- Page 1 Installation Guide Manual P/N 3-500049-01 MaxiScan 3010 Network System...
- Page 2 No part of this installation guide may be copied or reproduced in any manner without the prior written permission of Intermec Technologies Corporation. © Intermec Technologies Corporation All Rights Reserved The word Intermec, the Intermec logo, MaxiScan 3010 Network System and EasySet are either trademarks or registered trademarks of Intermec. ™...
-
Page 3: Table Of Contents
4 Setup ..................13 Online setup Offline setup 5 System configuration checklist......... 19 6 Technical characteristics........... 21 7 Pinouts................. 23 Scanner bus Power supply Host Synchros 8 Intermec scanner bus cables ..........27 Cable overview Pinouts MaxiScan 3010 - Installation Guide... - Page 4 MaxiScan 3010 - Installation Guide...
-
Page 5: Introduction
3100, MaxiScan 3300). This Installation Guide explains how to install your MNS 3010 and how to set up a network configuration. Use the EasySet System setup software to set up the MaxiScan 3010 Network System. The MaxiScan 3010 Network System is designed for use with a network of MaxiScan 3100 and/or MaxiScan 3300 scanners. - Page 6 1 Introduction MaxiScan 3010 - Installation Guide...
-
Page 7: Installation
Setup You can use a standard RS-232 cable for MaxiScan to set up your MaxiScan 3010 Network System with EasySet. Test your setup before you install the MaxiScan 3010 Network System permanently. • Twisted pair for data lines is strongly recommended Cabling on the SCANNER BUS port. - Page 8 2 Installation MaxiScan 3010 - Installation Guide...
-
Page 9: Connections
SUPPLY network cable power supply See the Pinouts and Intermec scanner bus cables sections to make your physical connections. How you connect up your MaxiScan 3010 Network System depends on the number of MaxiScan units in the network and the power rating of the power supply connected to the MNS 3010. -
Page 10: Network Of More Than 2 Maxiscan Units (With Mcs Boxes)
The MaxiScan units are connected to their respective standard MaxiScan Connexion System (MCS) boxes. All standard MCS boxes are then interconnected to the MaxiScan 3010 Network System through an RS-485 network bus. Each MaxiScan has its own power supply and manages its own I/O synchronization lines. -
Page 11: Network Of 1 Or 2 Maxiscan Units (Without Mcs Boxes)
RS-232 C If you use a standard MaxiScan 3100 / 3300 power supply (15 V), this solution is only possible if you connect 1 or 2 MaxiScan units to the MaxiScan 3010 Network System. If you want to connect more than 2 MaxiScan units, you must use the alternative... - Page 12 3 Connections MaxiScan 3010 - Installation Guide...
-
Page 13: Setup
System power ON MaxiScan 3100 only: Scan this code to enable online setup with EasySet EasySet Start EasySet \41\4A\0F\29\60 RS-232 cable P/N: 0-530022-01 Activate each MaxiScan unit as a slave with its own slave ID number MaxiScan 3010 - Installation Guide... - Page 14 4 Setup 2. Set up the MaxiScan 3010 Network System System power OFF RS-232 cable P/N: 0-530022-01 Connect the MaxiScan 3010 Network System to the PC where EasySet is installed System power ON EasySet Start EasySet RS-232 cable P/N: 0-530022-01...
-
Page 15: Offline Setup
– activate slave – MaxiScan 3100 - slave 1 \41\4A\0F\2A\47\3E\05\60 slave configuration – activate slave – MaxiScan 3100 - slave 2 \41\4A\0F\2A\47\3E\07\60 slave configuration – activate slave – MaxiScan 3100 - slave 3 \41\4A\0F\2A\47\3E\08\60 MaxiScan 3010 - Installation Guide... - Page 16 – activate slave – MaxiScan 3100 - slave 5 \41\4A\0F\2A\47\3E\0A\60 MaxiScan 3300 slave configuration – activate slave – MaxiScan 3300 - slave 1 \48\47\01\40\43\46\00\48\3E\06\49\3E\15\41\08\40\4E\45\53\3E\02\45\54\3E\03\47\3E\05\45\57\60 slave configuration – activate slave – MaxiScan 3300 - slave 2 48\47\01\40\43\46\00\48\3E\06\49\3E\15\41\08\40\4E\45\53\3E\02\45\54\3E\03\47\3E\07\45\57\60 MaxiScan 3010 - Installation Guide...
- Page 17 – activate slave – MaxiScan 3300 - slave 3 48\47\01\40\43\46\00\48\3E\06\49\3E\15\41\08\40\4E\45\53\3E\02\45\54\3E\03\47\3E\08\45\57\60 slave configuration – activate slave – MaxiScan 3300 - slave 4 48\47\01\40\43\46\00\48\3E\06\49\3E\15\41\08\40\4E\45\53\3E\02\45\54\3E\03\47\3E\09\45\57\60 slave configuration – activate slave – MaxiScan 3300 - slave 5 48\47\01\40\43\46\00\48\3E\06\49\3E\15\41\08\40\4E\45\53\3E\02\45\54\3E\03\47\3E\0A\45\57\60 MaxiScan 3010 - Installation Guide...
- Page 18 4 Setup MaxiScan 3010 - Installation Guide...
-
Page 19: System Configuration Checklist
Configure the MaxiScan slave units (online or offline setup)—each MaxiScan slave unit must have its own ID number. Configure the MaxiScan 3010 Network System (online setup)—parameters include the number of MaxiScan slave units on the network, polling delay, RS-232 C settings for communication with the host system. - Page 20 5 System configuration checklist MaxiScan 3010 - Installation Guide...
-
Page 21: Technical Characteristics
> 50 000 hours Cables The case of the MaxiScan 3010 Network System must be connected to the earth. Use shielded cables for the SCANNER BUS line. Twisted pair is recommended for data lines on the SCANNER BUS port. MaxiScan 3010 - Installation Guide... - Page 22 6 Technical characteristics MaxiScan 3010 - Installation Guide...
-
Page 23: Pinouts
(SI+) negative synchronization input (SI-) Not Connected Not Connected power in (7 to 25 VDC) power in (7 to 25 VDC) power ground Shield power ground power in (7 to 25 VDC) power ground MaxiScan 3010 - Installation Guide... -
Page 24: Power Supply
(7 to 25 VDC) power in (7 to 25 VDC) power in (7 to 25 VDC) power in (7 to 25 VDC) power in (7 to 25 VDC) power ground power ground power ground power ground MaxiScan 3010 - Installation Guide... -
Page 25: Host
(RS-232 C) transmit data (RS-232 C) clear to send (RS-232 C) request to send (RS-232 C) Not connected Not connected Not connected reserved reserved reserved reserved reserved signal ground (RS-232 C) reserved reserved MaxiScan 3010 - Installation Guide... -
Page 26: Synchros
SI+ signal to the SCANNER BUS port only (serial connection to slaves with MNS 3010 network cables) negative synchronization input (SI-) (50 mA max) 7-25 VDC 10 Watt reserved reserved power ground MaxiScan 3010 - Installation Guide... -
Page 27: Intermec Scanner Bus Cables
