Infinity Reference 5350a Service Manual page 17

5350a Reference Series
Description
Part Number
MECHANICAL
LS1AM0250401 Screw
LS1AA0301501 Screw
LS1FJ0200801 Screw
LS1CJ0402507 Screw
XN-10500-011 Knob
XN-10500-012 Knob
LS5KJ0301007 Screw
LS5KP0300807 Screw
LS1AP0300607 Screw
LS1AM0300607 Screw
KT-200012200 CAP
KT-200021300 CAP
DQ8069032084 Washer
LS1AY0301201 Screw
PL-L0007-000 Clipper
PL-L0006-000 Clipper
XG-0018-2601 Bottom plate
HG-0007-2601 Rear plate
MK-0006-2601 Front plate
KG-100100500 Snap bottom
LS1AA0200501 Screw
LS1FM0300011 Screw
CP-B00011400 Lens
GD-600021400 Reflector board
SG-0017-2601 Top plate
SR-F550-0117 Heatsink
JY436A10A10X Insulated paper
JY428A10A10X Insulated paper
ZL-A0001A-15 PC pole
JD-A01970515 Round mat
Plating black Zinc 2.5*4
PA3*15 Plating black Zinc
KA2*8 Black Zinc
T4*25MM Plating Nickel
ABS-757Black 11.7*Ф11MM with red arrow Black
painting
ABS-757Black Ф10.5*9MM with white arrow
3*10MM (Plating Nickel)
3*8MM (Plating Nickel)
3*6MM (Plating Nickel)
PM3*6(Plating Nickel)
White PVC for RCA
Red PVC for RCA
Φ6.9*Φ3.2*0.8MM
PM3*12MM Plating Black Zinc
30*36*0.8mm flexibility
30*28*0.8mm flexibility
385*182*1.2mm，H1-144 silver paintng
214*70*1.2mm H1-144 silver painting with
silkscreen
214*70*1.2mm H1-144 silver painting with
silkscreen
T07-003-01φ11*φ14*10.8 BlackABS
PA2*5(Black Zinc)
KM 3*6MMBlack Zinc
40*10.8*5.7mm PC cold grey 10C
340*53.5*13mm Clear Blue PC
420*227*62mm dia- casting aluminum alloy, H1-
144 silver painting with silkscreen
385*216*61mm extrusion, Hair with painting
Red;36*10*1.0mm one side with glue
28*10*1.0mm Red one side with 3M glue
φ7.5*φ3.0*6.4mm white LASK-5
Φ5.0*2.0 black EVA 60 one side with glue
Qty Reference Designator
4
2
2
4
1
7
7
8
6
4
3
3
2
2
8
7
1
1
1
4
1
6
1
1
1
1
1
6
2
7
16
