Summary of Contents for FLOJET Bottled Water Dispenser Plus
- Page 1 BOTTLED WATER DISPENSER DISPENSADOR DE AGUA EMBOTELLADA Line to Refrigerator Ice/Water Dispenser Bottled Water Pump Module Bottled Water Dispenser Dispensing System www.flojet.com Installation & Maintenance Instructions...
- Page 2 HOW THE SYSTEM WORKS The FLOJET Bottled Water Dispensing System was designed to pump purified water from a commercially available 5-gallon purified water bottle. The system will deliver the water under pressure to an individual drinking water faucet, the water inlet of a refrigerator for the icemaker and chilled drinking water tap, and to certain commercial coffee / tea brewers.
- Page 3 (1) year after purchase by the customer from ITT Flojet. During this one (1) year warranty period, ITT Flojet will, at its option and at no charge to the customer, repair or replace this product if found defective in material or workmanship, with a new or reconditioned product. But not to include costs of removal or installation.
- Page 4 If using the optional Flojet faucet, disconnect the tubing. Remove the faucet, immersing it in the water/bleach solution for ten minutes. Wash the faucet exterior with clean paper towel;...
- Page 5 PLUMBING INSTALLATION Select a cabinet large enough to accommodate the 5 gallon (19L) bottle and suction wand assembly. Place the Pump Module on the floor of the cabinet with on/off switch and suction tube facing out toward the cabinet doors. Position as close as possible to a grounded electrical outlet and place the five gallon bottle close to the Pump Module without kinking the suction hose.
- Page 6 PLUMBING There is 20 ft. (6.1 m) of 1/4 in. (6.35 mm) O.D. polyethylene tubing supplied with the FLOJET Bottled Water Dispensing System. Carefully measure the distance between the pump module outlet and the appliance water inlet or optional faucet, and cut the tubing clean and square to prevent fitting leaks. If the refrigerator and faucet are being connected, use 1/4 in.
- Page 7 TEMPERATURE WARNING For additional protection, thermal cut-off device which is activated at 158°F / 70°C. Under normal operation, it will take 45-50 minutes for the motor to reach 158°F / 70°C at open flow condition. Once the power is cut off to the unit, it takes 15-20 mintues to reset.
- Page 8 Dual Inlet Bottled Water System Installation and Maintenance Instruction Insert (To be released in near future) INVENTORY OF SYSTEM COMPONENTS A. Pump Module with On/Off Rocker Switch, 3.5 ft (1 m) cord. B. Suction Wand and Hose Assembly. C. 20 ft. (6.1 m) of 1/4 in. (6.35 mm) Discharge Tube. D.
