LIRA
Architectural Spot & Flood Light
Do not attempt to install or use Luminaire until you have read and
understand this guide and safety labels.
Luminaires must be installed by a qualified professional in accordance
with all national and local electrical and construction codes and
regulations.
Ensure that main power supply is OFF before installing or wiring
luminaire(s).
Do not exceed specified voltage and current input.
Do not use luminaires with a damaged lens, body, or cable.
Not heeding cautions may result in a hazardous situation which can
cause equipment and property damage, personal injury, or death.
This product must be installed in accordance with the applicable
installation code by a person familiar with the construction and
operation of the product and the hazards involved.
GVA Lighting, Inc. 3400 Ridgeway Drive, #14 Missisauga, Ontario L5L 0A2
Tel: + 1 905 569 6044 Email: info@gvalighting.com
™
WARNING
Do not exceed the specified voltage and current input.
Do not exceed the maximum number of specified fixtures in a light
run. Doing so will result in a current overload.
GVA Luminaires have no serviceable parts. Do not attempt to open
the units.
Do not hot swap! Ensure power supply is off before connecting or
disconnecting fixtures.
Do not stare into beam or view directly with optical instruments.
Unauthorized feild repairs will void warranty.
INSTALLATION GUIDE
CAUTION
IG-LIRA, 2018-08-10
gvalighting.com
|
Page 1 / 8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LIRA and is the answer not in the manual?

Questions and answers

Related Manuals for GVA LIRA

Summary of Contents for GVA LIRA

  • Page 1 Doing so will result in a current overload. with all national and local electrical and construction codes and regulations. GVA Luminaires have no serviceable parts. Do not attempt to open Ensure that main power supply is OFF before installing or wiring the units.

  • Page 2: Mounting Plate

    Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate. GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
  • Page 3 Make connections to junction boxes (not supplied) and to the luminaires. NOTE: LIRA luminaire 12 or 24VDC power conductors should be connected in parallel. DMX Common to be also connected in parallel. NOTE: DMX I/O must be connected in series.
  • Page 4 Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate. GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
  • Page 5 Connect Class 2, 12~24VDC output to power conductors of ELV LIRA luminaire : red(+), black(-). Connect DMX I/O to DMX conductors of luminaire. NOTE: LIRA DMX Luminaires require 12VDC or 24VDC Class 2 or limited to 25A Power Supply with Class 2 outputs. If PSU is other than Class 2, provisions must be made to create Class 2 outputs.
  • Page 6 Connect Class 2, 12~24VDC output to power conductors of ELV LIRA luminaire : red(+), black(-). NOTE: LIRA Non-Dimming Luminaires require 12VDC or 24VDC Class 2 or limited to 25A Power Supply with Class 2 outputs. If PSU is other than Class 2, provisions must be made to create Class 2 outputs.
  • Page 7 Connect Class 2, 12V Constant Current output to power conductors of ELV LIRA luminaire : red(+), black(-). NOTE: LIRA Constant Current Luminaires require at lease 12V constant current Class 2 or limited to 25A Power Supply with Class 2 outputs. If PSU is other than Class 2, provisions must be made to create Class 2 outputs.
  • Page 8 Specifications are subject to change without notice. Every effort has been made to ensure that the information provided in this manual is accurate. GVA Lighting Inc. is not responsible for printing or clerical errors. Refer to www.gvalighting.com for additional information.
