Description of symbols

Technical data

User Instruction - Pointoselect digital

General Information

Attention: Read Opertaion Instructions!
BF type application part.
Protection against electric shock.
The article or order number of the product follows this symbol.
The serial number of the product follows this symbol.
The year of construction of the product follows this symbol.
This equipment is marked with the recycling symbol. It means that at
the end of the life of the equipment you must dispose of it separately at
an appropriate collection point and not place it in the normal domestic
unsorted waste stream. This will benefit the environment for all.
Conform with Council Directive 93/42/EEC of 14 June 1993 concerning
medical devices.
Acupuncture point finder with automatic and manual location functions
and integrated stimulator.
Power supply:
Dimensions:
Weight:
Point finder
Current consumption:
Stimulator
Current consumption:
Output voltage:
Frequency range:
Pulse width:
9 V block battery
approx. 115 mm x 60 mm x 30 mm
approx. 123 g (without accessory)
approx. 17 mA (without signal tone)
approx. 30 mA (with signal tone)
approx. 28 mA
(under 20 kΩ load at 128 Hz and 120 µs)
200 V (under 20 kΩ load)
2-128 Hz
60-120 µs
