Ravenheat HE 25 C COMPACT Instructions For Use Installation And Servicing

High efficiency condensing combination boiler
Hide thumbs
Table of Contents

Advertisement

Quick Links

Instructions for Use

Installation and Servicing

To be left with the user
HIGH EFFICIENCY
CONDENSING

COMBINATION BOILER

HE 25 C - 30 C - 35 C - 40 C
COMPACT
Natural Gas (G20) II
2H3P
LPG (G31) II
2H3P
Technical and illustrative data are not binding and can be modifi ed without prior notice.
The descriptions and illustrations in the present booklet are for guidance purposes only.
RAVENHEAT INTERNATIONAL s.r.l. Via Dell' Agricoltura, 50 37059 Zevio (VR) IT
Tel. 045/6051578 - Fax 045/6060662
e-mail: info@ravenheat.it
1312
