Thank you for purchasing one of our XOMAX products! We appreciate your confi-
i
Please read the following manual carefully before you install and use the unit.
Please save this manual in case you will need to clarify further possible ques-
tions regarding installation and usage of our product.
We are constantly trying to keep our online-library of user's manuals for our
products up-to-date. In case you miss some information or if something should
be unclear, please visit our homepage
version of user's manual or contact our customer service.
Please note: Any alternations and changes of technical data or/and design
due to technical update of some models need no advertisement.
We appreciate our environment, so to keep it safe and clean, we
do not print our manuals on paper but provide our products with
manuals in digital version created in *.pdf format.
You can find and download them anytime on our homepage
www.xomax.de, view them on your mobile devices and print
them for yourself if needed.
XOMAX
User's Manual
XM-2VA718
XM-2DA9605
dence. Enjoy your brand new multimedia unit!
Version 1.0
Last update 02.05.2018
www.xomax.de/download
ENGLISH
for a current

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XM-2VA718 and is the answer not in the manual?

Questions and answers

Related Manuals for Xomax XM-2VA718

Summary of Contents for Xomax XM-2VA718

  • Page 1 User's Manual XM-2VA718 XM-2DA9605 Thank you for purchasing one of our XOMAX products! We appreciate your confi- dence. Enjoy your brand new multimedia unit! Please read the following manual carefully before you install and use the unit. Please save this manual in case you will need to clarify further possible ques- tions regarding installation and usage of our product.

  • Page 2: Table Of Contents

    Thema: Table of contents Table of contents Automatic frequency scan ....13 Safety instructions and precau- Store the found stations ....13 tions Switch AM/FM .......13 Handling by stop only ...... 4 LOC signal sensitivity .....14 Installation ........4 AF funktion ..14 (Alternative Frequency) Regular loudness ......
  • Page 3 Thema: Table of contents Mirror Link Start Bluetooth mode .....20 Pairing the unit with an external Android USB connect......31 device ..........20 iPhone WIFI connect ......33 Common information .....21 Make a call ........21 AUX-IN Modus Take a call ........21 Common information .....34 End / reject the call .......22 Start the AUX mode .......35 Phone book........22...

  • Page 4: Safety Instructions And Precautions

    Thema: Safety instructions and precautions Due to flawed warranty seal the Safety instructions and warranty becomes invalid. precautions Power supply Handling by stop only Use the unit connected only to 12 Volt on-board power supply. The minus (-) To avoid any accidents please don't should be connected with the ground handle the unit while you driving.

  • Page 5: Cleaning Of The Unit

    Thema: Safety instructions and precautions Only for XM-2DA9605: Cleaning of the unit Please keep the unit clean and remove The risk of injuries the dust from it regularly. Please use for Do not open the cabinet or modify that a soft and dry cleaning rag. the unit.

  • Page 6: Installation

    The detailed installation manual cutted or short-circuited. Otherwise the you can find on our homepage: warranty becomes invalid. www.xomax.de. » Before the installation please make The printed version of a common sure that your vehicle has the 12 Volt installation manual you can find in on-board power supply.
  • Page 7 Thema: Installation of the cables in each case have the connect it with the vehicle battery. same purpose. To connect everything » Do not ever connect speaker cables correctly please refer to the manuals of among one another. In case you do not the both devices.

  • Page 8: Operating Elements Of The Unit

    Thema: Operating elements of the unit Operating elements of the unit XM-2VA718: XM-2DA9605:...
  • Page 9 Thema: Operating elements of the unit Maximal harddisk supported volume: 2 Home menu Press the button to enter the main menu. RES Reset Deletes all the customer's adjustments Back and sets the unit back to factory Return to the previous screen or menu settings.

  • Page 10: Use The Unit

    Thema: Use the unit Use the unit Use apps Tap an app to open it. Customize the unit Arrange apps Swipe left or right to see other screens. Touch and hold any app on the Home screen, and then drag the app around. Drag an app to the edge of the screen to move it to a different Home screen.

  • Page 11: Change The Wallpaper

    Thema: Use the unit Change the wallpaper You can set an image or photo as wallpaper for the Home screen. You can choose from the preset Live Wallpapers (dynamic) and Wallpapers (stills), or choose from images or photos stored on a USB storage device or an SD memory card. Change the wallpaper.

  • Page 12: Radio Mode

    Thema: Radio mode Radio mode Touch icon in the main interface to enter into the radio interface. Broadcast frequency slider Manual tuning Manual tuning Band indicator RDS indicator Current frequency Preset channel list APS Auto Search FM Band (FM1, FM2 or FM3) Stereo/Mono AM Band...

  • Page 13: Automatic Frequency Scan

    Thema: Radio mode Automatic frequency scan Touch radio menu's sensor key can scanning stations automatically and [Scan] store the strongest signal stations on the screen. Hold sensor key, short-press to browse stored stations. [Intro] Store the found stations There are 30 memory cells in total to store your favorite radio stations: P1-P18 within FM and P1-P12 for AM frequency band.

  • Page 14: Loc Signal Sensitivity

    Thema: USB/SD mode LOC signal sensitivity Touch the sensor key to switch between the local and distanced stations mode. When the function is activated the radio searches only for the local stations with the strong enough broadcasting signal. Otherwise the radio finds the more distant stations as well.

  • Page 15: Audio Mode

    Thema: Audio mode Audio mode Data media display Shuffle / Repeat File name ID3Tag - display Playback progress Equalizer File Browser Play / Pause sensor key pauses the playback, the key resumes it. Previous / Next track Touch the sensor keys on the touchscreen. FF / Rewind Put your finger on the cursor of the playback progress bar and scroll it to the requi- red time point.

  • Page 16: Folder Browser

    Thema: Audio mode Folder browser Touch the - sensor key on the right of the toolbar or move the audio menu to the right with your finger. File browser Move the audio menu to the left with your finger. Touch on the desired file to start playback. The screen immediately changes to the playback mode.

  • Page 17: Video Mode

    Thema: Video mode Video mode For safety reasons, video images cannot be viewed while your vehicle is in motion. To view video images, stop in a safe place and apply the parking brake. Home menu Playback progress File menu Full screen mode Pause/play Next file Repeat...

  • Page 18: Repeat / Random Playback

    Thema: Video mode Repeat / Random playback Touch the sensor key ( ) to switch: REPEAT ALL RANDOM PLAYBACK NORMAL PLAYBACK REPEAT SINGLE Folder browser Touch the - sensor key on the right of the toolbar or move the video menu to the right with your finger.

  • Page 19: File Browser

    Thema: Picture viewer mode File browser Move the video menu to the left with your finger. Picture viewer mode Open the picture Swipe your finger over the second menu page and press the icon to start the gallery. Display the options Tip the touchscreen during the slide show.

  • Page 20: Bluetooth Connection

    Thema: Bluetooth connection Tap the icon on the status bar to show for more features. Scroll down to see more features. Bluetooth connection Please note: all the names and numbers used on the images of this user manual serve as an example only and any match with real life persons and their data are coincidentally and unintentionally.

  • Page 21: Common Information

    Thema: Bluetooth connection Once you have connected via Bluetooth the unit with an external device of your choice, the connection will be built automatically as soon as the device appears in the receiving area of the unit. The Bluetooth function should be "ON" both on the external device and on the unit.

  • Page 22: End / Reject The Call

    Thema: Bluetooth connection End / reject the call Press when the conversation is over or by an incoming call. Phone book To access the phone book press and Press to import the data from your cell phone. The confirmation of share of the cell phone data can be required. All the imported data remain stored in the unit's memory and are available even if the connection between the unit and the source (cell phone) is interrupted.

  • Page 23: Phone Protocol

    Thema: Bluetooth connection Phone protocol Press to call up the lists. There are three types of protocols: dialed numbers, incoming calls, missed calls: - incoming calls - dialed numbers - missed calls Bluetooth settings You can change the Device Name of this unit. Tap CARKIT to enter a different name.

  • Page 24: Bluetooth Music

    Thema: Bluetooth music Bluetooth music Common information The "Bluetooth music" feature allows to play the music from the external device of your choice (cellphone, smartphone, tablet PC) via car radio speakers. The device should support the A2DP service. Start Bluetooth music Swipe your finger over the second menu page and press - icon.

  • Page 25: Setup

    Thema: Setup Setup Swipe your finger over the second menu page and press - icon. Wi-Fi setup Turn Wi-Fi - "ON". Choose a network: Tap one of the listed networks and then enter the password if required.

  • Page 26: Display

    Thema: Setup Display Brightness level Drag the slider to adjust the screen brightness. Wallpaper Set an image or photo as wallpaper for the Home screen. Font size Choose from Small Normal Large Huge Sound Key tone Choose from High Middle Volumes Drag the slider to adjust the volumes.

  • Page 27: Ampliefier (Eq And Fader Setting)

    Thema: Setup Ampliefier (EQ and Fader setting) The user can present a sound effect: Rock Jazz Classic Flat Voice manualy adjust the slider to set the value of sound effect: Custom Loudness Touch the - sensor key to turn on or off of loudness. Fader and Balance Touch the - sensor key to enter the sound field mode page.

  • Page 28: System

    Thema: Setup Now touch the - icon on the main menu to open the navigation App. System Scroll down the Settings menu and tap System to see more settings. Languages & input Click " " to access language setting interface, as shown in below: Languages &...

  • Page 29: Date & Time

    Thema: Setup Drag the selected language up to activate the language. Date & time Touch the to remove the GPS automatic update time Automatic date & time check. Touch the and adjust the year, month and date. Set date...

  • Page 30: Reset

    Thema: Mirror Link Touch the and adjust the hour and minutes. Set time Reset Restore the factory settings. ALL data will be deleted from the internal memory of the car radio. Mirror Link Tap Easy Connected on the apps menu screen to enter screen mirroring mode. When you connect a mobile phone with compatible applications installed, you can control the applications for the mobile phone directly from this unit.

  • Page 31: Android Usb Connect

    Thema: Mirror Link Android USB connect On your Android smartphone or tablet: go to > , and then Settings About Device up to 7 times to enable Developer options. Build number Turn on USB debugging. A message "Allow USB debugging?" will pop up. Turn on the Always allow from this computer option, and then tap OK.
  • Page 32 Thema: Mirror Link To use MirrorLink feature, you need an "EasyConnection" app on your mobile device. Install the "EasyConnection" app from the Google PlayStore and start the software on your smartphone or tablet. Slide to the second page in the main menu on the car radio. Tap the icon to launch the MirrorLink application.

  • Page 33: Iphone Wifi Connect

    Thema: Mirror Link iPhone WIFI connect On your iPhone: Go to > , and then turn Settings Personal Hotspot Personal Hotspot , and then select your iPhone name from the hotspot list. Enter the iPhone WiFi password when prompted. in the Control Center on your iPhone. Select and turn AirPlay EC-Mirror...

  • Page 34: Aux-In Modus

    Thema: AUX-IN Modus On iPhone 4/4s, only photos can be streamed wireless to this unit. On iPhone 5 and other later iPhone models, both music and photos can be streamed wireless to this unit. Video streaming requires the appropriate Apple cable or adapter.

  • Page 35: Start The Aux Mode

    Thema: Rear view camera (optional) Right (red). Start the AUX mode Press the - icon on the screen. If the device is a videoplayer it's picture appears on the unit's screen. Otherwise only the audio signal will be transmitted. Rear view camera (optional) Common information A rear view camera is an optional accessory.

  • Page 36: Common Solutions

    Common solutions Common solutions The following advices are generally valid and refer to diverse XOMAX models with the similar characteristics. Please note that some articles may refer not to your model exactly and may contain the describtion of features and functions that your model does not support.
  • Page 37 Thema: Common solutions Poor radio recep- For problem-solving regarding the radio reception it is tion: important to know the type of the antenna of your vehicle. The radio tuner finds no broadcaster or the Here are the possible solutions for each type of the antenna: reception is poor.

  • Page 38: Disposal / Recycling Information

    Batteries that contain pollutants (e.g. Hg = mercury, Pb = lead, Cd = cadmium) are labelled with the symbol pictured above. At our place you can free dispose of the empty batteries purchased at our store. XOMAX in the world wide web XOMAX distribution worldwide Purchase XOMAX car radio online: XOMAX manufacturer's information: https://www.carmediashop.de...
