GB Installation and operating instructions
White infra red movement detector:
Art. no. 42207
Many thanks for deciding to buy our movement detector.
Our timer clock is made out of sturdy and high value materials. The movement detector can only be
used in inside areas, such as hallways, stairs and the basement, for example. The movement detector
is equipped with a twilight sensor and a sound sensor. Brightness, sensitivity, switch on time, range
and sound sensitivity can be set.
Please read through the installation and operation instructions carefully and keep these in a
safe place for later reference.
We do not accept any liability for damage to persons or property caused by not following the
instructions, or improper use or for changes made to the product.
Packaging contents:

1 movement detector

Istallation and operating instructions
Technical data:
Connection
Switching capacity
Minimum load
Protection type
Sensor
Sensor range
Recording range
Installation height:
Surrounding
Response brightness
Switch on duration
Sound sensitivity
consumption
Fusing
Safey and warning notice:

Take the movement detector carefully out of the packaging.

Make sure, before using the movement detector that this has not been damaged during
transportation.

Keep the packaging material well away from children and household pets. Danger of
suffocation!

Use is strictly forbidden if there is damage to the movement detector. Never make your own
repairs to faulty parts. Repairs must be done by trained electrical specialists.

Do not install the movement detector in the immediate vicinity of heat sources.

The entire product must not be changed or modified. Changes made lead to invalidation of the
guarantee (warranty).
Care and maintenance:

Use a dry, or slightly damp cloth for cleaning the sensor.

Never use chemicals, inflammable cleaners or abrasives. These can damage the surface
coating and/or the insulations.
Disposal:

Used electronic devices must be brought back to public collection points and must not be
disposed of as household waste.
Installation instructions Art. No. 42207
220 -240V, 50 Hz
up to a max. 500W (filament bulbs, halogen lamps)
>40W
IP 20
Infra red detector
4-9m (settable)
140°
1 – 1.8m
-20°C - +40°C
Settable between darkness and daylight (approx. 3 – 2000 Lux)
approx. Settable from 10 seconds up to a max. of 7 minutes
approx. 30db – 90 db
0.1W stand by, 0.45W during switching
2.5A, 250V
