Summary of Contents for Bennett Read ONE 114 R
- Page 1 COMPLETE HOME CLEANING SYSTEM USER GUIDE MODEL 114 R...
- Page 3 CONGRATULATIONS ON YOUR PURCHASE Thank you for purchasing a BENNETT READ ONE complete home cleaning system. Your BENNETTT READ ONE incorporates the latest technological advances in home cleaning systems. It imitates the most powerful forces of nature in a sleek, elegant machine to ensure that your home is easily and properly cleaned.
-
Page 4: Important Safety Instructions
• Do not operate the system if the appliance or any other part of the system has been dropped or damaged • Do not disassemble or attempt to repair your BENNETT READ ONE. Return the unit for examination and repair •... - Page 5 • Turn off all controls before unplugging from the electrical outlet • To unplug your BENNETT READ ONE, grasp the plug. Do not unplug by pulling on the electrical cord • Do not handle the plug or vacuum with wet hands •...
-
Page 7: Product View
PRODUCT VIEW Power Switch Pump Switch Spray Hose Connection Flexi Hose Suction Inlet Securing Clips Dirt Collection Tank Motor Unit Detachable Cleaning Solution Tank Carry Handle 10. Post-motor Filter 11. Retractable Power Cable 12. Cleaning Solution Inlet Port 13. Dust Filter Bag (Dry Vacuuming Only) 14. -
Page 8: Operating Instructions
OPERATING INSTRUCTIONS INSTALLING THE FILTERS Open motor unit by releasing both Lift motor unit from dirt collection tank (6) Attach dust filter bag (13): securing clips (5) Line up filter bag connector with housing on inside of dirt tank Twist clockwise to lock bag in place Insert microparticle filter (14) as shown Replace motor unit on dirt collection tank Secure motor using the securing clips (5) - Page 9 Please read these instructions carefully, failure to operate your BENNETT READ ONE according to IMPORTANT: these instructions may cause serious damage to your machine and result in the warranty being void. Attach flexi hose inlet connector (29) by inserting into flexi hose inlet (4)
- Page 10 Grasp the plug (11) at the rear of the machine and pull power cable to its full extent (See warnings). DO NOT extend power cable beyond red warning line on power cable. Insert Plug into the main power supply. Your BENNETT READ ONE is equipped with an automatic cord rewind function. After unplugging the...
-
Page 11: Cleaning The Filters
IMPORTANT: exceptional use from your BENNETT READ ONE. Should your filters be in need of replacement, they can be purchased from the outlet where you originally purchased the BENNETT READ ONE alternatively, please contact Tevo directly at the numbers listed on the last page of this guide. - Page 12 CLEANING THE MICROPARTICLE FILTER (14) The microparticle filter (14) is designed to trap any tiny particles that may escape the filter bag Twist filter securing lock (15) anticlockwise and remove Twist filter securing lock (15) anticlockwise and remove Gently tap filter on a hard surface like the side of the dustbin A soft brush can also be used to brush off any visible dirt / dust For a more thorough clean, use compressed air blown through the centre of the filter DO NOT use water or any liquid to clean the microparticle filter!
- Page 13 PLEASE REMEMBER: Your BENNETT READ ONE will give you years and years of exceptional service. To ensure this, you must regularly check filters, for any blockages to the air flow in your machine. Routinely inspect the attachments, flexi hose, extension wand for blockages that may be caused by normal household dirt such as pet hair, dust, fabric lint, sweet wrappers, etc.
- Page 14 WARNING: Do not use your BENNETT READ ONE to vacuum any hazardous liquids. These include but are not limited to: flammable liquids, boiling liquids, corrosives, acids, oil based liquids, caustic liquids, combustibles, etc.
- Page 15 Fasten foam filter in-place by inserting and tightening the filter securing lock (15) clockwise Replace motor unit on dirt collection tank Secure motor using the securing clips Attach flexi-hose inlet connector (29) by inserting Insert swivel handle (25) into end of into flexi hose inlet (4).
- Page 16 DO NOT extend power cable beyond red warning line on power cable. Insert Plug into the main power is on, the LED light on the switch will supply. Your BENNETT READ ONE is equipped with an automatic cord rewind function. After unplugging be illuminated...
- Page 17 Remove any furniture that may obstruct you during deep cleaning It is advised that deep cleaning takes place as early in the day as possible, to allow ample time for your carpets to dry. Your BENNETT READ ONE will remove up to 80% of the water used in the deep cleaning process. The remainder of the moisture will dry naturally according to the prevailing weather conditions.
- Page 18 Replace motor unit on dirt collection tank Secure motor using the securing clips Attach flexi-hose inlet connector (29) by inserting into flexi hose inlet (4). Push until you hear the both flexi hose securing clips click (30) Insert swivel handle (25) into end of stainless Extend wand to desired length by pressing Attach carpet deep cleaning attachment steel extension wand (22)
- Page 19 Pour 50ml of appropriate BENNETT READ ONE Fill tank with cold tap water. Insert Cleaning solution pipe assembly (33) cleaning formula into solution tank NOTE! DO NOT FILL TANK WITH into tank (8) WARM OR HOT WATER Attach loose end of cleaning solution pipe to...
- Page 20 DO NOT extend power cable beyond red warning line on power cable. Insert Plug into the main power the led light on the switch will be illuminated. supply. Your BENNETT READ ONE is equipped with an automatic cord rewind function. After unplugging Press pump on button (2). If pump is on,...
- Page 21 The BENNETT READ ONE allows you, the user, to control the level of cleaning and drying necessary for your carpet surface. The spray trigger should only be pressed when you need cleaning solution to be sprayed onto the area being cleaned.
- Page 22 UPHOLSTERY, MATTRESSES, CAR UPHOLSTERY, FLUFFY TOYS, BLINDS AND CURTAINS Your BENNETT READ ONE can be used to clean many other surfaces around the home. The setup of the machine, and cleaning principles, are the same as for carpet deep cleaning with only the following changes required: •...
- Page 23 BENNETT READ ONE CLEANING AND MAINTENANCE Your BENNETT READ ONE will give you years of outstanding service. You have a part to play in extending the life of your machine. To ensure that your BENNETT READ ONE continues to provide you with excellent service and your...
-
Page 24: Trouble Shooting
TROUBLE SHOOTING Should you experience any challenges with your BENNETT READ ONE, please check the following before sending it to a repair centre: PROBLEM POSSIBLE CAUSES REMEDIES Reduced spray or no spray 1. Solution tank may be empty 1. Check if pump switch is turned on 2. -
Page 25: Replacement Parts
REPLACEMENT PARTS The items below are available for purchase as accessories for your BENNETT READ ONE. To purchase contact customer care in your area. Details on page 24. ITEM PART NO. PART NAME HVC307C001 Pre-motor Filter ZHVC307C002 Dust Filter Bag... - Page 26 CONSUMER GUARANTEE The BENNETT READ ONE multi-function home cleaning system has a 24 month product guarantee from Tevo (PTY) ltd. Tevo will replace or repair, at Tevo’s option, any defective or malfunctioning part due to manufacturing defect, free of charge from the date of purchase by the original purchaser for 24 months.
- Page 28 COMPLETE HOME CLEANING SYSTEM Brought to you by: 0861 77 88 88 www.tevo.co.za | info@tevo.co.za...
