INSTALLATION ANd OPERATION INSTRUCTIONS
PERLICk bATCh ROTARy gLASSwAShERS
PkbR24L
IMPORTANT INFORMATION
This. manual. has. been. prepared. to. assist. you.
in. the. operation. of. . the. Perlick. Batch. Rotary.
Glasswasher.
We. dedicate. considerable. time. to. ensure. that. our. .
products. provide. the. highest. level. of. customer. .
satisfaction.. If. service. is. required,. your. dealer. can. .
provide.you.with.a.list.of.qualified.service.agents..For.
your. own. protection,. never. return. merchandise. for. .
credit.without.our.approval.
We. thank. you. for. selecting. a. Perlick. product. and. .
assure. you. of. our. continuing. interest. in. your. .
satisfaction.
8300.West.Good.Hope.Road..•..Milwaukee,.WI.53223..•..Phone.414-353-7060..•..Fax.414-353-7069
PkbR24
Toll.Free.800-558-5592..•..E-Mail:.Perlick@Perlick.com..•..www.Perlick.com
MOdEL NOS.
PKBR24
■
PKBR24L
■
PKBR24R
■
Table of Contents
warranty Information......................................... 2
Specifications..................................................... 3
Water.Conditioning. . ............................................. 4
Chemical.Concentrations. . ................................... 4
Before.Starting.the.Glasswasher......................... 5
Starting.the.Glasswasher..................................... 5
Priming.the.Chemical.System. . ............................ 5
Operational.Testing.............................................. 5
Installing.Chemical.Squeeze.Tubes..................... 6
Priming.the.Chemical.Pumps.............................. 7
Setting.the.Chemical.Controls............................. 7
Component.Identification. . ................................... 8
Instrument.Panel.................................................. 9
Operating.the.Glasswasher. . ................................ 9
Washing.Glasses. . ................................................ 9
Chemical.Control.Panel..................................... 10
End.of.Day.Shutdown........................................ 11
Deliming. . ............................................................ 11
Troubleshooting. . ................................................ 11
Replacement.Parts. . ........................................... 13
Electrical.Connection.Diagram. . ......................... 14
Adjusting.Chemical.Concentrations. . ................. 15
Calibrating.the.Chemical.System. . ..................... 15
