Birch PP-8100-15 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A l w a y s h i g h - s p e e d ! a b s o l u t e l y d e s i r a b l e
®Copyright 2015 July All Rights Reserved Version 1.0
The information contained in this document is subject to change without notice. We make no warranty of any
kind with regard to this material, including, but not limited to, the implied warranties of merchantability
and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental
or consequential damages in connection with the furnishing, performance, or use of this material.
This document contains proprietary information that is protected by copy right. All rights are reserved. No part of
this document may be photocopied, reproduced or translated to another language without the prior
written consent of the manufacturer.
TRADEMARK
Intel®, Pentium® and MMX are registered trademarks of Intel® Corporation. Microsoft® and Windows® are
registered trademarks of Microsoft Corporation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP-8100-15 and is the answer not in the manual?

Questions and answers

Related Manuals for Birch PP-8100-15

Summary of Contents for Birch PP-8100-15

  • Page 1 A l w a y s h i g h - s p e e d ! a b s o l u t e l y d e s i r a b l e ®Copyright 2015 July All Rights Reserved Version 1.0 The information contained in this document is subject to change without notice.

  • Page 2: Main Board

    Main Board PP-8100-15 Intel® Bay trail Celeron J1900 Processor D/M Series (2M Cache, 2.0 GHz) Chipset Intel® SoC System Memory Max 2 DDR3L 1333 MHz SO-DIMM slots, up to 8GB Graphic Memory Intel® HD Graphics LCD Panel PP-8100-15 Panel Size 15”...

  • Page 3: Optional Peripherals

    Optional Peripherals Magnetic Card Reader ISO Track 1/2/3, USB interface VFD customer display 20 x 2 characters, RS-232 interface Dimensions PP-8100-15 358(W) X 70(L) X 293(H) mm PP-8100-T15 358(W) X 223.9(L) X 309.6(H) mm Environment Operating Temperature 0°C ~ 40°C ( 32°F ~ 104°F ) Storage Temperature - 20°C ~ 60°C ( - 4°F ~ 140°F )
  • Page 4 If any item is missing, please contact your sale agent immediately. Take the system unit out from the carton. Remove the unit by carefully holding the foam inserts and remove slowly to protect the system. The following items should be found in the carton: 1.
  • Page 5 Please unplug the AC power of the adapter before opening any part of the system. Since the standby power is always on after the adapter is plugged in. It may cause permanent damage to your system when you open any part of it. Front View Power Earphone...
  • Page 6 Rear View Cable Cover Slot for installing Slot for installing Magnetic Card Custom Display Reader (optional) or Second Display (optional) VESA 75 VESA 100...

  • Page 7: How To Open The Connector Bezel

    How to open the connector bezel Please unplug the AC power of the adapter before opening any part of the system. Since the standby power is always on after the adapter is plugged in. It may cause permanent damage to your system when you open any part of it. As illustrated in the following, Release the screw...

  • Page 8: The Connector Panel

    The connector panel TOP of machine COM1 USB 2.0 Hard Disk 1 PS/2 USB 2.0 Microphone Power IN COM2 COM3 Hard Disk 2 Earphone Bottom of machine USB 2.0 Microphone Power Button Earphone...

  • Page 9: Installing Peripherals

    Please unplug the AC power of the adapter before opening any part of the system. Since the standby power is always on after the adapter is plugged in. It may cause permanent damage to your system when you open any part of the system. Installing Peripherals To install the peripheral’s cables, please follow the method described below.

  • Page 10: Installing Magnetic Card Reader (Msr)

    Installing Magnetic Card Reader (MSR) 1. Remove the rubber mat，Loosen the screw，and remove the MSR cover 2. Connected to the cable on the MSR and host，and lock two screws...

  • Page 11: Installing Customer Display

    Installing Customer Display 1. Remove the metal bezel 2. Connected to the cable, lock the two screws on Cable Cover 3. Installation VFD cover and lock the two screws...
  • Page 12 Installing Second Display 1. Remove the metal bezel 2. Connected to the cable, lock the two screws on Cable Cover 3. Installing the cover and lock the two screws...

  • Page 13: Remove And Installing Hard Disk

    Remove and Installing Hard Disk 1. Release the screw 2. Move these two sides upward 4. Grab the handle and pull up or down 3. Release the screw Remove or Installation Hard disk...

  • Page 14: Remove And Installing Memory

    Remove and Installing Memory 1. Release the screw 2. Grasp the both sides , and pulled down the back cover 3. Replace or Installing Memory...
  • Page 15 Installing WIFI Card and Antenna 1. Release the screw 2. Grasp the both sides , and pulled down the back cover 3. Install WIFI Card 4. Remove the plastic pad on the both sides Lock 2 screws of the Main cover 5.
  • Page 16 Installing A8V Printer Lock the cable box and A8 on the screw holes of the VESA75 1. Put the Cable box on the back of CZAR 2. Put the A8V on the Cable box 3. Determine screw holes are aligned 4.
  • Page 17 This chapter provides information on the BIOS Setup program and allows users to configure the system for optimal use. Users may need to run the Setup program when: ▄ An error message appears on the screen at system startup and requests users to run SETUP. ▄...

  • Page 18: Entering Setup

    Entering Setup Power on the computer and the system will start POST (Power On Self Test) process. When the message below appears on the screen, press <DEL> or <F2> key to enter Setup. Press <DEL> or <F2> to enter SETUP If the message disappears before you respond and you still wish to enter Setup, restart the system by turning it OFF and On or pressing the RESET button.

  • Page 19: Control Keys

    Control Keys ← → Select Screen ↑ ↓ Select Item Enter Select Change Option General Help Previous Values Optimized Defaults Save & Exit Exit Getting Help After entering the Setup menu, the first menu you will see is the Main Menu. Main Menu The main menu lists the setup functions you can make changes to.

  • Page 20: The Menu Bar

    The Menu Bar ▶Main Use this menu for basic system configurations, such as time, date, etc. ▶Advanced Use this menu to set up the items of special enhanced features. ▶Boot Use this menu to specify the priority of boot devices. ▶Security Use this menu to set supervisor and user passwords.
  • Page 21 Main ▶System Date This setting allows you to set the system date. The date format is <Day>, <Month> <Date> <Year>. ▶System Time This setting allows you to set the system time. The time format is <Hour> <Minute> <Second>. ▶SATA Mode This setting specifies the SATA controller mode.
  • Page 22 Advanced ▶Bootup NumLock State This setting is to set the Num Lock status when the system is powered on. Setting to [On] will turn on the Num Lock key when the system is powered on. Setting to [Off] will allow users to use the arrow keys on the numeric keypad.
  • Page 23 ▶Super IO Configuration ▶Serial Port 1/ 2/ 3/ 4/ 5/ 6 This setting enables/disables the specified serial port. ▶Change Settings This setting is used to change the address & IRQ settings of the specified serial port. ▶Parallel Port This setting enables/disables the parallel port. ▶Change Settings This setting is used to change the address &...
  • Page 24 ▶H/W Monitor These items display the current status of all monitored hardware devices/components such as voltages, temperatures and all fans’ speeds. ▶Smart Fan Configuration ▶Smart FAN1 Function These settings enable/disable the Smart Fan function. Smart Fan is an excel-lent feature which will adjust the CPU/system fan speed automatically de-pending on the current CPU/system temperature, avoiding the overheating to damage your system.
  • Page 25 ▶CPU Configuration ▶Active Processor Cores This setting specifies the number of active processor cores. ▶Execute Disable Bit Intel’s Execute Disable Bit functionality can prevent certain classes of malicious “buffer overflow” attacks when combined with a supporting operating system. This functionality allows the processor to classify areas in memory by where application code can execute and where it cannot.
  • Page 26 ▶PCI/PCIE Device Configuration ▶PCI Latency Timer This item controls how long each PCI device can hold the bus before another takes over. When set to higher values, every PCI device can conduct trans-actions for a longer time and thus improve the effective PCI bandwidth.
  • Page 27 ▶GPIO Group Configuration ▶GPO0 ~ GPO3 These settings control the operation mode of the specified GPIO.
  • Page 28 Boot ▶CSM Support This setting enables/disables the support for Compatibility Support Module, a part of the Intel Platform Innovation Framework for EFI providing the capability to support legacy BIOS interfaces. Important If the Operating System is going to boot in UEFI mode, disable CSM Support to speed up the boot process.
  • Page 29 Security ▶Administrator Password Administrator Password controls access to the BIOS Setup utility. ▶User Password User Password controls access to the system at boot and to the BIOS Setup utility. ▶Chassis Intrusion The field enables or disables the feature of recording the chassis intrusion status and issuing a warning message if the chassis is once opened.
  • Page 30 ▶Serial Port Console Redirection ▶Console Redirection Console Redirection operates in host systems that do not have a monitor and keyboard attached. This setting enables/disables the operation of console re-direction. When set to [Enabled], BIOS redirects and sends all contents that should be displayed on the screen to the serial COM port for display on the terminal screen.
  • Page 31 ▶Terminal Type To operate the system’s console redirection, you need a terminal supporting ANSI terminal protocol and a RS-232 null modem cable connected between the host system and terminal(s). This setting specifies the type of terminal device for console redirection. ▶Bits per second, Data Bits, Parity, Stop Bits This setting specifies the transfer rate (bits per second, data bits, parity, stop bits) of Console Redirection.

  • Page 32: Trusted Computing

    ▶Trusted Computing ▶Security Device Support This setting enables/disables BIOS support for security device. When set to [Disable], the OS will not show security device. TCG EFI protocol and INT1A interface will not be available. ▶Security Configuration ▶Intel(R) TXE Configuration Intel Trusted Execution Technology provides highly scalable platform security in physical and virtual infrastructures.
  • Page 33 Chipset ▶DVMT Pre-Allocated This setting defines the DVMT pre-allocated memory. Pre-allocated memory is the small amount of system memory made available at boot time by the system BIOS for video. Pre-allocated memory is also known as locked memory. This is because it is "locked" for video use only and as such, is invisible and unable to be used by the operating system.
  • Page 34 Power ▶Restore AC Power Loss This setting specifies whether your system will reboot after a power failure or interrupt occurs. Available settings are: [Power Off] Leaves the computer in the power off state. [Power On] Leaves the computer in the power on state. [Last State] Restores the system to the previous status before power failure or interrupt occurred.
  • Page 35 ** Advanced Resume Events Control ** ▶PCIE PME This field specifies whether the system will be awakened from power saving modes when activity or input signal of onboard PCIE PME is detected. ▶USB from S3/S4 The item allows the activity of the USB device to wake up the system from S3/S4 sleep state. ▶RTC When [Enabled], your can set the date and time at which the RTC (real-time clock) alarm awakens the system from suspend mode.

  • Page 36: Save And Exit

    Save & Exit ▶Save Changes and Reset Save changes to CMOS and reset the system. ▶Discard Changes and Exit Abandon all changes and exit the Setup Utility. ▶Discard Changes Abandon all changes. ▶Restore Defaults Use this menu to load the default values set by the motherboard manufacturer specifically for optimal performance of the motherboard.
  • Page 37 Please unplug the AC power of the adapter before opening any part of the system. Since the standby power is always on after the adapter is plugged in. It may cause permanent damage to your system when you open any part of the system. Installing Peripherals Connectors &...
  • Page 38 Memory The SO-DIMM slot is intended for memory modules. 1. Locate the SO-DIMM slot. Align the notch on the DIMM with the key on the slot and insert the DIMM into the slot. 2. Push the DIMM gently down-wards until the slot levers click and lock the DIMM in place.

  • Page 39: Power Supply

    Power Supply System Power Connector: JPWR1 This connector allows you to connect a power supply. To connect the power sup-ply, make sure the plug of the power supply is inserted in the proper orientation and the pins are aligned. Then push down the plug firmly into the connector.

  • Page 40: Rear Panel I/O

    Rear Panel I/O ▶ RS-232 Serial Port The serial port is a 16550A high speed communications port that sends/ receives 16 bytes FIFOs. You can attach a serial mouse or other serial devices directly to the connector. RS-232 SIGNAL DESCRIPTION Data Carrier Detect Receive Data Transmit Data...
  • Page 41 The standard RJ-45 LAN jack is for connection to the Local Area Network (LAN). You can connect a network cable to it. Color LED State Condition Left Yellow LAN link is not established. On (Steady state) LAN link is established. On (Blinking) The computer is communicating with another computer on the LAN.
  • Page 42 Connector Fan Power Connector: CPUFAN1 The fan power connectors support system cooling fan with +12V. When connecting the wire to the connectors, always note that the red wire is the positive and should be connected to the +12V; the black wire is Ground and should be connected to GND. If the motherboard has a System Hardware Monitor chipset onboard, you must use a specially designed fan with speed sensor to take advantage of the CPU fan control.

  • Page 43: Gpio Pin Header: Jgpio1

    GPIO Pin Header: JGPIO1 This connector is provided for the General-Purpose Input / Output (GPIO) peripheral module. Serial ATA Connector: SATA1 This connector is a high-speed Serial ATA interface port. Each connector can connect to one Serial ATA device. Important Please do not fold the SATA cable into a 90-degree angle.

  • Page 44: Front Panel Connector: Jfp1

    Front Panel Connector: JFP1 This front panel connector is provided for electrical connection to the front panel switches & LEDs and is compliant with Intel Front Panel I/O Connectivity Design Guide. LVDS Connector: JLVDS1 The LVDS (Low Voltage Differential Signal) connector provides a digital interface typically used with flat panels.
  • Page 45 USB 2.0 Connector: JUSB1, JUSB2 This connector, compliant with Intel I/O Connectivity Design Guide, is ideal for connecting high-speed USB interface peripherals such as USB HDD, digital cameras, MP3 players, printers, modems and the like. Important Note that the pins of VCC and GND must be connected correctly to avoid possible damage. Serial Port Connector: COM2 ~ COM6 This connector is a 16550A high speed communications port that sends/receives 16 bytes FIFOs.

  • Page 46: Tpm Module Connector: Jtpm1

    TPM Module Connector: JTPM1 This connector connects to a TPM (Trusted Platform Module) module (optional). Please refer to the TPM security platform manual for more details.

  • Page 47: Audio Amplifier Pin Header: Jamp1

    Audio Amplifier Pin header: JAMP1 The JAMP1 is used to connect audio amplifiers to enhance audio performance. Front Audio Connector: JAUD1 This connector allows you to connect the front panel audio and is compliant with Intel Front Panel I/O Connectivity Design Guide.
  • Page 48 Chassis Intrusion Pin Header: JCASE1 This connector connects to the chassis intrusion switch cable. If the computer case is opened, the chassis intrusion mechanism will be activated. The system will record this intrusion and a warning message will flash on screen. To clear the warning, you must enter the BIOS utility and clear the record. Keyboard/Mouse Connector: JKBMS1 This connector is provided to connect a keyboard and a mouse.
  • Page 49 Jumper Important Avoid adjusting jumpers when the system is on; it will damage the motherboard. Clear CMOS Jumper: JCMOS1 There is a CMOS RAM onboard that has a power supply from an external battery to keep the data of system configuration. With the CMOS RAM, the system can automatically boot OS every time it is turned on.
  • Page 50 Serial Port Power Jumper: JCOMP1 This jumper specifies the operation voltage of the COM1 serial port. Backlight Header & LVDS Power Jumper: JLCD1 Important Pin 2, 4, 6, 8 are panel power voltage select pins while pin 1, 3, 5, 7 are inverter voltage and control pins.

  • Page 51: Mini-Pcie (Peripheral Component Interconnect Express) Slot

    Slot PCIe (Peripheral Component Interconnect Express) Slot The PCI Express slot supports PCIe interface expansion cards. Mini-PCIe (Peripheral Component Interconnect Express) Slot The Mini-PCIe slot is provided for wireless LAN card, TV tuner card, Robson NAND Flash card and mSATA devices. Important When adding or removing expansion cards, make sure that you unplug the power supply first.
  • Page 52 Character Font Table A. Control code set B. U.S.A. font set...
  • Page 53 C. International character selection ASCII CODE 3DH: Standard Europe international font set...
  • Page 54 3EH: Multingual international font set 3FH: Portuguese international font set...
  • Page 55 40H: Canadian French international font set 41H: NORDIC international font set...
  • Page 56 42H: RUSSIA font set 43H: SLAVONIC Font set...
  • Page 57 44H: Katakana font set...
  • Page 58 System Commands Command Format Command List A. Set Baud Rate COMMAND: B COMPUTER:EOT SOH 'B' 'BAUD RATE' 'N' ETB ASCII (04H) (01H)(42H) (31H~37H)(4EH)(17H) Byte 1 DISPLAY: ACK (or NACK if failed) ASCII (06H) (15H) Byte Note: Baud rates 31H: 9600 32H: 4800 33H: 2400 34H: 1200...
  • Page 59 B. Select international code table COMMAND: I COMPUTER:EOT SOH 'I' 'CHAR' ETB ASCII(04H)(01H)(49H)(30H~44H)(17H) Byte DISPLAY: ACK (or NACK if failed) ASCII (06H) (15H) Byte Note : International Character Code C. Save the current view message (Save Demo view data) COMMAND: S COMPUTER:EOT SOH 'S' 'Layer' ETB ASCII(04H)(01H)(53H)(31H~33H)(17H) Byte 1...
  • Page 60 Note: The cursor can be set to the position from 1 to 40 Position 1 means the upper left corner position. Position 20 means the upper right corner position. Position 21 means the lower left corner position. Position 40 means the lower right corner position. E.
  • Page 61 select 33H means display the message with Mode 1+Mode 2. For this Demo display function, you must have saved the message by COMMAND "S" previously, For example, select 37H for displaying layers and select 33H for displaying modes, DSP would display all the three messages saved on layer 1+ layer 2 + layer 3 with both Mode 1 + Mode 2 displaying modes.
  • Page 62 Transmission method Each ASCII character is transmitted with 1 start bit 8 data bits 1 stop bit No parity Note: You may generate your own application software to run the display according to the standard RS-232C communication protocols and the SOFTWARE CONTROL information listed on this chapter.

  • Page 63: Command Modes

    Command Modes The command modes can be selected with the Demo Software. Mode 0: Default Mode 1: EPSON Esc/POS Mode 2: UTC Standard Mode 3: UTC Enhanced Mode 4: AEDEX Mode 5: ICD 2002 Mode 6: CD 5220 Mode 7: DSP-800 Mode 8: ADM 787/788 Mode 0: Default...
  • Page 64 Mode 1: EPSON Esc/POS mode Mode 2: UTC Standard mode...
  • Page 65 Mode 3: UTC enhanced mode Mode 4: AEDEX mode...
  • Page 66 Mode 5: ICD 2002 mode REMARK)* Using command "ESC E r Φ", the value of parameter: r 58= all rows 55= upper row 44= lower row Φspecial function, the value is one of 30= shift mode (default) 31= rotation mode 32= blink mode 33= clear this row and switch to shift mode 34= overwrite mode...
  • Page 67 Mode 6: CD 5220 standard mode...
  • Page 68 Mode 7: DSP-800 mode Mode 8: ADM 787/788 mode...

  • Page 69: Caution On Lithium Batteries

    CE MARK This device compiles with the requirements of the EEC directive 89/336/EEC with regard to “Electromagnetic compatibility” and 73/23/EEC “Low Voltage Directive” This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1)This device may not cause harmful interference.
