Summary of Contents for Pierenkemper Pointoselect Digital
-
Page 2: Table Of Contents
User Instruction - Pointoselect digital Content Intended use ......................3 Safe usage of the device ..................3 Description ......................4 Operating the device Setting up the device .....................4 Starting the device ....................4 Mode selection.......................5 Measurement ......................5 Automatic ....................5 Manual ......................6 Gold/silver detection ..................6 Stimulation ......................6... -
Page 3: Intended Use
Keep the Pointoselect digital away from water or other liquids. · Do not drop the Pointoselect digital. Do not handle it roughly or expose it to extreme temperatures or high humidity (only use at temperatures between 10 °C and 40 °C and at a relative humidity of less than 90 %). -
Page 4: Description
The hand probe and the hand electrode must be connected to the respective output sockets of the Pointoselect digital. Starting the device Start the Pointoselect digital by pressing the button. The display screen shown left appears. The most recently used settings are now loaded. -
Page 5: Mode Selection
User Instruction - Pointoselect digital After 2 minutes of no use (measurement or stimulation) the device switches off automatically. If the hand probe is not correctly connected to the Pointoselect digital, „no HS“ appears in the display (see illustration left). Mode selection... -
Page 6: Manual
On Ear-Gold modulation, only gold points will be detected and displayed. On Ear-Silver modulation, only silver points will be detected and displayed. Attention! On „Body“ modulation, only the inner sensor of the Pointoselect digital is operating. No Gold/Silver-detection is completed or displayed. Stimulation... -
Page 7: Adjusting The Intensity
User Instruction - Pointoselect digital Pressing the button again switches to the next stimulation setting (frequen- cy). Pressing the button once more switches to the next stimulation setting. Sequence: Intensity-frequency range-frequency pulse width Adjusting the intensity The intensity can be set to the desired value using the left buttons on the device console. -
Page 8: Adjusting The Volume Of The Signal Tone
User Instruction - Pointoselect digital Adjusting the volume of the signal tone To adjust the volume, press the button and the left button on the de- vice console when the device is starting up. The display screen shown left appears. -
Page 9: General Information
User Instruction - Pointoselect digital General Information Description of symbols Attention: Read Opertaion Instructions! BF type application part. Protection against electric shock. The article or order number of the product follows this symbol. The serial number of the product follows this symbol. -
Page 10: Classification
Maximum stimulation pulse under 20 kΩ load Electric current according to resistive load Classification The Pointoselect digital is rated as a class IIa medical device according to annex IX of EC directive 93/42/EEC concerning medical devices. Recalibration, changes and repairs... -
Page 11: Guarantee
No special care or cleaning agents are necessary for the Pointoselect digital. The Pointoselect digital and the hand probe should be cleaned with a soft, lint-free cloth. Alcohol (80 %) applied to a soft cloth can be used for cleaning purposes.
