1834i-English_Manuals 4/27/17 2:22 PM Page 1
Self-Leveling Cross-Line Laser
Model No. 40-6603
Instruction Manual
Congratulations on your choice of this Self-Leveling Cross-Line Laser. We
suggest you read this instruction manual thoroughly before using the
instrument and save this instruction manual for future use.
This is a Class II laser tool and is manufactured to comply with CRF 21,
parts 1040.10 and 1040.11 as well as international safety rule IEC 285.
©2017 Johnson Level & Tool
1
