List of spare parts

The following spare parts and accessories are available via our Customer Service
Depart
No. Part No. Designation
1 1151C01 Male water supply
connector
2 1151014 Nut
3 1151003 logo W
4 1108003 S1600 knob
5 1151C02 panel assembly
6 B400013F Cross recessed pan head
tapping screw ST3.5X16
7 01125IB Pump assembly
8 1151C03 hood assembly
9 1119208 U shape pin
10 1151C04C switch assembly-ESO
plug 5.6m power cord
11 1151C05 left Wheel
12 1119005 Gun holster
13 1151C06 Rear housing assembly
14 1129010 Cord bracket
15 B504006 Washer Φ6
16 B400063F Cross recessed pan head
tapping screw ST6.3X22
17 B504008B Washer Φ8
18 B304025B Hexagon socket cap
screwM8X25
19 1151C07 Right Wheel
20 1130013 Detergent tank
+44 (0) 190 472 7501
AFTER SALES SUPPORT GB
+353 (0) 19022605
IRE
11
No. Part No. Designation
21 1151C08 Detergent hose
22 1119003 Detergent tank cap
23 1130012 Accessories holder
24 1142005 Nozzle pin
P1235C
25 B400012F Cross recessed pan head
tapping screw ST3.5X9.5
26 1151C09 Hose reel crank
27 1151C10 Right alu. Bar assembly
28 B620008 Tapping screw and washer
assemblies ST3.5X9.5
29 1151C11 Carrying handle
30 1151C12 Left alu. Bar assembly
31 1128806 Hose assembly(short)
32 B282015H Split washer Φ9
33 1119020 Bracket plate pinch
34 B400043F Cross recessed pan head
tapping screw ST3.5X13
35 1151C13 hose reel
36 1136801 Hose assembly
37 1119202 Rotary joint assembly
38 1151C14 cleaning agent
39 1132802 Rotary brush
40 1106B21 Turbo lance
26
www.coreservice.co.uk
Q1W-SP14-1900A

Warranty

The machine comes with a three-year warranty which begins on the day of purchase.
Please retain the till receipt as proof of purchase.
During the warranty, a defective high-pressure washer can be returned free of charge to
our service address. You will then receive a new or repaired machine by return.
Before sending the machine for repair, please call our service on the phone number sta-
ted below. We will send you a return label for sending us your machine free of charge.
Once the warranty has elapsed, you can also send the defective machine to the address
below for repair. You will be charged for repairs arising after the warranty has elapsed.
Your statutory rights are not affected by this warranty.
+44 (0) 190 472 7501
AFTER SALES SUPPORT GB
+353 (0) 19022605
IRE
12
