- Page 1 TIDLAND SLITTING SOLUTIONS Tidland Digital Measurement System Installation, Operation and Maintenance For use with SIKO MA503 display MI 659995 1 M...
- Page 3 Cleaning the linear rails ..................4-1 PARAMETERS Display Parameters ....................5-1 Parameter Description ..................5-2 CAUTION Wear eye protection when using tools or compressed air. TIDLAND CUSTOMER SERVICE 800.426.1000 www.maxcessintl.com 360.834.2345 www.maxcessintl.com Tidland Digital Measurement System MI 659995 1 M...
- Page 4 WIRING DIAGRAM Wiring Diagram www.maxcessintl.com Tidland Digital Measurement System MI 659995 1 M...
- Page 5 2. Connect green ground wire to earth ground. Step Four 1. The DMS requires clean, non-lubricated (instrument quality) air at approximately 5.5 bar [80 psi]. 2. Connect hose assembly to mill air. Note: 1/8 NPT connection is provided. www.maxcessintl.com Tidland Digital Measurement System MI 659995 1 M...
-
Page 6: Positioning Anvil Rings Using The Dms
Note: Move the reader head away from the anvil ring before retracting set stop shaft. 6. Retract the set stop shaft with the set stop shaft extension knob. Repeat for each anvil ring. www.maxcessintl.com Tidland Digital Measurement System MI 659995 1 M... -
Page 7: Cleaning The Linear Rails
3. Using a vacuum system or compressed air, clean around the upper and lower bearings and rails while moving the carriage from one end of the linear rail to the other. 4. Wipe the linear rails using a clean, lint-free cloth. www.maxcessintl.com Tidland Digital Measurement System MI 659995 1 M... -
Page 8: Display Parameters
To switch on the parameters: Press To change parameters: To store parameters: Press To leave programming mode: It is automatic when no key is pressed in approximately 30 seconds OR Press www.maxcessintl.com Tidland Digital Measurement System MI 659995 1 M... - Page 9 'Last value' memory is ON. If you lose power, the last measured value will be displayed when the unit it turned on. If the unit is moved during the power outage, the value may vary slightly. Tidland recommends recalibrating any time there is a loss of power.
- Page 10 Language: to choose the language in which the menu points are to be displayed Note: If display is in German, this parameter is "SPr". Set to "E" to display English. "d" German "E" English www.maxcessintl.com Tidland Digital Measurement System MI 659995 1 M...
