Summary of Contents for TERMA ONE
- Page 1 User Manual Electric Heating Element...
-
Page 2: Important-Please Read
Electric radiator & Electric Heating Element General rules. As of 1 January 2005, changes to the Building Regulations affected 1. Electric heater is not a toy. domestic electrical installations Children under the age of 3 in England and Wales. You do not should not be allowed within need to be a qualified electrician close proximity of the device... - Page 3 on for a maximum of 3 seconds. case which demands its replace- BEWARE! DURING THIS TEST THE ment, contact your supplier. HEATING ELEMENT WILL GET 5. The device is not equipped with VERY HOT ALMOST IMMEDI� an external temperature con- ATELY;...
- Page 4 Notes for safe use. 1. The heating element’s power 5. The heating element must be fully submerged in the heating liquid during its operation. output must not exceed the ra- 6. Ensure that the power cord does not touch the hot diators power output for the pa- parts of the heating element or radiator.
-
Page 5: Installation
Installation Electric only Radiator 230 VAC 1. Correct placement and position of the radiator and heating element. 2. Install and tighten by hand only. 3. Fill the radiator with a proper heating agent. Use a suitable heating liquid for filling the electric radiator, (i.e.) water, special products based on wa- ter and glycol for use in central heating systems, or oil which complies with the requirements of the manufacturer of the radiator and heating element When filling the radiator with hot liquid insure that the liquid temperature does not exceed 65°... - Page 6 1 Phase Supply (220-240V 50 Hz) GREEN / YELLOW E (PE) BLUE BROWN FUSE 230 VAC 230 VAC 0,5 h 5. Set the heater on max and keep it for 30 min. 4. Fit the radiator on the wall and connect the heating element to the power supply.
- Page 7 Dual Fuel Radiator 230 VAC 1. Correct placement and position of the radiator and heating element. OPEN OPEN OPEN CLOSE 2. Fit the T-fitting to the radiator and then in- Fill the radiator with the water, then bleed it. Once bled make sure that the flow and return valves stall the heating element.
-
Page 8: Functions And Use
Functions and use The ‘ONE’ heating element has two radia- tor temperature settings (45° C and 60° C) as well as an automatic 2 hour timer that will switch off the element. The on/off button is also used to change set- tings which are identified by using different colours of the LED diode. -
Page 9: On/Off Button
Turning the device on will result in the radiator heating up to the set temperature (45/60° C). The ‘ONE’ is pre configured to work with Terma IR con- After reaching the set temperature the device will trollers (DTIR and TTIR). -
Page 10: Maintenance
Notes prior to removal: Maintenance 1. Before dismantling permanently, disconnect the heat- • Before performing maintenance, always unplug the unit ing element from the mains and ensure that the radiator from the mains system. is not hot. • Periodically check the fluid level in the radiator and en- 2. -
Page 11: Troubleshooting
Troubleshooting The ‘ONE‘ constantly monitors all of its parameters so that it can indicate if it is damaged or not working correctly due to an in- ternal fault. If a problem is found it automatically activates any necessary protective procedures. - Page 12 www.termaheat.pl MPGKE-218 WOŁOSIUK KACPER...
