Page 1: Quick Installation Guide
SUN2000-(33KTL, 40KTL) Quick Installation Guide Issue: 05 Part Number: 31507079 Date: 2015-11-21 HUAWEI TECHNOLOGIES CO., LTD. -
Page 2: System Installation
3. Install and use the device according to this document and the user manual. Otherwise, the device may be damaged. Use insulated tools when installing the device. Inverter Model SUN2000-33KTL SUN2000-40KTL Weight 50 kg Dimensions (H x W x D) - Page 3 Installing an Inverter (Support-mounting Used as an Example) 1. Determine the hole positions on the support 2. Drill holes. based on rear panel dimensions. Unit: mm 3. Secure the rear panel. 4. Mount the inverter on the rear panel. M12 (3 PCS) 45 N·...
-
Page 4: Electrical Connection
Installing AC Output Power Cables OT-M6 Cross-sectional Area of the Inverter Model Cable Type Cable (Recommended) SUN2000-33KTL 4-core outdoor cable (L1, L2, L3, N) 16 mm or 6 AWG SUN2000-40KTL 3-core outdoor cable (L1, L2, L3) NOTE The table lists only the recommended cable specifications. For more information about cable specifications, see the SUN2000-(33KTL, 40KTL) User Manual. - Page 5 SUN2000-33KTL b. SUN2000-40KTL NOTE The AC output power cable for the SUN2000-33KTL is a 4-core outdoor cable (L1, L2, L3, and N). The AC output power cable for the SUN2000-40KTL is a 3-core outdoor cable (L1, L2, and L3).
-
Page 6: Installing Dc Input Power Cables
9. Connect the wires of the AC output cable for the SUN2000-33KTL to L1, L2, L3, and N on the AC terminal block. The required torque is 4 N· m. Connect the wires of the AC output cable for the SUN2000-40KTL to L1, L2, and L3 on the AC terminal block. The required torque is 8 N· m. -
Page 7: Selecting A Communication Mode
Then, turn off the DC SWITCH, remove the positive and negative connectors, and rectify the connection. Selecting a Communication Mode Communication Mode Model Remarks RS485 SUN2000-33KTL 1. Only one communications mode can be Supported Supported (with PLC) selected in application scenarios. 2. If the PLC communications mode is selected,... - Page 8 Installing RS485 Communications Cables NOTICE 1. When routing communications cables, ensure that communications cables are separated from power cables and away from interfering source to prevent communication from being affected . 2. RS485 Communications cables can be connected to the terminal block or RJ45 ports. Connecting to the terminal block is recommended.
- Page 9 Method 2: Connecting to RJ45 Ports Recommended outdoor network cable: cable outer diameter < 9 mm; internal resistance ≤ 1.5 ohms/10 m. 1. Insert the wires of the network cable to the RJ45 connector in sequence. 2. Crimp the connectors using a crimping tool. Color Pin Definition White-orange...
-
Page 10: Installation Verification
Installation Verification Yes □ No □ 1. The SUN2000 is installed correctly and securely. 2. All screws, especially the screws used for electrical connections, are Yes □ No □ tightened. Yes □ No □ 3. All circuit breakers are switched to OFF. 4. - Page 11 Indicator Status Meaning Alarm/ Alarm state Blinking red slowly (on The inverter has generated a warning. Maintenance for 1s and then off for 4s) indicator Blinking red fast (on for The inverter has generated a minor 0.5s and then off for 0.5s) alarm.
- Page 12 NOTICE The initial password for Common User, Advanced User, and Special User is 000001 or 00000a. Use the initial password to log in to the inverter for the first time and change the password immediately to ensure account security. NOTE 1.
-
Page 13: Appendix 1: Power Grid Standard Code Mapping Table (Sun2000-33Ktl)
Appendix 1: Power Grid Standard Code Mapping Table (SUN2000-33KTL) Power Grid Country and Power Grid Country and Standard Code Condition Standard Code Condition China low-voltage Germany low-voltage NB/T 32004 VDE-AR-N-4105 power grid power grid Netherlands low- Germany medium- EN50438-NL BDEW-MV... -
Page 14: Appendix 2: Power Grid Standard Code Mapping Table (Sun2000-40Ktl)
Appendix 2: Power Grid Standard Code Mapping Table (SUN2000-40KTL) Power Grid Country and Power Grid Country and Condition Standard Code Condition Standard Code China medium- Philippines- Philippines medium- CHINA-MV480 voltage power grid MV480 voltage power grid EN50438-TR- Turkey medium- Germany medium-voltage BDEW-MV480 MV480 voltage power grid... - Page 15 Scan here for technical support (carrier): Huawei App Store Apple Store Google Play Scan here for more documents: Support WeChat You can also log in to Huawei technical support website: http://support.huawei.com Huawei Technologies Co., Ltd. Huawei Industrial Base, Bantian, Longgang Shenzhen 518129 People's Republic of China www.huawei.com...
