POWER
The Camel Toe Overdrive MkII is powered by a single 9-volt battery,
™
a 9-volt AC adapter such as the Dunlop ECB003/ECB003EU, or the
DC Brick and Iso-Brick power supplies. The power input is a
™ ™
5.5mm x 2.1mm jack with the positive voltage on the outer sleeve.
Us i n g a n ex te r n a l p owe r s u p p l y w i l l d i s c o n n e c t t h e ba t te r y.
Disconnect the input jack to preserve battery life when not in use.
The pedal will lock into bypass mode when it is time to change the
batter y. It also includes power protection circuitr y to prevent
damage from AC power supplies.

SPECIFICATIONS

RHINO
INPUT IMPEDANCE.........> 400 kΩ
OUTPUT IMPEDANCE.......< 100 Ω
NOISE FLOOR................... - 98 dBV
- 100 dBV
NOISE FLOOR ( Classic )...
BYPASS........................................................................Relay True Bypass
DIMENSIONS......................................................4-25/32" x 3-3/16" x 1-3/4"
WEIGHT..............................................................................................13oz
CURRENT DRAW.............................................................................110 mA
ENGAGED........................................................................................110 mA
BYPASSED......................................................................................22.8 mA
POWER SUPPLY......................................................................... 9 volts DC
All measurements made with controls at center.
Noise measurements are A-weighted.
LLAMA
INPUT IMPEDANCE............100 kΩ
OUTPUT IMPEDANCE.......< 10 kΩ
NOISE FLOOR..................-85 dBV
