BIRCH 854

Mini Barebone system
Intel D510 High Performance Platform
Installation Guide
Edition 1.0
2010/8/31









Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 854 and is the answer not in the manual?

Questions and answers

Summary of Contents for Birch 854

  • Page 1         BIRCH 854   Mini Barebone system Intel D510 High Performance Platform Installation Guide Edition 1.0 2010/8/31                ...
  • Page 2: Hardware Installation

    Document Content:  Packing List  Product Specification  Hardware Installation Packing List: BIRCH 854 Chassis x 1 (Including D510MO Motherboard) DSPD-080-12A 80W AC-DC Adapter x 1 Power Cord x 1 ATAPI Power Cord x1 SATA Cable x 1 ATX to SATA Power Cable x 1 CD Driver x1  ...
  • Page 3: Rear Panel

    Hardware Installation: I/O panel: Front: Reset Button Power Button   HD LED     Power LED Rear panel:     PRINTER PORT Antenna   COM4 COM3 RJ-45   Line-in     Mouse   Mic-in DC IN   Line-out Keyboard COM2 COM1  ...
  • Page 4: System Memory

    Processor Birch 854 includes a passively-cooled, dual-core Intel Atom processor with integrated graphics and memory controller. The processor is soldered to the Desktop Board and is not customer upgradeable. NOTE The board is designed to be passively cooled in a properly ventilated chassis. Chassis venting locations are recommended above the processor heatsink area for maximum heat dissipation effectiveness.
  • Page 5: Operating System Support

    • Microsoft Windows* XP Home, SP 3 • Microsoft Windows* 7 Home Basic and Starter Onboard Audio Subsystem The Birch 854 6-channel (5.1) onboard audio subsystem supports both Intel HD Audio and AC ’97 Audio. The subsystem is based on the following components: •...
  • Page 6: Usb 2.0 Support

    • PCI bus power management Supports ACPI technology Supports LAN wake capabilities LAN drivers are available from Intel’s World Wide Web site at http://downloadcenter.intel.com/. USB 2.0 Support The Desktop Board supports up to seven USB 2.0 ports (four ports routed to the back panel and three ports routed to two front panel USB 2.0 headers).
  • Page 7: Power Management Features

    and for booting the computer, with the following restrictions: • The supervisor password gives unrestricted access to view and change all Setup options. If only the supervisor password is set, pressing <Enter> at the password prompt of Setup gives the user restricted access to Setup.
  • Page 8: Lan Wake Capabilities

    sleep-state. While in the ACPI S3 sleep-state, the computer will appear to be off (the hard drive(s) and fan will power off, the front panel power LED will blink). When signaled by a wake-up device or event, the system quickly returns to its last known state. The board supports the PCI Bus Power Management Interface Specification.
  • Page 9: Installing Memory

    <Installing Memory>   NOTE To be fully compliant with all applicable Intel SDRAM memory specifications, the boards require DIMMs that support the Serial Presence Detect (SPD) data structure. The Desktop Board has two 240-pin DDR2 DIMM sockets.     1. Turn off all peripheral devices connected to the computer. Turn off the computer and disconnect the AC power cord.
  • Page 10 <Connecting SATA Drives> The board has two SATA connectors each supporting one SATA drive. The included SATA cables support the Serial ATA protocol. For correct cable and drive function: 1. Attach the locking cable end to the connector on the board. 2.
  • Page 11 <Installing a Wireless LAN Card in the PCI> A wireless LAN card can be installed in the Desktop Board’s PCI Express Full-Mini Card slot. To install a wireless LAN card on the Desktop Board, see Figure 10 and follow these steps: 1.
  • Page 12: Setting The Bios Configuration Jumper

    <Setting the BIOS Configuration Jumper> NOTE Always turn off the power and unplug the power cord from the computer before changing a jumper. Moving the jumper with the power on may result in unreliable computer operation.      ...
