Girl tech Password Phone G8067 Instruction Manual

Model G8067
INSTRUCTION MANUAL
P/N 82348200 Rev.A
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety pre-
cautions should always be followed to reduce the risk of
fire, electric shock and injury to persons, including the
following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the
product.
3. Unplug this product from the wall outlet before clean-
ing. Do not use liquid cleaners or aerosol cleaners.
Use a damp cloth for cleaning.
4. Do not use this product near water, for example,
near a bath tub, wash bowl, kitchen sink, or laundry
tub, in a wet basement, or near a swimming pool.
5. Do not place this product on an unstable cart, stand,
or table. The product may fall, causing serious dam-
age to the product.
6. Slots and openings in the cabinet and the back or
bottom are provided for ventilation, to protect it from
overheating, these openings must not be blocked or
covered. The openings should never be blocked by
placing the product on the bed, sofa, rug, or other
similar surface. This product should never be placed
near or over a radiator or heat register. This product
should not be placed in a built-in installation unless
proper ventilation is provided.
7. Never push objects of any kind into this product
through cabinet slots as they may touch dangerous
voltage points or short out parts that could result in a
E risk of fire or electric shock. Never spill liquid of any
kind on the product.
8. To reduce the risk of electric shock, do not disassem-
ble this product, but take it to a qualified serviceman
when some service or repair work is required.
Opening or removing covers may expose you to dan-
gerous voltages or other risks. Incorrect reassembly
can cause electric shock when the appliance is sub-
sequently used.
9. Unplug this product from the wall outlet and refer
servicing to qualified service personnel under the fol-
lowing conditions:
a) When the power supply cord or plug is damaged
or frayed.
b) If liquid has been spilled into the product.
c) If the product has been exposed to rain or water.
d) If the product does not operate normally by
following the operating instructions. Adjust only
those controls, that are covered by the operating
instructions because improper adjustment of other
controls may result in damage and will often
require extensive work by a qualified technician to
restore the product to normal operation.
e) If the product has been dropped or the cabinet has
been damaged.
f) If the product exhibits a distinct change in
performance.
10. Avoid using a telephone (other than a cordless type)
during an electrical storm. There may be a remote
risk of electric shock from lighting.
11. Do not use the telephone to report a gas leak in the
vicinity of the leak.
SAVE THESE INSTRUCTIONS
CAUTION:
To reduce the risk of fire or injury to persons, read and
follow these instructions:
1. Use only the following type and size batteries:
Requires 3 "AA" (LR6) size batteries (we recommend
alkaline).
2. Do not dispose of the batteries in a fire. The cell may
explode. Check with local codes for possible special
disposal instructions.
3. Do not open or mutilate the batteries. Released elec-
trolyte is corrosive and may cause damage to the
eyes or skin. It may be toxic if swallowed.
4. Exercise care in handing batteries in order not to
short the battery with conducting materials such as
rings, bracelets, and keys. The battery or conductor
may overheat and cause burns.
5. Do not attempt to recharge the batteries provided with
or identified for use with this product. The batteries
may leak corrosive electrolyte or explode.
6. Do not attempt to rejuvenate the batteries provided
with or identified for use with this product by heating
them. Sudden release of the battery electrolyte may
occur causing burns or irritation to eyes or skin.
7. When replacing batteries, all batteries should be
replaced at the same time. Mixing fresh and dis-
charged batteries could increase cell pressure and
rupture the discharged batteries.
8. When inserting batteries into this product, the proper
polarity or direction must be observed. Reverse inser-
tion of batteries can cause charging, and that may
result in leakage or explosion.
9. Remove the batteries from this product if the product
will not be used for a long period of time (serveral
months or more) since during this time the battery
could leak in the product.
10. Discard "dead" batteries as soon as possible since
"dead" batteries are more likely to leak in a product.
11. Do not store this product, or the batteries provided
with or identified for use with this product in high-tem-
perature areas. Batteries that are stored in a freezer
or refrigerator for the purpose of extending shelf life
should be protected from condensation during stor-
age and defrosting. Batteries should be stabilized at
room temperature prior to use after cold storage.
SETTING UP YOUR PASSWORD
PHONE™
1. Remove the screw on the battery compartment door
(located on the back of your Password Phone).
Remove the battery compartment door and insert
three (3) AA batteries (we recommend alkaline) with
the negative (-) ends against the springs.
NOTE: Notice the pinhole below the battery compart-
ment. Should you ever need to reset your phone,
insert a straightened paper clip into the pinhole and
push down firmly.
2. Replace battery compartment door.
3. Using the phone cord provided, plug the Password
Phone into the telephone outlet already installed in
your home.
NOTE: If there isn't a telephone outlet installed where
you want to use your Password Phone, you will need to
have one installed.
ADULT SUPERVISION IS RECOMMENDED WHEN
INSTALLING BATTERIES AND PLUGGING IN YOUR
PASSWORD PHONE.
Flash
Ringer
Talk / Off
Volume
Escape
Security
Mic
Password Key
/ Directory
Compartment
List
Add
Call
Erase
Phone
Directory
Password On / Off
Set Password
RECORDING YOUR PASSWORD
1. Turn your Password Phone on by pressing the
Talk/Off button. A yellow light will glow when your
Password Phone is turned on.
2. The first time you turn on your Password Phone, you
will be asked to "Record your password". When
prompted and green light inside directory compart-
ment comes on, speak your password into the mic.
3. You will be asked to "Repeat your password". Again,
speak your password into the mic. If your password
has been accepted, you will hear "Password
accepted" and your Password Phone will go to the
Add mode. If your password wasn't accepted, you
will be prompted to "Please begin again" and you will
need to repeat steps 2 and 3.
To change your password at a later time, press the Set
Password button and repeat steps 2-3 above.
ADDING NAMES AND PHONE NUMBERS
Your Password Phone can store up to 10 phone num-
bers, selectable by simply saying your friend's name.
After recording your password, your Password Phone
will automatically switch to the Add mode where you add
friends to your phone list.
1. You will be asked to "Record your friend's name".
When prompted and green light inside directory
compartment comes on, speak your friend's name
into the mic.
2. You will be asked to "Please repeat name". Again,
speak your friend's name into the mic. If the name
has been accepted, you will hear "Name accepted".
If not, you will hear "Please begin again" and you will
need to repeat steps 1 and 2 again.
3. Once you hear "Name accepted", you will then be
prompted to "Press numbers, then press pound".
Using the keypad, enter that friend's phone number
followed by the # key.
4. You will hear "Number accepted". To add another
friend, press the Add button. To exit the Add Mode,
press the Escape (*) Key.
If you would like to add more friends' numbers at a later
time, you can return to the Add Mode by pressing the
Add button, then repeating the steps above. If you
already have 10 friends in your directory, you won't be
able to add any more or make changes to your list until
you have erased an old entry.
NOTE: Since your Password Phone cannot repeat your
friend's name, only the number corresponds to that
friend (Example: "friend three"), it is important that you
write your friend's name, in pencil, next to the appropri-
ate number, in the Phone Directory.
