- Page 1 SUN2000-(30KTL-A, 33KTL, 33KTL-E001, 40KTL) Quick Guide Issue: 09 Part Number: 31507079 Date: 2018-04-15 HUAWEI TECHNOLOGIES CO., LTD.
-
Page 2: System Installation
5. Use insulated tools when installing the device. For personal safety, wear insulation gloves and protective shoes. 6. Huawei shall not be liable for any consequence caused by violation of the storage, transportation, installation, and operation regulations specified in this document and the user manual. - Page 3 Installing an Inverter (Support-mounting Used as an Example) 1. Determine the hole positions on the support 2. Drill holes. (You are advised to apply anti-rust paint on the hole positions for protection.) based on rear panel dimensions. 3. Secure the rear panel. 4.
-
Page 4: Electrical Connection
If you connect a ground cable to the ground point on the chassis shell, you are recommended to use a four-core (L1, L2, L3, and N) outdoor copper-core cable for the SUN2000-33KTL/33KTL- E001. If you connect a ground cable to the ground point in the maintenance compartment, you are recommended to use a five-core (L1, L2, L3, N, and PE) outdoor copper-core cable. - Page 5 4. Remove an appropriate length of the jacket and insulation layer from the AC output cable using a wire stripper. a. SUN2000-33KTL/33KTL-E001 b. SUN2000-33KTL/33KTL-E001 (including (excluding the ground cable) the ground cable) Core wire...
- Page 6 8. Route the AC output power cable into the locking cap and the AC OUTPUT connector at the inverter bottom. 9. Connect the wires of the AC output cable for the SUN2000-33KTL/33KTL-E001 to L1, L2, L3, and N on the AC terminal block. Secure the screws using a 10 mm socket wrench. Connect the wires of the AC output cable for the SUN2000-30KTL-A/40KTL to L1, L2, and L3 on the AC terminal block.
-
Page 7: Installing Dc Input Power Cables
Installing DC Input Power Cables Optional DC input terminals Number of SUN2000 Inputs Connects to any one route Connects to routes 1 and 3 Connects to routes 1, 3, and 5 Connects to routes 1, 2, 3, and 5 NOTE Connects to routes 1, 2, 3, 4, and 5 Routes 1, 2, 3, 4, 5, and 6 are defined Connects to routes 1, 2, 3, 4, 5, and 6... - Page 8 Installing a DC input power cable (using metal cold forming contacts) Positive metal contact Positive connector H4TC0001 (Amphenol) Negative Negative metal contact connector Common PV cables with a Ensure that cables cannot Click cross-sectional area of 4 mm² be removed after crimped. are recommended.
-
Page 9: Selecting A Communication Mode
Supported Supported 1. Only one communications mode (with PLC) can be selected in application scenarios. SUN2000-33KTL/33KTL-E001 Supported Supported 2. If PLC is used, you do not have to (with PLC) connect any cable to the inverter, but have to connect AC power... - Page 10 4. Connect the input end to terminals 5 and 7 on the terminal block and connect the output end to terminals 6 and 8 on the terminal block. Tighten the terminals using an M3 flat-head screwdriver to a torque of 0.5 N· m. Connect the shield layer to the ground point and tighten the screw using an M4 Phillips torque screwdriver to a torque of 1.2 N·...
- Page 11 Method 2: Connecting to RJ45 ports You are recommended to use a shielded RJ45 connector and a CAT 5E outdoor shielded network cable with an outer diameter less than 9 mm and internal resistance not greater than 1.5 ohms/10 m. 1.
-
Page 12: Installation Verification
Installation Verification Yes □ No □ 1. The SUN2000 is installed correctly and securely. Yes □ No □ 2. All screws, especially the screws used for electrical connections, are tightened. Yes □ No □ 3. The DC SWITCH and downstream AC output circuit breaker are OFF. 4. - Page 13 2. Mobile phone operating system: Android 4.0 or later, and iOS 7.0 or later. When the iOS is used, the APP supports only Bluetooth connection. 3. Access the Huawei app store (http://appstore.huawei.com), Google Play (https://play.google.com), or App Store (iOS), search for SUN2000, and download the SUN2000 APP installation package.
- Page 14 Data cable connection Inverter USB data cable Mobile phone Select a Connect Switch between Login screen connection mode Bluetooth users Quick setting Function menu • The preset password for Common User, Advanced User, and Special User is 00000a. • Use the preset password upon initial login. To ensure account security, change the password immediately after login.
- Page 15 Appendix 1: Power Grid Standard Code Mapping Table (SUN2000- 33KTL/SUN2000-33KTL-E001) Power Grid Power Grid Description Description Standard Code Standard Code China low-voltage Germany low-voltage NB/T 32004 VDE-AR-N-4105 power grid power grid Netherlands low- Germany medium- EN50438-NL BDEW-MV voltage power grid...
- Page 16 Appendix 2: Power Grid Standard Code Mapping Table (SUN2000-30KTL-A /SUN2000-40KTL) Power Grid Power Grid Description Description Standard Code Standard Code China medium-voltage RD1699/661- Spain medium-voltage CHINA-MV480 MV480 power grid (RD1699/661) power grid (480 V) Germany medium-voltage Custom-MV480 BDEW-MV480 Reserved power grid (50Hz) G59-England- UK 480 V Medium-voltage...
- Page 17 Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang Shenzhen 518129 People's Republic of China www.huawei.com...
