data Points 3. Calibration - Perform OSL Calibration 4. Smith Chart Result - Connect DUT (Device under test) to RF Out port and read the result INNO Instrument Inc. Page 57 of 69... -
Page 59: Single/Dual Display
- Set the frequency of Power Sensor by using Menu>Frequency (it is very important to set frequency correctly to read out correct power) - Connect DUT (Device under test) to power sensor and read the result INNO Instrument Inc. Page 58 of 69... - Page 60 Power Sensor Menu-Tree - RF Power measurement - Initialize the Power Sensor - Set the frequency - Set additional loss include external offset - Save the measurement screen - Load the saved screen INNO Instrument Inc. Page 59 of 69...
-
Page 61: Specifications
7.4 Vd.c., 7800 mAh Environmental Operating Temperature -10 °C ~ +50 °C Storage Temperature -40 °C ~ +80 °C (-40 °F ~ +176 °F) Humidity 95 % R.H. Non Condensation Degree of protection IPX0 INNO Instrument Inc. Page 60 of 69... -
Page 62: V90 Basic Specifications (Option)
5 MHz to 6 GHz DC Voltage With USB Cable (Option) 5 Vdc/480 mA Power Consumption 0.3W (5 Vdc 60 mA) Dimensions (LxWxH) 113x38x27 mm Weight Less than 162 g Operating Temperature 0 °C ~ +50 °C INNO Instrument Inc. Page 61 of 69... -
Page 63: Ordering Information
Rechargeable lithium ion battery TM00900400 AC/DC adapter TM00900500 UPPLIED CCESSORIES The standard accessories supplied with the View900 are as follows: - Soft-carrying case - AC/DC adapter - Rechargeable Li-Ion battery - 8 GB USB memory INNO Instrument Inc. Page 62 of 69... -
Page 64: Optional Accessories
Accuracy: ±7% Test Port: Precision N Female V95 Electrical Frequency Range: 5MHz to 6GHz Calibration Kit DC Voltage: 5Vd.c/500 mA Max input Power: +20 dBm V96 Mechanical Frequency Range: 5MHz to 6GHz Calibration Kit INNO Instrument Inc. Page 63 of 69... -
Page 65: Warranty Information
View900 Cable Antenna Analyzer User Manual WARRANTY INFORMATION Certificate of Warranty INNO Instrument Inc. Page 64 of 69... - Page 66 Warranty Policy We, INNO Instrument Inc., do hereby warrant our CAA products, be free from defects due to defective materials or workmanship for a period of 3 years from the date of shipment. With free of charge calibration can be done in headquarter, Korea for a period of 2 years.
- Page 67 MERCHANTABILITY or fitness for a particular purpose is EXCLUDED from this transaction and shall not apply. The purchaser agrees that his sole and exclusive remedy against INNO Instrument Inc. shall be for the repair or replacement of defective parts as provided hereinabove. The purchaser agrees that NO OTHER REMEDY (including, but not limited to, incidental or consequential damages for lost profits, lost sales, injury to person or property, or any other incidental or consequential loss) shall be available to him.
-
Page 68: Appendix
View900 Cable Antenna Analyzer User Manual APPENDIX INNO Instrument Inc. Page 67 of 69... - Page 69 0.443 RG17, 17A 0.659 0.18 RG174 0.66 0.984 RG178B 0.69 1.509 RG187, 188 0.69 1.017 RG213/U 0.66 0.292 RG214 0.659 0.292 RG223 0.659 0.165 RG55, 55A, 55B 0.659 0.541 RG58, 58B 0.659 1.574 INNO Instrument Inc. Page 68 of 69...
-
Page 70: Inno Instrument Inc
0.0294 HFC-42D (1_5/8") 0.87 0.0243 RFCX-12D (1/2") 0.88 0.088 RFCX-22D (7/8") 0.88 0.049 RFCX-33D (1_1/4") 0.88 0.038 RFCX-42D (1_5/8") 0.87 0.028 RFCL-22D (7/8") 0.88 0.044 RFCL-33D (1_1/4") 0.88 0.034 RFCL-42D (1_5/8") 0.87 0.0315 INNO Instrument Inc. Page 69 of 69... - Page 71 www.innoinstrument.com...
