PAG NPH
Ni-Mh NP1 Battery
Model No. 9323
Instruction Manual
CONTENTS
SECTION
1
SPECIFICATION
2
CARE & MAINTENANCE
3
INSTRUCTIONS FOR USE
4
SAFETY
5
WARRANTY
U5000A PAG NPH INSTRUCTION MANUAL
PAGE
2
3
4
5
6
1
SECTION 1
SPECIFICATION
1.1
Description: Model 9323 PAG NPH Ni-Mh Professional Broadcast
NP1 type Battery.
1.2
Construction: PAG NPH batteries have welded cell interconnections
of low-resistance nickel strap. The case for these models consists of
high-impact injection mouldings designed to protect the cells from
impact damage. The batteries are sealed and non user-serviceable.
1.3
Cells: Premium grade Nickel-Metal Hydride sealed rechargeable
cylindrical cells.
1.4
Voltage: 13.2V nominal (11 cells connected in series, nominal
voltage 1.2V per cell).
1.5
Capacity: 2.2Ah, measured at the one-hour rate.
1.6
Output Current: Rated maximum output 10A continuous.
1.7
State of Charge Indication: An LED-array charge indicator is
incorporated.
1.8
Output Protection: The PAG NPH battery is protected against
short circuit and excessive currents by means of a self-resetting
protection device. The battery is also protected against over-
temperature by means of a non-resetting thermal fuse rated 98°C.
1.9
Operating Temperature Range: Optimum discharge efficiency is
achieved within the temperature range +10°C to +40°C.
1.10 Weight: 730gm (1.6lb approx.)
1.11 Size: 182mm (H) x 71mm (W) x 25mm (D).
U5000A PAG NPH INSTRUCTION MANUAL
2
