- Page 1 Operators Manual Heated Box Extractor BS300H READ OPERATORS MANUAL BEFORE OPERATING...
- Page 3 Record this Important Information Date of Purchase Purchased From Address City State Phone Contact Serial Number Emergency Contacts Medical Emergency Police Fire...
-
Page 5: Table Of Contents
T a b l e o f C o n t e n t s Introduction ........... 2 Unpacking . -
Page 6: Introduction
Be sure to fill out and return your warranty card. PARTS AND SERVICE Repairs, when needed, should be performed by your authorized Pioneer Eclipse dealer only. They maintain a complete inventory of original replacement parts and accessories. Call the distributor from whom you purchased your machine when you need parts or service. -
Page 7: Safe Operating Procedures
S a f e O p e r a t i n g P r o c e d u r e s IMPORTANT SAFETY INSTRUCTIONS This machine is suitable for commercial use in hotels, schools, hospitals, factories, shops, and offices other than normal residential housekeeping purposes. -
Page 8: Description
D e s c r i p t i o n BECOME FAMILIAR WITH YOUR NEW MACHINE A general description of your new BrightStar 300H machine with heater is shown in Figure 1. The BrightStar 300H Wiring Schematic is shown in Figure 2. 4-button switch plate operators handle recovery tank lid... -
Page 9: Machine Operation
MACHINE OPERATION 1. Inspect the machine, hoses, and cleaning tools for cleanliness and completeness. 2. Fill the solution tank with warm water. Using warm water may be a benefit in cleaning effectiveness, but do not use hot water above 130ºF (54ºC) in the tank. Add liquid cleaning solution with a pH value of between 6 and 9. -
Page 10: Ball Float Vacuum Shut-Off
BALL FLOAT VACUUM SHUT-OFF Prior to using the machine, always check that the float filter is clean and the ball can travel freely. When the recovery tank is full, the ball float will rise and will shut off the vacuum flow to prevent any more water from entering the tank. -
Page 11: Brightstar 300H Wiring Schematic (Figure 2)
BrightStar 300H Machine Figure 2... -
Page 12: Exploded View & Parts List
Exploded View - BS300H... - Page 13 BS300H - Parts List PART# DESCRIPTION PART# DESCRIPTION VT-5 RECOVERY TANK LOCKNUT, 10-32 908A LATCH CASTOR, 4" SCREW, 8-32 X 5/8 IN BRACKET, AXLE MOUNT LOCKNUT, 8-21 AXLE 903D DRAIN GATE, FEM THREADS 2003 WHEEL VACUUM INLET HOSE BARB, AXLE CAP 1-1/2 IN CIRCUIT BOARD, 2086...
-
Page 14: Machine Specifications
Wand - BS11 - Before Nov. 2003... - Page 15 Wand - BS11 - Before Nov. 2003 PART # DESCRIPTION Wand Body Grab Handle Assembly 204A Lock Nut Screw Filter Spray Tip, size 110015 FP202 1/4” Hose & Swage Assembly 700MAN* Manifold Valve Lever Valve Body Brass Elbow, 45 Degrees, 1/4”...
- Page 16 Wand - BS11 - After Nov. 2003...
- Page 17 Wand - BS11 - After Nov. 2003 PART # DESCRIPTION CSW-12HP-500 Wand, Complete Grab Handle Assembly 204A Lock Nut Screw Filter, spray tip Spray Tip, size # 110015 FP202 Hose, 1/4”, and swage assembly 700MAN-RD Manifold Valve, complete Elbow brass 45 Degrees Nipple, brass, 1/4 p.t.
-
Page 18: Preventive Maintenance
M a c h i n e S p e c i f i c a t i o n s POWER SOURCE: 110-120V 50/60 RUNNING AMPS: PUMP, VACUUM AND FAN - 15 AMPS HEATER - 16 AMPS WAND & SPRAY TIPS: S/S, 12 IN (30,5 CM), DOUBLE BEND 2 TIPS, SIZE #110015 HOSES:... - Page 19 THE OBLIGATION OF PIONEER ECLIPSE CORPORATION 1) The obligation of Pioneer Eclipse under this warranty is limited to repairing or replacing, at its option, any part which is proven to be defective in material or workmanship under normal use for the applicable period stated above.
- Page 20 P.O. Box 909 Sparta, NC 28675 1-800-367-3550; 1-336-372-8080 Fax: 1-336-372-2895 LT041100-C, 11/14/06...
