Yealink SIP-T46G Quick Installation Manual

For a SIP-T42G/T41P IP phone:
46mm
73.5mm
102.5mm
You can also download the wall mount drilling template
online: http://www.yealink.com/Support.aspx.
Following the drilling template above, you can mount
the IP phone to the wall, as shown below
(Take a SIP-T46G IP phone as an example):
c
Copyright 2013 YEALINK NETWORK TECHNOLOGY CO.,LTD.
Screw position
x 3
Min:6.5mm
Max:4.5mm
(0.256")
(0.177")
Min:6.5mm
(0.256")
Wall Mount Quick Installation Guide
This quick installation guide provides step-by-step
instructions for mounting your IP phone to a wall.
Wall mount is avaliable for the following IP phones:
SIP-T46G IP Phone
SIP-T42G IP Phone
SIP-T41P IP Phone
The wall mount bracket is required for wall mount
installation, which is not included with your IP phone,
contact your reseller to purchase it separately.
Packaging Contents
The following items are included in your package. If you
find anything missing, contact your system administrator.
(Purchase the proper package according to the IP phone
model you own.)
Avaliable for a SIP-T46G IP phone:
Wall Mount Bracket
for SIP-T4x IP Phones
Quick Installation Guide
www.yealink.com
