ASCOM 9d24 Mkll Quick Reference Manual page 2

Use the Central phonebook
Enter "Contacts", step to "Central phonebook" and press
"Find". Enter the first letter(s) in the first name, a space and
the first letter(s) in the family name. Press "Ok". The Central
phonebook will be searched and a list of matching names will
be displayed. You can step to the next entry in alphabetic
order by pressing the Navigation key. Press "Select" or Call
key to make the call.
Soft keys and Hot keys
The three Soft keys below the display can be defined for
specific functions such as dialing a specific number etc.
A Hot key can have the same function as a Soft key and any
key "0" - "9" can be programmed as a Hot key.
For more information about Soft keys and Hot keys; see User
Manual, 9d24 Mkll Cordless Telephone.
Turn the automatic keypad lock on/off
Enter "Settings", step to "General" and press ( ). Select
"Auto key lock, press "Change"; the Auto lock checkbox is
marked/unmarked. A locked keypad is indicated by the
"Locked keypad" icon.
Switch the telephone off/on
Off: Enter "Modes". Step to "Switch off" and press "Select".
Step to ( ) "Yes" and press "Ok".
On: Press and hold the Call key; the question "Switch on?"
will be displayed. Press "Yes" within 10 seconds.
Alarm functions
Personal alarm*
Press the red Alarm button twice within 2 seconds. "Personal
alarm" is displayed.
Test alarm*
Press and hold the red Alarm button until "Test alarm" is
displayed.
*Dependent of installation
Deactivate/Activate Alarms
Enter "Settings", step to "Alarm settings" and press ( ).
Select "No-movement", "Man-down", or "Pull-cord", press
"Change"; the checkbox is unmarked/marked.
Hot keys/Soft keys can also be reserved for deactivation/
activation of alarms.
Safety instructions
This product shall only be used with the following batteries:
P/N:660087 Battery
P/N:660088 Battery Medic
Desktop chargers shall only be connected with power
adapters supplied by the manufacturer.
Available power adapters are:
P/N: FW7650/05 Power supply univ. AC/5V DC/1
Regulatory compliance statements
Compliance statement for USA:
This product complies with part 15 of the FCC Rules
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation of
the device.
Any modifications made to this device that is not approved by
the supplier may void the authority granted to the user by
FCC to operate the equipment.
Compliance statement for Canada:
This Class B digital apparatus complies with Canadian ICES-
003
Cet appareil numérique de la Classe B conforme á la
norme NMB-003 du Canada
This device is certified to the requirements of RSS-2I0 for 2.4
GHz spread spectrum devices. The use of this device in a
system operating outdoors may require the user to obtain a
licence for the system.
PRELIMINARY
FCC 15.105 Information to the user of a Class B device:
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for
help.
Privacy of communications may not be ensured when using
this phone.
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This device
complies with FCC SAR limit of 1.6 W/kg. The maximum SAR
value measured when used at the ear is 0.0081 W/kg. The
telephone has also been tested when worn on the body using
the belt clip, maximum measured SAR value in this
configuration is 0.0255 W/Kg. This device must not be co-
located or operating in conjunction with any other antenna or
transmitter.
Accessories
The following accessories for the 9d24 Mkll are available:
Belt clip, swivel type
Leather casing incl. belt clip
Standard clip Desktop charger
Headset with hearing protection Headset with microphone on boom
Also avilable:
• Security string
• Headset with microphone integrated in cable
• Adapter for standard Peltor headset
• Charging Rack
Distributed by:
Manufactured by:
Ascom Tateco AB, Sweden
Quick Reference Guide
Ascom 9d24 Mkll
Cordless Telephone
USA
