IM 11
RFID Reader Module
Integration Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IM11 and is the answer not in the manual?

Questions and answers

Related Manuals for Intermec IM11

Summary of Contents for Intermec IM11

  • Page 1 IM 11 RFID Reader Module Integration Guide...
  • Page 2 Intermec Technologies Corporation. Information and specifications contained in this document are subject to change without prior notice and do not represent a commitment on the part of Intermec Technologies Corporation. © 2013 by Intermec Technologies Corporation. All rights reserved.

  • Page 3: Table Of Contents

    About the IM11........
  • Page 4 DIP Switch Default Settings ..........35 IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 5: Before You Begin

    Note: Notes either provide extra information about a topic or contain special instructions for handling a particular condition or set of circumstances. Global Services and Support Warranty Information To understand the warranty for your Intermec product, read the Intermec supply agreement. IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 6: Web Support

    Taiwan OEM Sales: +886-936-934-366 Who Should Read This Manl This integration guide explains how to integrate the IM11 module into a computer or other device. It is written for the person who will be integrating the module into any product that needs to be UHF RFID-enabled.

  • Page 7: Related Documents

    There may be U.S. and foreign patents pending. Regulatory Information Note: Regulatory compliance of the end product is the responsibility of the module integrator. Upon request, Intermec will provide proprietary module documentation using non-disclosure agreements (NDAs) or directly to the certifying agency.

  • Page 8: Safety

    The module incorporates principles for ease of disassembly to facilitate recovery and recycling of printed circuit board assemblies and base materials. Restriction of Hazardous Substances (RoHS) Directive The module complies with the RoHS Directive. viii IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 9: About The Im11

    About the IM11 The Intermec IM11 RFID Reader Module is designed for quick integration into computers, printers, and any other products that need to be RFID-enabled. The IM11 includes these features: • Allows the RFID-enabled product to read and write to tags used in most worldwide applications: •...

  • Page 10: Technical Overview

    Operating 3.15 All internal voltages Voltage regulated on module Deep Sleep μA Vbatt current when enable low powers Real-Time Clock Standby At 3.8 V, USB Current connection in Suspend mode, no GPIO loading IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 11 As measured by Shutdown sensor on module Thermal °C Recovery Transceiver Specifications Specification Values Output Power Control 29.5 dBm. User adjustable in 1 dBm down to 10.5 dBm. Tolerance drift from +0.5 to -0.7. IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 12 Read Speed >200 tags per second (using 32 conducted tags) 50 tags per second (using over air tags) Performance Testing AD 223 tags on cardboard IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 13: Epc Compliance And Certification

    Multiple Reader Mode: Operates in an EPC Class 1 Gen 2 multiple • interrogator environment. Dense Reader Mode: Operates in an EPC Class 1 Gen 2 dense • interrogator environment. May require reducing power output to 27 dBm to meet EPC DRM guidelines. IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 14: Mechanical Integration

    45.84 50.95 IM11 RFID Reader Module Physical Specifications: 50.95 mm long x 30 mm wide x 4.78 mm thick. Exceptions to the MiniPCI Express form factor: top shield side thickness is 2.4 mm (instead of 2.01 mm) and bottom shield side thickness is 1.35 mm (instead of 1.75 mm).

  • Page 15: About The Connectors

    Radio communications regulatory agencies in each country has restrictions for antenna gain or transmitter power. Consult with your Intermec OEM Sales Representative or Professional Wireless /RFID Installer for details. These antennas are approved to work with the IM11: • Antenna primary linear (0 dBi linear, omni) •...

  • Page 16: Operating Modes

    The module has a temperature sensor. If overtemperature is detected (nominally 85 °C), the module sends an overtemperature message. No RF output occurs until the temperature falls below the recovery threshold (nominally 75 °C). IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 17: Electrical Integration

    IM11. For proper placement, refer to the illustration of the page 14...

  • Page 18: Reader Power States

    The module handles its own power management and goes into Standby mode automatically when there are no outstanding commands. However, even in Standby mode, the IM11 immediately responds to host activity, eliminating any potential host timeout conditions. To achieve an even lower power Standby mode, the host needs to support USB suspend and remote wakeup.

  • Page 19: Reader Power Draw

    Reader Power Draw This section explains the power draw of the IM11 under various operating conditions. These are the four tests that were conducted: Test A: READ REPORT=EVENT: This test uses default values •...
  • Page 20 Supply Voltage 3.35 V Radiated,50 Tags Cardboard Box in Front of Antenna Field Strength Test A Test B Test C Test D 30 dB 27 dB 24 dB 21 dB 18 dB 15 dB IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 21 21 dB 18 dB 15 dB BRI, Default Attributes, 32 Conducted Tags, READ: The long, flat CW period after the inventroy round is caused when the BRI repoprts the tags before shutting off RF. IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 22: Mini-Pci Connector Pin Descriptions

    REPORT=EVENT: UNSELTRIES=0 causes the tags to remain quiet, they rarely respond after the first time. Mini-PCI Connector Pin Descriptions Pin Descriptions Pin Name Description Reserved Do NOT connect +V_BATT Power input Reserved Do NOT connect Ground IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 23 USB (at Enable active) Reserved Do NOT connect +V_BATT Power input Reserved Do NOT connect Ground Ground GPIO1 Ground GPIO3 Reserved Do NOT connect GPIO4 RESET_L Logic low level resets IM11 Ground IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 24 RS-232 transceiver. • USB_DP: If UART_SEL_L is low, pull up to wake up. If logic level is low, IM11 is in Sleep mode. • All signals are 3.3 V logic levels (5 V tolerant inputs). IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 25: Input And Output Voltage Level Descriptions

    Auxiliary outputs are 3-state inputs (high impedance) on power-up until they are written to for the first time. You should provide pullups or pulldowns to keep any external logic disabled during this condition. IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 26: Transmit Power

    Output power tolerance from the nominal setting is +/- 0.75 dBm over an ambient temperature range of -20 °C to 60 °C. The module supports PR-ASK modulation for EPC Class 1 Gen 2 tags only. IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 27: Rf Integration

    Basic Reader Interface (BRI) Programmer Reference Manual. BRI Command Default Values Command Default Value ANTS ANTTIMEOUT ANTTRIES BROADCASTSYNC CHKSUM DENSEREADERMODE ECHO EPCC1G2PARAMETERS FIELDSEP ASCII space character (0x20) FIELDSTRENGTH 30dB, 30dB IDREPORT IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 28 TIMEOUTMODE UNSELTRIES UTCTIME WRTRIES From the Intermec website, you can also download a sample application (JRFID) to test, configure, and control the module. To download the JRFID application 1 Go to www.intermec.com. 2 Click Products > RFID > Fixed Readers > IF2.

  • Page 29: About The Development Kit

    USB cable • Serial cable • RFID tags • CD that contains software tools and this guide Once connected, open a serial or USB connection to setup, test, configure, and control the module. IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 30 Antenna port 1 Antenna port 2 Antenna cables COM 2 COM 1 CN19 USB port IM11 Development Board: The default settings for the switches and jumpers. IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 31: Connect The Development Kit

    6 Configure the communications parameters to: • Bits per second: 115200 • Data bits: 8 Parity: None • • Stop bit: 1 • Flow control: None Send line ends with line feeds: Enabled • IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 32: Open A Usb Connection

    2 Click Start > Programs > Accessories > Notepad. 3 In Notepad, copy and paste this text: [Version] Signature="$Windows NT$" Class=Ports ClassGuid={4D36E978-E325-11CE-BFC1-08002BE10318} Provider=%LINUX% DriverVer=08/17/2004,0.0.2.0 ; Copyright(C)2004 Al Borchers (alborchers@steinerpoint.com) [Manufacturer] %LINUX%=GSerialDeviceList [GSerialDeviceList] %GSERIAL%=GSerialInstall, USB\VID_0525&PID_A4A7 [DestinationDirs] DefaultDestDir=10,System32\Drivers [GSerialInstall] CopyFiles=GSerialCopyFiles IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 33 10 Connect the USB cable from the USB port on the development board to the USB port on your PC. The Found New Hardware Wizard appears. 11 Select Install from a list or specific location (Advanced), and click Next. IM11 RFID Reader Module Integration Guide (Confidential)

  • Page 34: Troubleshooting

    13 When the Windows Logo Testing screen appears, click Continue Anyway . The development kit is connected through USB. Troubleshooting Use the information in this section to fix problems with the IM11 module. Problems While Working with RFID Many problems you may encounter when working with your RFID system can be solved by carefully checking the RFID settings and changing them accordingly.

  • Page 35: Restore Default Settings

    SW1 DIP Switch Default Settings SW1 DIP Switch Default Settings Dip Switch Description Default Setting EN HEADSET DET Disabled EN BUTTON DET Disabled EN GRN LED Enabled EN RED LED Disabled IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 36 DISABLE MODEM Enabled SW4 DIP Switch Default Settings SW4 DIP Switch Default Settings Dip Switch Description Default Setting EN FIXED OUTPUT 3.3 V EN BARREL JACK LDO MODEM - 2.6 V LDO 2.6 V IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 37 SW3 DIP Switch Default Settings SW3 DIP Switch Default Settings Dip Switch Description Default Setting EN MIC_P GAIN + 20 dB EN MIC_N GAIN + 20 dB EN MIC_P BYPASS EN MIC_N BYPASS IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 38 Jumper J4 Jumper Default Setting J4 Jumper Default Setting Jumper Installed Description Default Setting VCC_3.3 V IM11 RFID Reader Module Integration Guide (Confidential)
  • Page 40 Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 41 Cet équipement doit être installé et utilisé avec un minimum de 20 cm de distance entre la source de rayonnement et votre corps. DETACHABLE ANTENNA USAGE This radio transmitter (IC: 1639B-IM11PRT/ Model: IM11-PRT) has been approved by ISED to operate with the antenna type listed below with maximum permissible gain indicated.
  • Page 42 d'antenne non inclus dans cette liste, et dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de l'émetteur. Approved antenna(s) list Type Gain Brand Manufacturer near-field -30dBi Honeywell Honeywell This device is intended only for OEM integrators under the following conditions: (For module device use) 1) The antenna must be installed such that 20 cm is maintained between the antenna and users.
  • Page 43 Plaque signalétique du produit final Ce module émetteur est autorisé uniquement pour une utilisation dans un dispositif où l'antenne peut être installée de telle sorte qu'une distance de 20cm peut être maintenue entre l'antenne et les utilisateurs. Le produit final doit être étiqueté dans un endroit visible avec l'inscription suivante: "Contient des IC: 1693B-IM11PRT".
  • Page 44 Worldwide Headquarters 6001 36th Avenue West Everett, Washington 98203 U.S.A. tel 425.348.2600 fax 425.355.9551 www.intermec.com © 2013 Intermec Technologies Corporation. All rights reserved. IM11 RFID Reader Module Integration Guide *944-637-001* P/N 944-637-001...
