- Page 1 Seascape14 User Manual Draft V4 18/7/2018...
- Page 2 SSC 14 user manual Mast Mast time / 10 min Jib furler / Bartels F0 Stay adjuster 2x / RF2331 Tie ball 2x with A-frame / RF1317AR...
- Page 3 SSC 14 user manual Mast Add soft shackle for jib. Attach furler to the bow chainplate. Attach stay adjuster to the side chainplate. Use double mens knot to attach A-frame. Leave knots undone to adjust the length. Make a loop in the center and adjust the length.
- Page 4 SSC 14 user manual Mast time / 20 min Jib furler / Bartels F0 Front stay Side stay 2x Front stay dyneema rope Main hallyard Jib hallyard Spi hallyard Dodger elastic rope Dodger thimble 2x...
- Page 5 SSC 14 user manual Mast Attach the furler to the front chaiplate. Prepare the mainsheet. Use dyneema to secure the elastic rope of a dodger. Connect side stays to finishe the dodger assembly. Prepare the spi hallyard. Attach the front stay and prepare jib hallyard.
- Page 6 SSC 14 user manual Mast Prepare the mast and attach side stays to the deck. Secure boom with elastic strap. Lift the mast with mast base and mast foot aligned. Hold it and take the front stay. Attach the front stay.
- Page 7 SSC 14 user manual Mast time / 20 min Gnav block with dyneema / RF15212 Gnav block with dyneema loop / RF15202 Cunningham block with dyneema rope / RF15202 Cunningham block / RF15212 Gnav rope Cunningham rope...
- Page 8 SSC 14 user manual Mast Connect the gnav slider loosely to the mast. Attach the block with dyneema loop and elastic rope. Attach the gnav rope to upper block. Connect the lower block.
- Page 9 SSC 14 user manual Mast Use shackle to attach the cunningham block. Connect the upper block. Use dyneema rope to attach to upper block.
- Page 10 SSC 14 user manual Deck Deck time / 10 min Bowsprit Tackline with tie ball / RF1317AR Single block with swivel shackle/ RF15100 Pole out dyneema with tie ball / RF1317AR Two single blocks / RF15100 + RF35100 Furling line...
- Page 11 SSC 14 user manual Deck Run the furling line through the block. Tie the furling line to the furler. Attach tackline to the mast base. Adjust the position of the bowsprit. Run the tackline through the bowsprit and add tie ball.
- Page 12 SSC 14 user manual Deck Run the poleout to through the assebled double block. Attach the block, run the poleout through. Add tie ball. Tie the poleout back to the saddle.
- Page 13 SSC 14 user manual Deck time / 20 min Jib block with dyneema / RF35101 Snuffer Snuffer elastic rope Snuffer dyneema rope Footstrap Footstrap soft shackle Footstrap elastic rope Footstrap elastic rope Spi hallyard elastic dodger with 2 blocks / RF15100...
- Page 14 SSC 14 user manual Deck Use dyneema to tie the snuffer to the block. Tie jib block to the center of the bar and add snuffer. Attach footstraps to the fixing plate on both sides. Use soft shackle to attach the center of the strap.
- Page 15 SSC 14 user manual Sails Sails time / 40 min Mainsail Mainsheet block with rope / RF45101 Mainsheet rachet / RF46101 Mainsail clew rope Mainsheet swivel cleat / RF5 Mainsheet Trapeze cleat with jib cunningham rope / RF5121 Jibsheet Gennaker...
- Page 16 SSC 14 user manual Sails Tie a hallyard to the head attachment. Lift the main sail. Connect gnav and cunningham. Attach mainsheet block with rope. Add mainsail clew rope.
- Page 17 SSC 14 user manual Sails Attach swivel to the boom with strap. Tie mainsheet to the boom and add mainsheet rachet. Attach trapeze cleat to the furler. Use soft shackle to attach jib. Prepare for lifting the jib. Pull jib hallyard while lifting jib and closing the zipper.
- Page 18 SSC 14 user manual Sails Secure trapeze cleat. Tie a loop to attach the trapeze cleat. Attach the jibsheet to the clew. Take jibsheet to the block and further to sunffer bar.
- Page 19 SSC 14 user manual Sails Tie the hallyard to the head. Attach gennaker tack to tackline. Bring the other end through the hole and secure it. Attach rachets on both side chainplates facing forward.. Run the endless gennaker sheet through the rachets.
- Page 20 SSC 14 user manual Sails Mark the position of the knot. Tighten gnav and cunningham. Tie a double mens knot. Try to repeat first step few times. If necessary repeat the steps 2 and 3. Use the pocket on the mainsail to store hallyard end.
