- Page 1 Dell Rugged Extreme 12-7204 Setup And Features Information Regulatory Model: P18T Regulatory Type:P18T001 RFID Model: DWRFID1302...
- Page 2 CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem. WARNING: A WARNING indicates a potential for property damage, personal injury, or death. © 2013 Dell Inc. All Rights Reserved. Trademarks used in this text: Dell , the Dell logo, Dell Boomi...
-
Page 3: Table Of Contents
Closing The Press-Latch doors ......................11 Opening The Slide-Latch doors ......................11 Closing The Slide-Latch doors 4 Smart Cards......................13 5 Specifications......................15 ................19 Information para NOM (únicamente para México) 6 Finding More Information and Resources............21 7 Contacting Dell....................... 23... -
Page 5: Front And Back View
Front and Back View Figure 1. Front view Display latch microphones Privacy shutter Camera (optional) Camera Status Light Ambient light sensor Screen-rotate button Volume button Status lights Rotatable outdoor readable display/ touchscreen (optional) Flip-hinge Secure card reader Optional USB 3.0 connector and memory- Hard disk card reader/PC-card reader/Express-card reader... - Page 6 WARNING: Do not block, push objects into, or allow dust to accumulate in the air vents. Do not store your Dell computer in a low-airflow environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or cause a fire. The computer turns on the fan when the computer gets hot.
-
Page 7: Quick Setup
Quick Setup WARNING: Before you begin any of the procedures in this section, read the safety information that shipped with your computer. For additional best practices information, see www.dell.com/ regulatory_compliance WARNING: The AC adapter works with electrical outlets worldwide. However, power connectors and power strips vary among countries. - Page 8 Connect IEEE 1394 devices, such as a 1394 hard drive (optional). Figure 6. 1394 Connector Open the computer display and press the power button to turn on the computer. Figure 7. Power Button NOTE: It is recommended that you turn on and shut down your computer at least once before you install any cards or connect the computer to a docking device or other external device, such as a printer.
-
Page 9: Removing And Installing Components
Removing and Installing Components This section provides detailed information on how to remove or install the components from your computer. -
Page 10: Removing The Battery
WARNING: Using an incompatible battery may increase the risk of fire or explosion. Replace the battery only with a compatible battery purchased from Dell. The battery is designed to work with your Dell computer. Do not use a battery from other computers with your computer. -
Page 11: Installing The Hard Drive
Installing the Hard Drive Push the hard drive into its compartment until its snaps in place. Close the hard-drive latch door . Opening The Press-Latch doors There are three press-latch doors. Two on the back and one on the right side panel. Follow the steps below to open the press-latch doors : a) Push the slide-lock to the right (the latch is locked when slid to the left). -
Page 13: Smart Cards
Smart Cards There are two main types of Smart or Common Access Cards (CAC): Enclosed Smart Cards — These cards have a contact area with many gold plated connection pads. When inserted into a card reader, the information from the chip can be read and written The Smart Card can be fully inserted, allowing the protective hinged door to be closed. -
Page 15: Specifications
Specifications NOTE: Offerings may vary by region. For more information regarding the configuration of your computer, click Start (Start icon) → Help and Support, and then select the option to view information about your computer. Table 1. System Information Feature Specification Chipset Intel Mobile Express Series 6 chipset... - Page 16 Feature Specification Stereo conversion 24-bit (analog-to-digital and digital-to-analog) Interface: Internal high definition audio External microphone-in/stereo headphones/external speakers connector Speakers Internal speaker amplifier 1W (RMS) Volume controls Volume Up/Volume Down buttons CAUTION: Adjustment of volume control, as well as the equalizer in the operating system and/or equalizer software, to other settings than the center position may increase the earphones and/or headphones output and cause hearing damage or loss.
- Page 17 Feature Specification Memory card reader one 8-in-1 memory card reader Serial one DB9 pin serial connector Docking port Subscriber Identity Module (SIM) port Table 8. Display Feature Specification Type white Light Emitting Diode (WLED) display Size 12.0 inches Dimensions: Height 158.5 mm (6.24 inches) Width 268.0 mm (10.59 inches)
- Page 18 Table 10. Touchpad Feature Specification Active Area: X-axis 91 mm (3.58 inches) Y-axis 51 mm (2.00 inches) Table 11. Battery Feature Specification Type 4-cell "smart" lithium ion Dimensions: Height 16.5 mm (0.65 inches) Width 215 mm (8.46 inches) Depth 72.6 mm (2.85 inches) Weight 318 g Voltage...
-
Page 19: Information Para Nom (Únicamente Para México)
Operating 0 °C to 40 °C (32 °F to 104 °F) Non-Operating –40 °C to 70 °C (–40 °F to 158 °F) Table 13. Auto-air Adapter Type 90 W Input voltage 11 VDC to 16 VDC Input current (maximum) 9.0 A Output power 90 W Output current... - Page 20 Voltaje de alimentación 100 VAC – 240 VAC Frecuencia 50 Hz – 60 Hz Consumo eléctrico 1.7 A Voltaje de salida 19,50 V de CC Intensidad de salida 3,34 A...
-
Page 21: Finding More Information And Resources
• Safety best practices • Regulatory certification • Ergonomics See www.dell.com for additional information on: • Warranty • Terms and Conditions (U.S. only) • End User License Agreement Additional information on your product is available at www.dell.com/support/manuals... -
Page 23: Contacting Dell
Dell product catalog. Dell provides several online and telephone-based support and service options. Availability varies by country and product, and some services may not be available in your area. To contact Dell for sales, technical support, or customer service issues: Visit dell.com/support...
