5350a Reference Series
Reference 5350a Basic Specifications
Output Power:
(14.4 VDC)
Signal-to-noise ratio:
Dynamic power:
Effective damping factor:
Frequency response:
Maximum input signal:
Maximum sensitivity:
Output regulation:
Dimensions (L x W x D):
Fuse:
Infinity continually strives to update and improve existing products, as well as create new ones. The specifications
and details in this and related JBL publications are therefore subject to change without notice.
- CONTENTS -

BASIC SPECIFICATIONS ......................................1

DETAILED SPECIFICATIONS .................................2
PACKING............................................................3
APPLICATIONS...................................................4
INSTALLATION/SETUP..........................................5

BASIC TROUBLESHOOTING..................................5

EXPLODED VIEW/PARTS LIST...............................6

AMPLIFIER BLOCK DIAGRAM................................7

P.C.B. DRAWINGS................................................8

ELECTRICAL PARTS LIST .................................. 11

IC/TRANSISTOR PINOUTS....................................17
SCHEMATICS......................................................18
50W RMS x 4 channels plus 150W RMS x 1 channel at 4 ohms ; ≤1% THD
60W RMS x 4 channels plus 300W RMS x 1 channel at 2 ohms ; ≤1% THD
85dBA (reference 1W into 4 ohms)
89W x 4 and 332W x 1 at 2 ohms
6.3 @ 4 ohms
10Hz – 100kHz (-3dB)
6.0V
100mV
0.12dB @ 4 ohms
16-9/16" x 9" x 2-11/16" (421mm x 229mm x 69mm)
2 x 40A
