MAJORITY PARKSIDE GO Instruction Manual

MAJORITY PARKSIDE GO Instruction Manual

Digital pocket radio with sd card playback
Hide thumbs Also See for PARKSIDE GO:

Advertisement

MAJORITY
PARKSIDE GO
Digital Pocket Radio with SD Card Playback
PAGO-DAB-BLK
Instructions Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PARKSIDE GO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for MAJORITY PARKSIDE GO

  • Page 1 MAJORITY PARKSIDE GO Digital Pocket Radio with SD Card Playback PAGO-DAB-BLK Instructions Guide...
  • Page 2: Table Of Contents

    Contents What’s in the Box? Controls And Functions  Navigation Controls  Basic Operation  Instructions Guide  DAB/DAB+ Mode ������������������������������������������������������ DAB Functions ���������������������������������������������������������� DAB Settings ������������������������������������������������������������� FM Radio ������������������������������������������������������������������ FM Functions ������������������������������������������������������������ FM Settings �������������������������������������������������������������� Micro SD Card Playback ������������������������������������������� Radio Settings ����������������������������������������������������������...
  • Page 3: What's In The Box

    Box Contents What’s in the Box? Majority Parkside Go Pocket DAB/DAB+ Radio USB cable Earphones User Guide...
  • Page 4: Controls And Functions

    Controls And Functions Front View / Control Buttons SELECT PRESET Screen Select/Preset/Pause/Play button Fastforward/Next Rewind/Previous...
  • Page 5 Controls And Functions Side View / Control Buttons DC in 5V 10. Power (On/Off ) Mode/Key 11. Volume - Menu/Info 12. Earphone jack MicroSD Card slot Volume +...
  • Page 6: Navigation Controls

    Instructions Guide Navigation Controls ON/OFF button To turn your radio on, press the ON/OFF button. To turn your radio off, press and hold the ON/OFF button. Next/Previous buttons Use the Next and Previous buttons to navigate around the radio and browse through your selections and stations available.
  • Page 7: Basic Operation

    Instructions Guide Basic Operation Ensure that the radio has been charged and view the battery life on the display when you turn it on. If the battery icon shows all of the bars illuminated then the system is fully charged. To charge the device, use the USB cable provided and plug it into a computer or a plug (not supplied) that accepts USB connectors.
  • Page 8: Dab/Dab+ Mode

    Instructions Guide DAB/DAB+ Mode Press the ‘ON/OFF’ button ( ). On first use, DAB radio Ref.10 will automatically start scanning all stations and save them. To auto scan (if the unit has not automatically done so, or shows no signal), ensure that the radio is in DAB mode by ).
  • Page 9: Dab Functions

    Instructions Guide DAB Functions How to preset a radio station Up to 10 preset stations can be set. To store a station that you are currently playing: To make your first preset station, press and hold the ‘Select/Preset/Play/Pause’ button ( ) until “Preset Store Ref.2 <1: (Empty)”...
  • Page 10 Instructions Guide DAB Station Information When on a DAB station with signal, you are able to find out station information available. Press the ‘Menu/Info’ button ) repeatedly to show the programme information. Ref.7 Signal Strength Bar: Displays a signal bar with the strength of the current station PTY (Programme Type): Shows the type and description of the programme provided by the DAB station.
  • Page 11: Dab Settings

    Instructions Guide DAB Settings When on DAB mode, press and hold the ‘Menu/Info’ button ) to begin accessing DAB settings. Ref.7 Scroll through the ‘Previous’ and ‘Next’ buttons ( ) to Ref.3 browse through the following options. Press the ‘Select/ Preset/Play/Pause’...
  • Page 12: Fm Radio

    Instructions Guide FM Radio FM Scan Press the ‘Mode/Key’ button ( ) to switch to FM radio. Ref.6 The first time you do this, FM frequency “87.50MHz” will be displayed on the screen. To autoscan to the next available station, press and hold the ‘Next’...
  • Page 13: Fm Functions

    Instructions Guide FM Functions How to preset a radio station Up to 10 preset stations can be set. To store a station that you are currently playing: To make your first preset station, press and hold the ‘Select/Preset/Play/Pause’ button ( ) until “Preset Store Ref.2 <1: (Empty)”...
  • Page 14 Instructions Guide FM Station Information When on a FM station with signal, you are able to find out station information available. Press the ‘Menu/Info’ button ) repeatedly to show the programme information. Ref.7 Signal Strength Bar: Displays a signal bar with the strength of the current station PTY (Programme Type): Shows the type and description of the programme provided by the DAB station.
  • Page 15: Fm Settings

    Instructions Guide FM Settings When on FM mode, press and hold the ‘Menu/Info’ button ) to begin accessing FM settings. Ref.7 Scroll through the ‘Previous’ and ‘Next’ buttons ( ) to Ref.3 browse through the following options. Press the ‘Select/ Preset/Play/Pause’...
  • Page 16: Micro Sd Card Playback

    Instructions Guide Micro SD Card Playback Press the ‘Mode/Key’ button ( ) multiple times until Ref.6 “SD” is shown on the display to indicate MP3 SD card mode. Insert the micro SD card into the SD card reader slot ( Ref.8 on the right side of the radio.
  • Page 17: Radio Settings

    Instructions Guide Radio Settings When on either of the two modes, DAB or FM, access the radio settings by holding down the ‘Menu/Info’ button Ref.7 Scroll through using the ‘Next’ or ‘Previous’ buttons ( Ref.3 to the ‘Settings’ option. Select with the ‘Select/Preset/Play/ Pause’...
  • Page 18 Instructions Guide Set 12/24 hour: Decide between a 12 hour or 24 hour clock. Set Date format: Browse between a variety of date formats: DD-MM-YY and MM-DD-YY. Set Backlight Use the ‘Next’ and ‘Previous’ buttons ( ) to set how Ref.3 long you would like the radio’s backlight to display before going to a lower dimmer setting.
  • Page 19 Instructions Guide Factory Reset When you are on settings for the radio, select the option for Factory Reset. The radio will then display: “Factory Reset?” with the options of “Yes” or “No”. Use the ‘Next’ or ‘Previous’ buttons ) to scroll to your chosen option and click the Ref.3 ‘Select/Preset/Play/Pause’...
  • Page 20: Troubleshooting

    Troubleshooting Troubleshooting Malfunction Possible causes/measures Check that the radio is charging and use when fully charged. No power / function Ensure radio is switched on by holding down the ON/OFF button. Please use the earphones provided as these are your external aerial. These should help to pick up DAB/ DAB+, time and date etc.
  • Page 21: Specifications

    Specifications Specifications USB Charger Wire 5V 0.5A Lithium battery 3.7V/1000mAh DAB: Band III 5A-13F Frequency Range FM: 87.5MHz to 108 MHz Earphone output 2 mW (32Ω) power Warranty All products come with a standard 12 month warranty. All www.majorityradios.co.uk items must be registered on for the warranty to be valid.
  • Page 22: Safety Information

    Safety Information ADDITIONAL WARNINGS 1. Read these instructions. 2. Keep these instructions. Instructions are also The apparatus shall not be exposed to dripping or available for download at www.majorityradios.co.uk splashing and no objects filled with liquid, such as 3. Heed all Warnings vases, shall be places on the apparatus.
  • Page 23 www.majorityradios.co.uk...
  • Page 24 MAJORITY PARKSIDE GO Digital Pocket Radio mit SD-Karten-Wiedergabe Instructions guide ist in deutscher Sprache auf unserer website verfügbar: www.majorityradios.de Anleitung PAGO-DAB-BLK...

This manual is also suitable for:

Pago-dab-blk
