LORUS W150 Instruction Manual

NREW151C 11-2000
I M
NSTRUCTION ANUAL
CAL. W150 (RCW SERIES)
CAL. W151 (RE5 SERIES)
C H A R A C T E R I S T I C S
1 . T i m e a n d c a l e n d a r :
•Hour, minutes, seconds, year, month, date
and day of the week.
• Fully automatic calendar: The calendar
a d j u s t s a u t o m a t i c a l l y f o r o d d a n d e v e n
m o n t h s i n c l u d i n g F e b r u a r y o f l e a p y e a r s
from the year 1996 up to 2045 (Cal. W150)
or 2000 up to 2049 (Cal. W151).
• T i m e i n d i c a t i o n : C h a n g e o v e r b e t w e e n
12- and 24-hour indications is possible.
2 . S t o p w a t c h : Measures up to 23 hours, 59
m i n u t e s a n d 5 9 s e c o n d s i n 1 / 1 0 0 - s e c o n d
increments for the first hour and in 1-second
increments thereafter.
3 . 7 5 l a p / s p l i t m e m o r y ( C a l . W 1 5 0 ) o r
1 0 0 l a p / s p l i t m e m o r y ( C a l . W 1 5 1 ) :
Up to 75 sets (Cal. W150) or 100 sets (Cal.
W 1 5 1 ) o f l a p t i m e s a n d s p l i t t i m e s c a n b e
stored in memory.
4 . C o u n t d o w n t i m e r : U p t o 2 3 h o u r s , 5 9
minutes and 59 seconds can be set in second
increments.
• After the set time is up, the timer counts
up the time up to 23 hours, 59 minutes and
59 seconds.
• The set time can be used repeatedly unless
c a n c e l e d .
5 . D a i l y a l a r m : The alarm can be set to ring
on a 24-hour basis.
• H o u r l y t i m e s i g n a l : Can be set to ring
every hour on the hour with a single beep.
6 . Illuminating light: The light evenly illuminates
the display for easy viewing in the dark.
B U T T O N S A N D D I S P L A Y S
D a t e
Day
L i g h t
button
PM mark
B
A
Seconds
Hour
Minutes
D C
With each press of button "A", the selection of
the mode can be made in the following order:
A
T I M E / C A L E N D A R S T O P W A T C H
m o d e m o d e
A A
A L A R M M E M O R Y R E C A L L
m o d e m o d e
A
A
T I M E R m o d e
* If the stopwatch is measuring and button "A"
is pressed to change the mode from the STOPWATCH,
the TIMER mode appears, skipping the MEMORY
RECALL mode.
T I M E / C A L E N D A R M O D E
Day D a t e
PM mark
A
B
D C
Hour Minutes Seconds
1 . Press button "A" to show the TIME/CALENDAR
mode.
2 . Press button "B" for 2 to 3 seconds to show
the time/calendar setting display. The second
digits start flashing.
3 . Selection of the digits to be adjusted (flashing)
is made in the following order by pressing
button "C".
Seconds Minutes Hour
→ →
Date Month Year
4 . Press button "D" to set the flashing digits.
O n e d i g i t i s a d v a n c e d w i t h e a c h p r e s s o f
t h e b u t t o n . D i g i t s e x c e p t s e c o n d s m o v e
quickly by keeping button "D" pressed.
S e c o n d s s e t t i n g
P r e s s b u t t o n " D " i n a c c o r d a n c e w i t h a
t i m e s i g n a l . T h e s e c o n d s a r e r e s e t t o
"00" and start immediately.
When the seconds count any number from
" 3 0 " t o " 5 9 " a n d b u t t o n " D " i s p r e s s e d ,
one minute is added and the seconds are
reset to "00".
1 2 - / 2 4 - h o u r i n d i c a t i o n s e t t i n g
Changeover between 12- and 24-hour indications
i s m a d e a l t e r n a t e l y w i t h e a c h p r e s s o f
button "A".
5. A f t e r a l l t h e a d j u s t m e n t s a r e c o m p l e t e d ,
p r e s s b u t t o n " B " t o r e t u r n t o t h e T I M E /
CALENDAR mode.
N o t e s :
1 . When setting the hour digits in the 12-hour
indication, check that AM/PM is set properly.
Only "PM" mark is displayed. For the AM
setting, there is no indication.
In the 24-hour indication, "24" is displayed.
2 . O n c e t h e y e a r , m o n t h a n d d a t e h a v e b e e n
set, the day of the week is set automatically.
3. If the watch is left untouched in the time/
calendar setting display with the digits flashing,
i t w i l l a u t o m a t i c a l l y r e t u r n t o t h e T I M E /
CALENDAR mode in 1 to 2 minutes.
S T O P W A T C H M O D E
• The stopwatch can measure up to 23 hours,
59 minutes and 59 seconds.
• It measures in 1/100-second increments for
t h e f i r s t h o u r a n d i n 1 - s e c o n d i n c r e m e n t s
t h e r e a f t e r .
S t o p w a t c h o p e r a t i o n
P r e s s b u t t o n " A " t o s h o w t h e S T O P W A T C H
m o d e . " C h r o n o " i s d i s p l a y e d f i r s t , a n d t h e n
the STOPWATCH mode appears.
B
A
D
C
Standard measurement
D D C
S t a r t S t o p R e s e t
Accumulated elapsed time measurement
D D D D C
**
S t a r t
S t o p R e s t a r t S t o p R e s e t
* * R e s t a r t a n d s t o p o f t h e s t o p w a t c h c a n b e
repeated by pressing button "D".
L a p t i m e / s p l i t t i m e m e a s u r e m e n t
• A "Start-Finish-End" stopwatch operation system
is used. The data obtained from the start till
f i n i s h o f a r a c e i s r e c o r d e d a s a b l o c k a n d
stored in memory.
Lap time
Split time
A
B
D C
C
D C C
* *
S t a r t L a p / L a p / F i n i s h
s p l i t 1 s p l i t 2 ( F i n a l l a p / s p l i t )
C D
R e s e t E n d
* Lap time measured remains displayed for 5
seconds in the upper row. In the lower row,
t h e l a p n u m b e r i s d i s p l a y e d , f o l l o w e d b y
split time measured. Then, the measurement
in progress appears.
* The time elapsed from the finish of the race
u n t i l t h e e n d o f t h e m e a s u r e m e n t w i l l n o t
be included in the measurement.
* * Lap time/split time can be measured repeatedly
by pressing button "C".
N o t e s :
1 . U p t o 7 5 ( C a l . W 1 5 0 ) o r 1 0 0 ( C a l . W 1 5 1 )
measurements can be stored in memory. If
more than 75 / 100 measurements are made,
the measurements over 75 / 100 will not be
stored in memory.
2 . When the memory has become full and a lap
time/split time measurement is made, "FULL"
appears below the measured lap time, indicating
that the measurement data is not stored in
m e m o r y . T o c h e c k t h e m e m o r y c a p a c i t y ,
change the mode to the MEMORY RECALL
mode, which displays the number of storable
data.
3 . I f t h e l a p t i m e m e a s u r e m e n t e x c e e d s 6 0
m i n u t e s , a n y f r a c t i o n l e s s t h a n a s e c o n d
will be discarded when it is displayed. The
split time recalled in the MEMORY RECALL
mode, which is the accumulation of the actual
lap time measurements, therefore, may not
be exactly equal to the one displayed when
it was measured.
M E M O R Y R E C A L L M O D E
• Up to 75 sets (Cal. W150) or 100 sets (Cal.
W 1 5 1 ) o f l a p t i m e s a n d s p l i t t i m e s c a n b e
stored in memory.
• M e a s u r e m e n t d a t a o b t a i n e d f r o m t h e s t a r t
to finish of a race is recorded as a block, to
which a block number is assigned.
• U p t o 3 8 b l o c k s ( C a l . W 1 5 0 ) o r 5 0 b l o c k s
(Cal. W151) of data can be stored in memory,
a n d s t o r e d d a t a c a n b e r e c a l l e d b l o c k b y
block after the measurement.
M e m o r y r e c a l l o p e r a t i o n
Press button "A" to show the MEMORY RECALL
m o d e . " R E C A L " i s d i s p l a y e d f i r s t , a n d t h e n
the MEMORY RECALL mode appears.
Number of
s t o r a b l e
data
A
B
D C
1. Press button "C" to show the block selection
display. "RUN" and the block number are
displayed.
2 . P r e s s b u t t o n " C " r e p e a t e d l y t o s e l e c t t h e
desired block of data.
* With each press of the button, the block
n u m b e r a d v a n c e s b y o n e , s t a r t i n g f r o m
Block 1.
3. Press button "D" to recall the stored data in
the block. The lap/split number is displayed
f i r s t , a n d t h e n t h e l a p t i m e a n d s p l i t t i m e
are displayed in the upper and lower rows,
respectively.
* With each press of the button, the stored
data is recalled successively from the oldest
to the newest.
H o w t o c l e a r t h e s t o r e d d a t a
• To erase the data block by block:
In the block selection display, press button
"C" to select the block of data to be erased,
a n d t h e n p r e s s a n d h o l d b u t t o n " B " u n t i l
"DEL" appears. The data only in the selected
block is erased from memory.
• To erase the data in all the blocks at a stretch:
In the block selection display with any block
n u m b e r s h o w n , p r e s s a n d h o l d b u t t o n " B "
u n t i l " F R E E " a p p e a r s . T h e d a t a i n a l l t h e
blocks is erased from memory.
N o t e s :
1 . W h e n a b l o c k o f d a t a i s e r a s e d , t h e b l o c k
number is reassigned accordingly.
2. W h e n t h e s t o r e d d a t a i n a l l t h e b l o c k s i s
erased, the mode is automatically changed
to the STOPWATCH.
3 . T h e s t o r e d d a t a c a n n o t b e e r a s e d o n e b y
one.
