Seuic AutoID 6L-W Quick Start Manual

Do not throw away : Apply to some electronic components,
such as battery, etc., some components may cause an explosion,
pollution or other adverse consequences to the environment,
and should be used for recycling.
Environmental protection life span mark: The number in this
logo means that the normal environmental protection life span
is 10 years, harmful substances or elements contained in the
product during this period will not be disclosed, will not cause
serious pollution to the environment or its personal, property
damage. Some parts may also have environmental protection
use period logo, its environmental protection service life is
identified by the number.

Technical Support

Please visit SEUIC' s official website www.chinaautoid.net to
download User Manual, SDK, different Apps or software in order
to help you better use the device.
2017 SEUIC Company. All rights reserved.
It is strictly prohibited to copy, transfer, distribute and store any
content in the document in any form without the SEUIC's
permission.
JIANGSU SEUIC TECHNOLOGY CO.,LTD
Company address: NO.15 Xinghuo Road,Nanjing New High
Technology Industry Zone,Nanjing City,Jiangsu Province, China
Hotline: 0086-400-777-0876
Company official website:www.seuic.com
Products official website: www.chinaautoid.net
Mailbox: AUTOID@seuic.com
Post code: 210061
6
JIANGSU SEUIC TECHNOLOGY CO.,LTD
QUICK START GUIDE
Power on/off
Scan indicator Power indicator
Flash light
Camera
Loud speaker
USB port
ESC key
Scan button
Hard keyboard Rest key
switch
Hard keyboard
Custom key
Microphone
（Picture 1）
（Picture 3）
Apply series：
1
Install battery and battery cover
Take out the device and battery from the package. Install the battery
and battery cover according to Picture 2.
First use
For the first time, please make sure the battery, has enough power
Scan engine
supply for the system to boost.
Power on
Long press power key until PDA vibrates to power on the device.
Power off
Long press the power button for more than 5 seconds, when the
Memery card
slot indicator light on the top right of the terminal is extinguished, terminal
shuts down.
SIM card slot
Install SIM card and SD card
PSAM card slot
（Picture 2）
Remove the battery, and insert SIM card into the right card slot
(Note：The terminal does not support small card), the lower-left side is
PSAM slot, insert it according to the direction of the slot. The top-left
side is a memory card slot, insert it according to the direction of the slot.
(Note：The terminal does not support SIM card hot plug, need to restart
terminal after accident hot plug).
Charging
The device could be charged through USB cable with power adapter.
Battery cover lock
USB cable: Connect the PDA to the power socket using an USB data
cable and a power adapter, or connect the PDA to the computer via
the USB data cable. Red indicator of PDA means under charging, green
one means full charged.
Note：If the device will not used for a long time, please charge the
device at least once every two months to ensure the battery and backup
battery won't over discharge.
®
6L W
2
