Premio DSS424S-D4 Quick Manual

Congratulation on your purchase of Premio DSS424S-D4 Storage Server System!
1.
Check the Content
your package contains the following:
# Description
1 DSS424S-D4
Enclosure
2 Motherboard
3 CPU and memory
4 IO Cards
5 Heatsink
6 Slide Rail Kit + Screws
7 Power Cable*
8 Serial Cable*
* Inside the accessories box. Box may consist of screw sets for rail kit or
drives. If any items are missing, please contact your reseller or sales rep.
2.

Get Familiar with the Unit.

DSS424S-D4 is a redundant server supporting dual Intel
processor with a front tray-less 12x 3.5" HDD storage in a 2U
space. Two Asrock motherboards (EP2C612D16NM model),
and internal cabling are preinstalled. Other motherboard
model, IO cards, CPU, and memory preinstalled upon request.
Front View of the Unit
Rear View of the Unit
Installation and service of this product should be conducted by a trained
personnel to avoid bodily injury from electric shock or heavy object
DSS424S-D4 Quick Guide
Version 1.10 – 2017.06.19
of the box. Please confirm that
Image / Description
Asrock DP motherboard
Intel E5 and DDR4
3.
Install 3.5" Drives
suggested to install HDDs after the unit is mounted to the
rack.
Qty
1
2
Opt.
Opt.
2
1 set
2
1
4.

Remove the Controller Node

components required (IO cards, mezzanine, CPU, memory).
5.

Inspect the Controller Node

comprise of an Asrock motherboard, an expander board, an
NTB switch board, power board, 4x internal fan modules (all
connected to the motherboard).
6.
Install OS
Observe ESD (Electrostatic Discharge) practices during integration to avoid
possible damage to the board and / or other components
to the unit as illustrated. It is
.
disk(s)
if required as follows:
to install any
The components
