Advanced Poly-Packaging T-200 Operation Manual page 24

4.1 Recommended Spare Parts List
The following spare parts are recommended for your inventory and include components which can easily
be replaced. These items are either wear items or other components which may fail during the day to day
operation of the machine.
PART NO
TP-T8MA00140
TP-T8MA00130
TP-108153
TP-406181
TP-214215
TP-402176
TP-403124
TP-T8ME0161
TP-T8ME0161-1
4.2 Parts / Component Identification
This section includes assembly drawings of the T-200. Please use APPI part numbers whenever possible
to order replacement parts. You can also refer to Drawing Numbers and Corresponding Item Numbers on
the drawings to assist in determining the required components. See sections A-E.
4.3 Pneumatic Diagram
Refer to Dwg NO. T-200 PNE, section F, for the Pneumatics diagram.
4.4 Wiring Diagram
Refer to Dwg, Section G, for T200 Table Top Bagger with PLC wiring diagram.
23
Level 1 Spare Parts Kit
DESCRIPTION
Seal Bar Rubber Strip
Teflon Sheet
Extension Springs
4 Micron Filter
O-Rings
Solenoid Valve
Pneumatic Cylinders
Anti-Jam Sensor Board Assembly.
Pig Tail for Anti-Jam Board
QTY
1
1
2
1
5
2
2
2
2
